- Page 1 Gebrauchsanweisung , Notice d'utilisation et d'installation EFP 6430 Instrucciones de montaje y manejo , User manual...
-
Page 2: Table Of Contents
Contents Safety warnings for the installer for the user Introduction Extractor version Filter Version Description of the Appliance Control Panel Correct ventilation Maintenance and care Cleaning Metal grease filter Open the metal grease filter Charcoal filter Changing the light bulb(s) Technical Specifications Special accessories Installation... -
Page 3: Safety Warnings
Safety warnings for the installer • When the hood is used in its extractor function, • When used as an extractor unit, the hood must the following rules must be followed to obtain be fitted with a 120mm diameter hose. optimal operation: •... -
Page 4: Introduction
Introduction • The hood is supplied as an extractor unit and can also be used with a filtering function by fitting one charcoal filter (special accessory). • You will need original AEG charcoal filter KLF 60/80 for this function (see Special Accessories). -
Page 5: Control Panel
Control Panel • The switches are arranged on the upper right side of the vapour catcher. (Fig. 1 - E). The numbers and symbols have the following meanings (Fig. 2 - from left to right): blower set 1 blower set 2 blower set 3 blower set 4 light... -
Page 6: Maintenance And Care
Maintenance and care The hood must always be disconnected from the electricity supply before beginning any maintenance work. Warning Cleaning • Failure to observe the instructions on cleaning • Warning: always disconnect the hood from the the unit and changing the filters will cause a fire mains power supply before cleaning it. -
Page 7: Charcoal Filter
Charcoal filter • The charcoal filter should only be used if you want to use the hood in its filtering function. • To do this you will need an original AEG charcoal filter (see special accessories). • Replacing the charcoal filter The charcoal filter must normally be replaced at least once every year. -
Page 8: Technical Specifications
Technical Specifications Dimensions (in cm) Height 39,5 Width 59,8 Depth 27,5 + Lichtblende (max. 430 + Lichtblende) Lighting: 2 x 40 W (E14) Grease filter Maximum absorbed power 320 W We reserve the right to generate constructive and chromatic modifications as required by technological growth. Special accessories Charcoal filter KLF 60/80 E-Nr. -
Page 9: Mounting Accessories Included
Installation Mounting accessories included 1 deflector 4 spacer discs 1 metal screws 2,9x13 2 metal screws 2,9x9,5 2 metal screws 3x9 4 wood-screws 4,5 x 16 mm 1 flange Ø 120 mm Preparing the wall unit - Extractor version • The hood is supplied as an extractor unit. Before installing the hood, drill a hole in the roof of the wall unit (see fig. -
Page 10: Installation
