- Page 1 Operating instructions Mode d’emploi Bedienungsanleitung Gebruiksaanwijzing Istruzioni per l’uso ECOLINE...
- Page 2 English ............ pag. 3 - 6 Français ............ pag. 7 - 10 Deutsch ............ pag. 11 - 14 Nederlands ............ pag. 15 - 18 Italiano ............ pag. 19 - 22...
-
Page 3: Safety Warnings
Part 1 - INSTALLATION INSTRUCTIONS 1 - GENERAL This hood is constructed ready for installation in the bottom part of an overhead unit fixed above a cooker and fastened to a wall. It can be used either in the ducting version (evacuation of air to the outside) or in the filter version (internal recirculation of air). -
Page 4: Electrical Connection And Working Test
If the base is pre-drilled and suitable to take the hood, it will be sufficient to screw the hood onto it using the four 4.2 x 44.5 mm screws provided. If the base is not pre-drilled the hood must be correctly positioned and screwed into place from the inside outward, using 3.5 x 16 mm screws. -
Page 5: Metal Grease Filters
2 - If the hood does not have a plug, it can be connected by means of a special earthed connection. Always comply with the warnings given in points 2.3, 2.4 and 2.5 of the safety instructions. 3 - Once the electrical connection has been completed, check that the worktop illumination, motor and speeds work properly. -
Page 6: Worktop Illumination
c - Remove the wire filter holder and replace the grease filter d - Replace the ducting grille panel. CAUTION: always comply with the cleaning and maintenance times given above, to prevent any risk of fire due to filters that are saturated with grease. 2.3 - Activated charcoal filter 1 - Function The activated charcoal filters absorb smells and odours until they reach saturation point. - Page 7 4323817 02 - 1198...
