RollerTron 250™
Unpacking:
Thank you for purchasing the RollerTron 250™ by Ameri-
can DJ
. Every RollerTron 250™ has been thoroughly tested and has
®
been shipped in perfect operating condition. Carefully check the ship-
ping carton for damage that may have occurred during shipping. If the
carton appears to be damaged, carefully inspect your fixture for any
damage and be sure all equipment necessary to operate the unit has
arrived intact. In the event damage has been found or parts are miss-
ing, please contact our toll free customer support number for further
instructions. Please do not return this unit to your dealer without first
contacting customer support.
Introduction:
This unit is five channel DMX intelligent scanner with a
unique barrel mirror that may be easily converted to an intelligent color
changer by removing the mirror unit. This unit can also run as a stand
alone, sound-active unit, or in a Master/Slave configuration as either
a scanner or color changer. The RollerTron 250
built in programs and is best used in multiples of four. When used
as a stand alone unit or when used in multiples linked in a master/
slave configuration the optional Mini/C or Wireless/C controller may
be used. The optional controller will access different programs and
control a blackout function. For best results use fog or special effects
smoke to enhance the beams projections.
Customer Support:
American DJ
port line, to provide set up help and to answer any question should you
encounter problems during your set up or initial operation. You may
also visit us on the web at www.americandj.com for any comments or
suggestions. Service Hours are Monday through Friday 9:00 a.m. to
5:00 p.m. Pacific Standard Time.
Voice:
(800) 322-6337
Fax:
(323) 582-2941
E-mail:
support@americandj.com
To purchase parts online visit http://parts.americandj.com
Warning!
To prevent or reduce the risk of electrical shock or fire, do
not expose this unit to rain or moisture.
Caution!
There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures war-
ranty. In the unlikely event your unit may require service please contact
American DJ
.
®
American DJ
- www.americandj.com - RollerTron 250™ Instruction Manual Page 2
©
®
General Information
comes with three
provides a toll free customer sup-
®
