Summary of Contents for THOMSON Chipper Check II

  • Page 1 Chipper Check II User Manual...

  • Page 3: Table Of Contents

    Contents What is Chipper Check II (CCII)?............4 Chipper Check (CC) vs. Chipper Check II (CCII) ......4 Chipper Check II Interface ..............5 Connecting the Interface Box to the PC ..........7 CCII Install Software ................7 CCII Software Start-UP ..............10 Entering the Service Mode ..............

  • Page 4: What Is Chipper Check Ii (Ccii)

    What is Chipper Check II (CCII)? Chipper Check II is an advanced interface box that provides communication between the TV set being serviced and a personal computer. The interface converts the I C bus communication of the TV to serial communication used by the PC. With the Chipper Check software, the PC is able to control certain functions of the TV and perform some alignments.

  • Page 5: Chipper Check Ii Interface

    The new interface CCII and a modified CC incorporates the tri-level logic circuit and are backwards compatible. Chipper Check II Interface There are two types of interface boxes, the modified CF002 and CF003. A tri-level interface is the only one that is compatible with current chassis.
  • Page 6 The PS2 cable is connected between the interface box and adapter board. There are 3 adapter boards; two legacy adapters and one TECI1. The TECI1 board has many plugs and a switch. These plugs are for connecting different cables for the different chassis.

  • Page 7: Connecting The Interface Box To The Pc

    Connecting the Interface Box to the PC Using the parallel cable, locate the printer port on the PC and connect the 25-pin Din connector to it. The other end of the printer cable (Centrex connector) connects to the interface box. This is the only connection between the PC and the interface box.
  • Page 8 The next user input required screen asks for the “Destination Directory”. This is the directory in which you want the install program to store the Chipper Check files. It is recommended you accept the default location but is not necessary. After the destination is selected the installation process is started and the progress is displayed for reference only by the following graphic.
  • Page 9 Next is the program group selection. It is recommended you select the default location but not necessary. This will allow you to customize where you launch Chipper Check program from. The last window displayed will indicate that changes have been made to the computer registry and the PC will need to be rebooted before the changes will take effect.

  • Page 10: Ccii Software Start-Up

    CCII Software Start-UP To start the Chipper Check software, locate the start button on the task bar with the mouse pointer and click it. Then point to “Programs and locate the program group “Chipper Check”. Once in the program group of Chipper Check, locate the CCII program icon and click it. This will launch the Chipper Check software.
  • Page 11 More information about the software can be found in the Help files within Chipper Check Software. One screen found in all Chipper Check versions is the “Customer Information Screen”. This screen allows the technician to enter unique information to generate a file of the stored values in the main EEPROM of the instrument being serviced.
  • Page 12 eliminated by restoring the customer file for that set. The only requirement would be locating the correct file and restoring it to the customers set. The Model and Serial number fields are the best way to distinguish between instruments. Because of this, the model and serial fields need to be filled in to advance in the program.

  • Page 13: Entering The Service Mode

    Entering the Service Mode During normal operation, newer chassis (CTC195, 197, 203, 210, 211, MM101, 102, DTV306, 307, and LCOS) are continuously monitoring the I C bus for an acknowledgment from the EEPROM that resides in the Chipper Check interface box. When these newer chassis detect that the Chipper Check EEPROM has been connected to the I C bus, the chassis automatically go into the Service Mode.

  • Page 14: Ctc175, 176, 177, 186 & 187 Setup Procedure

    CTC175, 176, 177, 186 & 187 Setup Procedure Connecting the Chipper Check interface box to the chassis requires the following: 1. Interface Box 2. Parallel Printer Cable 3. Interface Cable 212118 4. Adapter Board 212121 The only function Chipper Check can perform on these chassis is initializing the EEPROM to factory settings.
  • Page 15 The diagram below shows how to connect the adapter to the chassis. Adapter board 212121, 7 jumper wires and an IC clip are used to connect the Chipper Check interface box to the EEPROM. You may connect leads directly to the EEPROM or use an IC clip. The IC clip shown in the diagram is a Pomona clip, Pomona part number 5108, available from most parts suppliers.

  • Page 16: Ctc178, 179, 188 & 189 Setup Procedures

    CTC178, 179, 188 & 189 Setup Procedures Connecting the Chipper Check interface box to the chassis requires the following: 1. Interface Box 2. Parallel Printer Cable 3. Interface Cable 212118 4. Adapter Board 212117 Things to Consider: Do not connect the instrument to the interface box until the instrument is on and in the service mode.
  • Page 17 1. Place the instrument in the service mode. a. With the instrument ON, press and hold the Menu button, press and release the power button then press and release the volume + button. Release the Menu button. The instrument should now display the ROM version and P: 00 V: 00. b.

  • Page 18: Dead Set

    Dead Set If the set will not start up, the EEPROM error code information can still be obtained by Chipper Check. The EEPROM may also be tested for proper hardware operation, but keep in mind that even if the EEPROM is OK, the software information contained in it may be corrupt. 1.

  • Page 19: Ctc195, 197 & 203 Setup Procedures

    CTC195, 197 & 203 Setup Procedures Connecting the Chipper Check interface box to the chassis requires the following: 1. Interface Box 2. Parallel Printer Cable 3. Interface Cable 212118 4. Adapter Board 212121 Things to Consider: Before putting the instrument into the service mode, preset the volume to a low level. Once the instrument is in the service mode, it is not possible to adjust the volume from the front panel or remote control.

  • Page 20: Dead Set

    4. Turn the computer on and start the Chipper Check software. DO NOT try to detect the chassis at this time! 5. Connect the interface cable to the 212121 adapter board. 6. Connect the adapter board to J13120 (CTC195/197), or J13101 (CTC203) on the chassis.

  • Page 21: Procedure

    When the instrument is connected to Chipper Check, the main microprocessor, is placed into the “slave” mode. It will not respond to any remote commands or front panel key presses. In order to exit this service mode, it is necessary to remove AC power from the instrument. f the instrument will not turn on but the standby supplies are functioning, then it is possible to read the error codes stored in the main EEPROM by using the “Dead Set”...

  • Page 22: Setup Dtv306, Dtv307 Chassis

    Setup DTV306, DTV307 Chassis Connecting the Chipper Check interface box to the chassis requires the following: 1. Interface Box 2. Parallel Printer Cable 3. Interface Cable 212118 4. TECI1 Adapter Things to Consider The DTV30x uses the TECI1 adapter. Make sure the switch is set to the position closest to the white 3-pin convergence connector for chassis communication.

  • Page 23: Teci1 Switch Position

    TECI1 Switch Position Chassis Communications (TECI1) Switch Position The switch on the TECI1 adapter needs to be in the correct position to communicate with the chassis. The other position is for convergence communication. To put the switch in the correct position, locate the three (3) pin connector next to the switch. Slide the switch to the position closest to the 3-pin connector.

  • Page 24: Procedure

    f the instrument will not turn on but the standby supplies are functioning, then it is possible to read the error codes stored in the main EEPROM by using the “Dead Set” procedure. Procedure: Chassis Communications (TECI1) Switch Position The switch on the TECI1 adapter needs to be in the correct position to communicate with the chassis.

  • Page 25: Dlp, Atc311, 321, 322, And 323 Setup

    DLP, ATC311, 321, 322, and 323 Setup Connecting the PC to the chassis requires the following: 1. Ethernet Crossover Cable and PC with Ethernet port Things to Consider: The DM2 / DM2CR / DM3 instruments communicate with Chipper Check software via the DM module Ethernet port.
  • Page 26 Next the user will be asked to select the Type of DM module in the TV. The DM module type can be found by accessing the Service Screen Menu under Information. The DM module type will be listed. The ATC311 uses the DM2 module. The ATC311M (DLPs) can be either a DM2 or DM2CR. The ATC321, ATC322 and ATC323 use the DM3 module.
  • Page 27 The DM2 module requires that the IP address of the computer be set to 169.254.36.171. If the computer’s settings are different then the following box will be displayed with instructions for changing the IP address. NOTE: If your computer is normally connected to a network write down the original IP address so that you can change the settings back when finished.

  • Page 28: Dead Set

    Dead Set 1. Remove AC power from the instrument by disconnecting the AC power cord. 2. Click on the “Dead set” button in the main screen. 3. Select the correct TV chassis for the instrument being tested and click on the OK button.

  • Page 29: Interface Box Diagnostic Tests

    Interface Box Diagnostic Tests Chipper Check II software incorporates several diagnostic tests to verify communication between the interface, adapter, and PC. To do all the tests requires the interface be connected to the PC and one adapter or cable / adapter combination be connected to the interface.
  • Page 30 indicates a problem with a data line, an output line, or a tri-state buffer. The problem could also originate in the parallel port or cable. The following is displayed when ‘Check data lines’ routine is run. This is the start of the routine asking if you are sure you want to test the data lines.
  • Page 31 Check clock lines and Check IM_Enable: The ‘Check clock lines’ test and the ‘Check IM_Enable’ tests require an extern jumper that routes the signals through the data lines back to the computer for analysis. The ‘Check data lines’ test should always be performed prior to running the ‘Check clock lines’...
  • Page 32 All 8 outputs high or low: There are 8 inputs, from the computer to the interface box, that control 3 tri-state buffers inside the box and the 5 outputs that are connected to the chassis. These 8 inputs can be toggled high or low. This test requires the technician to measure each output to make sure it is high or low based on the test being run.
  • Page 33 Options The options tool bar is used to set Chipper Check software options such as: · Initialize Port · Parallel Port · Serial · Initialize CC EEPROM · Usage Log · Clock Speed To use the diagnostic routines, the correct port settings need to be used. Under the options tool bar the important one is Parallel Port.

  • Page 34: Frequently Asked Questions

    Chipper Check up to the chassis. Where is the Chipper Check CCF002 upgrade kit? CCF002 is no longer available. You will need to buy Chipper Check II available on-line at Thomson Network. Chipper Check is not communicating with this TV has worked with other sets.
  • Page 35 What adapter do I need to hook Chipper Check to the following chassis? Chassis Diagram / Photo Used CTC17x, CTC18x, CTC195/197, CTC203, and ATC113 Used for CTC178/179, CTC188/198, CTC185 Used for CTC210/211, CTC203, DTV306/307, MM101/102, CTC195/197, ITC008, ITC222, ATC311, LCOS Used ATC311, ATC321, ATC322, and...

  • Page 36: Contact Phone Numbers

    Always have the consumer purchase receipt information, model number (including service suffix) and serial number of the instrument, and the Authorized Service Center number available before placing calls to Thomson. Most Use & Care or accessory issues can be resolved by the consumer online at www.RCA.com...
  • Page 38 TTCCIIUM...
