Washing Machine

WF 8101-A

THE BEAUTY OF SIMPLICITY

USER MANUAL

Table of Contents

Need help?

Do you have a question about the WF 8101-A and is the answer not in the manual?

Questions and answers

Summary of Contents for EF WF 8101-A

Page 1 Washing Machine WF 8101-A THE BEAUTY OF SIMPLICITY USER MANUAL...
Page 2: Important Safety Instructions
1 Important safety instructions • Follow the instructions on the textile tags and on This section contains safety instructions that will the detergent package. help protect from risk of personal injury or property • The product must be unplugged during damage. Failure to follow these instructions shall installation, maintenance, cleaning and repairing void any warranty. procedures.
Page 3: Removing Packaging Reinforcement
• Total weight of the washing machine and the laundry. dryer -with full load- when they are placed 1. Connect the special hoses supplied with the on top of each other reaches to approx. 180 product to the water inlets on the product. Red kilograms. Place the product on a solid and flat hose (left) (max. 90 ºC) is for hot water inlet, floor that has sufficient load carrying capacity! blue hose (right) (max. 25 ºC) is for cold water • Do not place the product on the power cable. inlet. • Do not install the product at places where temperature may fall below 0ºC. • Place the product at least 1 cm away from the edges of other furniture.
Page 4: Electrical Connection
Do not use any tools to loosen the lock nuts. Otherwise, they will get damaged. Electrical connection Connect the product to a grounded outlet protected by a fuse complying with the values in the "Technical specifications" table. Our company shall not be liable for any damages that will arise when the product is used without grounding in accordance with the local regulations. • Connection must comply with national regulations. • To prevent flowing of dirty water back into the • Power cable plug must be within easy reach after machine and to allow for easy discharge, do installation.
Page 5: Transportation Of The Product
Packaging materials of the product are damage the product or cause noise problem. manufactured from recyclable materials. Dispose of • Put small size clothes such as infant's socks and them properly and sort in accordance with recycled nylon stockings in a laundry bag or pillow case. waste instructions. Do not dispose of them with • Place curtains in without compressing them. normal domestic waste. Remove curtain attachment items. Transportation of the product • Fasten zippers, sew loose buttons and mend rips and tears. Unplug the product before transporting it. Remove • Wash “machine washable” or “hand washable” water drain and water supply connections. Drain labeled products only with an appropriate the remaining water in the product completely;...
Page 6: Using Detergent And Softener
Using detergent and softener foam, poor rinsing, ﬁnancial savings and ﬁnally, environmental protection. Detergent Drawer • Use lesser detergent for small amounts or lightly The detergent drawer is composed of three soiled clothes. compartments: • Use concentrated detergents in the - (I) for prewash recommended dosage.
Page 7 laundry, close to the lower part of the drum in future washings. Use the tablet or gel detergent without selecting the prewash function. Using starch • Add liquid starch, powder starch or the dyestuff into the softener compartment as instructed on the package. • Do not use softener and starch together in a washing cycle. • Wipe the inside of the machine with a damp and clean cloth after using starch. Using bleaches • Select a programme with prewash and add the bleaching agent at the beginning of...
Page 8: Operating The Product
4 Operating the product Control panel 1 - Spin Speed Adjustment button 5 - On / Off button 2 - Display 6 - Delayed Start buttons (+ / -) 3 - Temperature Adjustment button 7 - Auxiliary Function buttons 4 - Programme Selection knob 8 - Start / Pause / Cancel button Display symbols Preparing the machine Make sure that the hoses are connected tightly. Plug in your machine.
Page 9: Main Programmes
• Eco 40 Always select the lowest required temperature. Use this programme to wash your laundry for which Higher temperature means higher power you cannot use Cottons 60 °C programme. It gives consumption. the same result with the Cottons 60 °C programme For further programme details, see "Programme by washing for a longer time at 40 °C, thus enabling and consumption table".
Page 10: Spin Speed Selection
appears on the temperature indicator. To decrease the temperature, press the Temperature Adjustment button. Temperature decreases with increments of 10° and finally, “-” symbol indicating the cold wash option appears on the display. If you scroll to cold wash option and press Temperature Adjustment button again, the recommended temperature for the selected programme appears on the display. Press the Temperature Adjustment button again to decrease the temperature. Economy symbol Indicates the programmes and temperatures that provide energy savings. Economy symbol can not be selected in Intensive and Hygiene programmes since washing is performed in long times and...
Page 11: Programme And Consumption Table
Programme and consumption table Auxiliary functions Temperature Program (°C) Selectable temperature range℃ Cottons 82 2.70 1200 • • • • • 90-Cold Cottons 80 1.80 1200 • • • • • 90-Cold Cottons 80 1.00 1200 • • • • •...
Page 12: Auxiliary Function Selection
Auxiliary function selection may use rinse hold function to keep your laundry in the final rinsing water in order to prevent them Select the desired auxiliary functions before starting from getting wrinkled when there is no water in the the programme. Furthermore, you may also select machine. Press Start / Pause / Cancel button after or cancel auxiliary functions that are suitable to the this process if you want to drain the water without...
Page 13: Changing The Selections After Programme Has Started
Changing the selections after “:” sign in the middle of the delayed start time on the display starts flashing. programme has started Canceling the Delayed Start function Switching the machine to pause mode If you want to cancel the delayed start countdown Press the Start / Pause / Cancel button to switch the and start the programme immediately: machine to pause mode. Pause symbol appears on Press Start / Pause / Cancel button. “:” sign in the the display indicating that the machine is paused.
Page 14: Maintenance And Cleaning
avoid touching of the residues in the drawer with door opening, then turn the Programme your skin when cleaning. Insert the drawer back Selection knob to Pump+Spin programme into its place after cleaning and make sure that it is and discharge the water in the machine. seated well.
Page 15 If the filter cap is one piece, pull the cap from both sides at the top to open. You can remove the filter cover by slightly pushing downwards with a thin plastic tipped tool, through the gap above the filter cover. Do not use metal tipped tools to remove the cover. Some of our products have emergency draining hose and some does not have. Follow the steps below to discharge the water.
Page 16: Technical Specifications
6 Technical speciﬁcations Models WA 8101-A Maximum dry laundry capacity (kg) Height (cm) Width (cm) Depth (cm) 56.5 Net weight (±4 kg.) Electrical input (V/Hz) 220-240V~/50Hz Total current (A) Total power (W) 2000-2350W Spin speed (rpm max.) 1200 Stand-by mode power(W) 1.00 Off-mode power(W) 0.20...
Page 17: Troubleshooting
7 Troubleshooting Programme cannot be started or selected. • Washing machine has switched to self protection mode due to a supply problem (line voltage, water pressure, etc.). >>> Press and hold Start / Pause button for 3 seconds to reset the machine to factory settings. (See "Canceling the programme") Water in the machine. • Some water might have remained in the product due to the quality control processes in the production. >>> This is not a failure; water is not harmful to the machine. Machine vibrates or makes noise.
Page 18 Casa (S) Pte Ltd. 15 Kian Teck Crescent, Singapore 628884. Service Centre Hotline: 62680077. Fax: 68980510. Email: service@casa.com.sg...
