- Page 1 OWNER’S INSTRUCTIONS AHR18MEB AHR24MEB WINDOW-TYPE ROOM AIR CONDITIONER ( Cool ) DB98-04270A(2)
-
Page 2: Safety Precautions
Safety Precautions The following safety precautions must be taken when using your air conditioner. 1 The unit must be plugged into an independent circuit. The air conditioner must be installed in accordance with national wiring regulations and safety regulations wherever applicable. 2 Some installation locations may require installation of a short circuit breaker or grounding. -
Page 3: Table Of Contents
Contents REPARING ONDITIONER Safety Precautions ..................Air Conditioning Unit - Main Parts and Control Panel ........Getting Started ....................PERATING ONDITIONER Heating Your Room ..................Airing Your Room .................... Switching the Air Conditioner Off ..............Adjusting the Air Flow Direction Horizontally ..........Adjusting the Air Flow Direction Vertically ............ -
Page 4: Air Conditioning Unit - Main Parts And Control Panel
Air Conditioning Unit - Main Parts and Control Panel ❄ The design and shape are subject to change according to the model. Inner air flow blades Air outlet (right/left orientation) Outer air flow blades (up/down orientation) Air inlet (Outside) Air inlet (Inside) Ventilation lever Air filter Power Cable... -
Page 5: Getting Started
Getting Started You have just purchased a window-type room air conditioner and it has been installed by your installation specialist. Your Owner’s Instructions contain much valuable information on using your air conditioner. Please take the time to read them as they will help you take full advantage of the unit’s features. The booklet is organized as follows. -
Page 6: Heating Your Room
Heating Your Room You must select the HEAT mode if you wish to higher the temperature in your room. You can also set the fan speed. Select the operating mode and fan speed. To Heat your room Set the operating mode with a... -
Page 7: Airing Your Room
Airing Your Room If the atmosphere in your room is stale, you can air it using the Fan feature and if necessary, evacuate the stale air outside. If you wish to evacuate stale air outside, push the ventilation lever on the front of the unit to the right and the open position ( Result: The air inside the room circulates and stale air is evacuated outside. -
Page 8: Adjusting The Air Flow Direction Horizontally
Adjusting the Air Flow Direction Horizontally Depending on the position of the unit in your room, you can adjust the orientation of the inner air flow blades on the right-hand side of the unit, thus increasing the efficiency of the air conditioner. Set the air flow blade swing switch to the ON position. -
Page 9: Operating Recommendation
Operating Recommendation Here are a few recommendations that you should follow when using your air conditioner. Topic Recommendation The air conditioner circulates warm air to heat your room; as a result, some time will be required after starting the air conditioner to warm the entire room. If necessary, set the air conditioner going a short time before you wish to use the room. -
Page 10: Cleaning Your Air Conditioner
Cleaning Your Air Conditioner To get the best possible use out of your air conditioner, you must clean it regularly by two weeks to remove the dust on the air filter. ☛ Before cleaning your air conditioner, ensure that it is switched off and unplugged from the wall socket. -
Page 11: Solving Common Problems
ON position Air the room. Odours are permeated in the room during air conditioning Technical Specifications Design and specifications are subject to change without notice. Model Power Supply AHR18MEB 220-240V~, 50Hz AHR24MEB... -
Page 12: Method Of Installation
Method of Installation Before installation, be sure to check the installation area for the air conditioner, and installation method of the drain hose. Checkpoints prior to installation Check the cabinet and front grille of the unit for any harmful defects such as scratches. - Page 13 Method of Installation Installation of the Drain Tube Rear Fix the drain tube as shown in the figure. Rubber cap Gasket Drain Tube Screws(2EA) Installation of the Drain Pan The procedure for installing the drain pan should be determined by the condition of the installing area.
- Page 14 THIS AIR CONDITIONER IS MANUFACTURED BY:...
