- Page 1 Extender for 1.3 over CAT6 GTV-HDMI1.3-CAT6 User Manual www.gefentv.com...
-
Page 3: Asking For Assistance
Chatsworth, CA 91311 www.gefentv.com support@gefentv.com Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. Extender for HDMI 1.3 Over CAT-6 is a trademark of Gefen Inc. -
Page 4: Table Of Contents
Introduction Operation Notes Features Sender Unit Panel Layout Sender Unit Panel Descriptions Receiver Unit Panel Layout Receiver Unit Panel Descriptions Connecting And Operating The Extender For HDMI 1.3 Over CAT-6 Network Cable Wiring Diagram 10 Specifi cations 11 Warranty CONTENTS... -
Page 5: Introduction
Your complete satisfaction is very important to us. Gefen TV Gefen TV is a unique product line catering to the growing needs for innovative home theater solutions. We specialize in total integration for your home theater, while also focusing on going above and beyond customer expectations to ensure you get the most from your hardware. -
Page 6: Operation Notes
READ THESE NOTES BEFORE INSTALLING OR OPERATING THE EXTENDER FOR HDMI 1.3 OVER CAT-6 • The distance at which the Extender for HDMI 1.3 Over CAT-6 will carry a signal will vary depending on the source’s resolution and features. 20m (66 feet) -- HDMI 1.3 w/Deep Color/1080p, Dolby TrueHD or DTS- HD losless multi-channel audio 30m (99 feet) -- HDMI 1.2 at 1080p with Multichannel Audio 45m (148 feet) -- HDMI 1.2 at 720p or 1080i with Multichannel Audio... -
Page 7: Features
Features • Flexible extension of high-bandwidth HDMI 1.3 thanks to the performance and reliability of CAT-6a cable. • Audio and video are transmitted digitally over the CAT-6a cable for zero signal loss. • Single Link Range: 1080p/60, 12 bit color depth, 1920x1200. •... -
Page 8: Sender Unit Panel Layout
SENDER UNIT PANEL LAYOUT Front Panel Back Panel... -
Page 9: Sender Unit Panel Descriptions
SENDER UNIT PANEL DESCRIPTIONS HDMI Input Port Connect the HDMI source to this input port. Power Indicator LED This LED indicator will become active once the included 5V DC power adapter has bee properly connected between the sender unit and an open wall power socket. -
Page 10: Receiver Unit Panel Layout
RECEIVER UNIT PANEL LAYOUT Front Panel Back Panel... -
Page 11: Receiver Unit Panel Descriptions
RECEIVER UNIT PANEL DESCRIPTIONS 5V DC Power Input Port Connect the included 5V DC power supply to this input port. Power Indicator LED This LED indicator will become active once the included 5V DC power adapter has bee properly connected between the sender unit and an open wall power socket. -
Page 12: Connecting And Operating The
CONNECTING AND OPERATING THE EXTENDER FOR HDMI 1.3 OVER CAT-6 How to Connect the Extender for HDMI 1.3 Over CAT-6 Connect the HDMI source device to the Extender for HDMI 1.3 Over CAT-6 sender unit using the supplied HDMI cable. Connect one pair of CAT-6a* cables between the VIDEO and DDC ports on the sender and receiver. -
Page 13: Network Cable Wiring Diagram
Gefen has specifi cally engineered their products to work with the TIA/EIA-568-B specifi cation. Please adhere to the table below when fi eld terminating cable for use with Gefen products. Failure to do so may produce unexpected results and reduced performance. -
Page 14: Specifi Cations
SPECIFICATIONS Video Amplifi er Bandwidth ... 225 MHz Video Output ... 1080p/60, 12 bit color depth, 2k and 1920x1200 max. res Input DDC Signal ... 5 Volts p-p (TTL); Input Video Signal: 1.2 Volts p-p HDMI Connector ... Type A, 19 Pin Female Link Connector ...
