- Page 1 PCM-3291 USER MANUAL...
-
Page 2: Copyright Notice
PCM-3291 Copyright notice This document is copyrighted, 2000, by Advantech Co., Ltd. All rights are reserved. The original manufacturer reserves the right to make improvements to the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of the original manufacturer. -
Page 3: Table Of Contents
Table of Contents CHAPTER 1 GPS INTRODUCTION……………………..1 CHAPTER 2 PCM-3291 INTRODUCTION……..…………2 2.1 Module Dimensions…………………………….………….. 3 2.2 Placement………………………….………………………..4 2.3 Connector Define…………………………………………...4~6 2.4 Jump Setting………………………………………………...7 2.5 TMARK……………………………………………………..8 2.6 10KHz clock……………………………………………..…..8 2.7 How to Use GPS PCM-3291 module..………………….…..9~10 CHAPTER 3 D ata Format... -
Page 4: Chapter 1 Gps Introduction
PCM-3291 USER MENU 1.GPS INTRODUCTION GPS is fully operational and meets the criteria established in the 1960s for an optimum positioning system. The system provides accurate, continuous , worldwide , three-dimensional position and velocity information to users with the appropriate receiving equipment. -
Page 5: Chapter 2 Pcm-3291 Introduction
PCM-3291 2.GPS Application 2.1 Automotive applications. 2.2 Marine navigation applications. 2.3 Aviation applications. 2.4 Surveying. 2.5 Timing applications. 3. PCM-3291 INTRODUCTION 3.1 Top View Engine Board Table2 Table3 Table1... -
Page 6: Module Dimensions
PCM-3291 3.2 Module Dimensions 3250 ¡í250 ¡í125 3775 1050 3550 Unit:mil 16.5 28.6 Unit:mm 28.6 Unit:mm... -
Page 7: Placement
PCM-3291 3.3 Connector Define Table 1 PIN No PIN Name PIN No PIN Name PIN No PIN Name JP12 IRQ7 JP11 IRQ5 IRQ4 IRQ3 JP13 IRQ3 JP14 IRQ4 JP20 IRQ14 JP21 IRQ15 JP16 IRQ7 JP19 IRQ12 JP18 IRQ11 JP17 IRQ10... - Page 8 PCM-3291 PC/104 connectors (J4,J5) 1 2 ¡E¡E¡E¡E¡E31 32 Row B ¡E¡E¡E Row A 1 2 ¡E¡E¡E¡E¡E31 32 1 2 ¡E¡E¡E¡E¡E19 20 Row C ¡E¡E¡E Row D 1 2 ¡E¡E¡E¡E¡E19 20 PC/104 connectors Signal (J4) Signal (J5) Number Row A Row B...
- Page 9 PCM-3291 PC/104 connectors (cont.) Signal (J4) Signal (J5) Number Row A Row B Row C Row D SA13 DRQ1 SD14 MASTER* SA12 REFRESH* SD15 SA11 SYSCLK (KEY) ― ― SA10 IRQ7 ― ― IRQ6 ― ― IRQ5 ― ― IRQ4 ―...
-
Page 10: Jump Setting
PCM-3291 3.4 Jump Setting Serial Port Select Jump No Define Note COM1 Short :Enable ; Open :Disable COM2 Short :Enable ; Open :Disable COM3 Short :Enable ; Open :Disable COM4 Short :Enable ; Open :Disable Interrupt Port Select Jump No... -
Page 11: Tmark
PCM-3291 3.5 TMARK The TMARK pulse waveform is shown in Figure 1. This signal is a positive logic , buffered CMOS level output pulse that transitions from a logic “low” condition to a logic “high” at a 1 Hz rate. The TMARK output pulse rise time is typically less than 2 nanoseconds and the pulse duration is typically 25.6... -
Page 12: How To Use Gps Pcm-3291 Module
PC104 male PC104 standard connector main board GPS active antenna should be located at ourdoor without cover 2.The data input and output functions of PCM-3291 module are from the signal pins enhance of standard PC XT/AT. memory PC XT/AT structure... - Page 13 How to receive Binary Data Message, (9600 bps No parity 8 data bits 1 stop bit) C:>232 /C3 /b9600 /h Currently, PCM-3291 default at COM3,IRQ5 ,4800bps, No parity, 8 data bit, 1 stop bit. NMEA-0183 Data Messages Regarding to details, please refer the following Data interface specification.
