TileVision 22" Specifications

s p e c i f
Screen Size 26" (661 mm) Diagonal
Resolution WUXGA 1920 x 1080 Full HD
Type a-si TFT Colour Active Matrix LCD with an integrated LED Backlight System
Brightness 300 cd/m2
26" Display
Contrast Ratio 3,000:1
Viewing Angle 89°/89°/89°/89° – L/R/U/D
Colour Depth 16.7 M colours (RGB 8 bits)
Response Time 12 ms
AC/DC Adaptor 4M Lead Input 100–240 VAC 50/60 Hz, Output 24 VDC/6.25 A
Power Consumption 70 W max
Standby Less than 1 watt
External Dimensions (W x H x D) 685 mm x 450 mm x 75 mm
Cutout/Recess Required 703 mm x 455 mm and 75 mm
Dimensions/
Weight Mirrored Acrylic Surround Overall size 728 mm x 494 mm (1.5 mm deep, 30 mm wide)
Total Weight including Back Box 19.5 Kg
Screen Size 21.5" (547 mm) Diagonal
Resolution 1920 x 1080 Full HD
Type a-si TFT LCD Module with W-LED Backlight System
Brightness 250 cd/m2
22" Display
Contrast Ratio 5,000:1
Viewing Angle 89°/89°/89°/89° – L/R/U/D
Colour Depth 16.7 M colours (RGB 8 bits)
Response Time 16 ms
AC/DC Adaptor 4M Lead Input 100–240 VAC 50/60 Hz, Output 24 VDC/6.25 A
Consumption 65 W max
Power
Standby Less than 1 watt
External Dimensions (W x H x D) 572 mm x 376 mm x 75 mm
Cutout/Recess Required 590 mm x 381 mm and 75 mm
Dimensions/
Weight Mirrored Acrylic Surround Overall size 616 mm x 420 mm (1.5 mm deep, 30 mm wide)
Total Weight including Back Box 16 Kg
Digital TV DVB-T (MHEG-5) MPEG-2, H.264/MPEG-4 : DVB-C
Analogue TV PAL-BG, I, DK/SECAM-BG, DK, L : CADTV
Tuner/
Reception Channels DTV 600, ATV 100, Satellite HD 3000
Satellite HD S2 Compliant HD
Output 8 W + 8 W @ 8Ω
Audio
Features Surround Sound, SRS TruSurround XT, Treble and Bass Controls
Satellite -S2 F Connector
Aerial Input 75 ohm coaxial
HDMI 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Component (Y,Pb,Pr) 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
SCART Full Scart
PC RGB (D-sub) Format Up to 1920 x 1080 @ 60HZ
Connectivity PC RGB (D-sub) Colour 16 Bit, 24 Bit, 32 Bit
Composite (CVBS) 1.0Vp-p +/-5%
Common Interface Port Additional channels via CAM/Smartcard
L+R Audio Input For Component and Composite (CVBS) Audio Input
PC Audio Input 1 x Stereo Jack Socket for PC Audio Input
Headphone Out Headphone
Speaker Clip Terminals LEFT +/- and RIGHT +/-
RS-232 Receives RS232 Control Codes from Home Automation/Hotel Systems
Sky™ IR Link Control of a Sky Box via the TileVision® IR receiver and Aerial cable
Control RJ12 Command code in and out
3.5mm IR In For connection to external IR receiver
3.5mm IR Out For connection to external IR emitter
Loudspeaker 6.5" Single Stereo, Flush Mount, 8 ohm, Water Resistant
Speaker External Dimensions 240 mm Ø x 95 mm deep
Loudspeaker
Speaker Cutout Required 208 mm Ø
Speaker Depth 79 mm
Splashproof Remote Control Universal Learning, Full Function, complete with battery
Remote Control Holder Wall/Tile mount, clear plastic with gel adhesive strip
Standard Remote Control Complete with batteries
Stainless Steel Back Box Adjustable brackets to allow precise installation flush with tiles/wall
Mains Power Cord UK and Europe
Accessories
AC/DC Adaptor Complete with detachable 4 meter cord
AC / DC Adaptor Dimensions 170mm x 65mm x 38mm depth (excluding connecting cables)
Speaker Cable 4.5 meter, 4 core, colour coded
Installation and Operating
Book
Instructions
Český, Dansk, Deutsch, English, Español, Ελληνικά, Français, Hrvatski, Italiano, Magyar, Nederlands,
Multi- Language OSD
Norsk, Polski, Portugês, Pyccкий, Româneste, Slovenščina, Srpski, Suomi, Svenska, Български, Slovak.
Auto Tuning DTV and ATV
Manual Tune DTV and ATV
Programme Edit Allows programmes to be deleted, skipped, or selected as favourites
Favourites List Favourite channels can be stored and accessed in a favourites list
Convenience EPG 8 day Electronic Programme Guide
Features Picture Mode Standard, Mild, Dynamic, User
Sound Mode Standard, Music, Movie, Sports, User
Aspect Ratio Control (ARC) Auto, Zoom 1, Zoom 2, 16:9, 4:3
AVL Auto Volume Leveller
Subtitles Switchable, as available from the broadcaster
Digital Text MHEG 5 – Interactive text via the red button
Analogue Teletext TOP/FLOF
Volume Limit Set maximum volume limit
Input Selection Selects which Inputs will be available on the Input Menu
Hotel Mode
Input Priority Selects which Input will be the default when the TileVision® is turned on
Menu Button Disabled Menu button can be disabled to prevent access to menus by hotel guest
TileVision ® is designed and manufactured by Porter Lancastrian Limited – www.tilevision.tv · Design and specifications are subject to change without notice · All TileVision
i c a t i o n
® pictures are simulated. E. & O.E.
s
22" and 26" waterproof LCD TVs
13/04/2012
