Step 5 • Install new door handle using original screws.
Install
handles
Step 6 • For shipping purposes, the top case trim is secured at
Adjust
grille • Loosen 2 screws on both sides of the case trim and
panel height
• Tighten all 4 screws.
IMPORTANT: Maintain 1-1/2" min. gap between top of door
and bottom of grille panel.
Step 7 • Secure the grille panel support to the back side of the
Secure 3/4"
panel to • Be sure the lip of the support is over the top of the
grille panel
support
24
the 84" installation height.
raise or lower trim to meet soffit height, from 83-1/2"
to 84-1/2".
3/4" custom panel with #6 screws.
wood panel.
Panel Support
Overlaps Top
ZKTR36LH/ZKTR36RH Trim Kit
3/4" Custom Panels
Top Case Trim
Raise To
Installation
Height
Screws
