Installation Manual
Hickory Rotisseries
Models: N/5.5 E
Machine Type
Total Power Rating
Elements / Spits
Electrical Rating
Temperature Range
Timer
Delivery Date:
4900 Westside Avenue, North Bergen, New Jersey 07047
Tel: [201] 223-0050 Fax: [201] 223-0950
Hickory Industries, Inc.
N / 5. 5 E
6000 or 8400 Watts
4 Elements with 5 Spits
208/240 V or 380/410 V
200ºF - 550ºF
Manual or Fully Automatic
Final Inspection:
USA
N/5.5E Installation 8/5/97
Page 1 of 15
Advertisement
Table of Contents
Summary of Contents for Hickory 5.5 E
- Page 1 Hickory Industries, Inc. Installation Manual Hickory Rotisseries Models: N/5.5 E Machine Type N / 5. 5 E Total Power Rating 6000 or 8400 Watts Elements / Spits 4 Elements with 5 Spits Electrical Rating 208/240 V or 380/410 V Temperature Range 200ºF - 550ºF...
-
Page 2: Table Of Contents
Hickory Industries, Inc. Table of Contents 1.0 Installation Instructions General Information Description of the Data Plate Machine Drawings and Dimensions Electrical Conversion and Adjustment Instructions Cooking Cycle Maintenance, Response to Technical Problems 1.6.1 Reasons for Problems and Solutions Spit Drive Mechanism N/5.5E Parts List N/5.5E Exploded View 4900 Westside Avenue, North Bergen, New Jersey 07047... -
Page 3: Installation Instructions
Hickory Industries, Inc. 1.0 Installation Instructions When installing these units, it is important to comply with the most recently established rules and regulations as deemed pertinent by the local and national electrical, ventilation, sanitation, and fire codes. These units are classified by Underwriters Laboratories, Inc. -
Page 4: General Information
It is recommended that a repair and maintenance contract be signed with the manufacturer's agent, distributor, or service agency. Description of the Data Plate HICKORY INDUSTRIES, INC. HICKORY INDUSTRIES, INC. NORTH BERGEN, NJ 07047 NORTH BERGEN, NJ 07047 N/5.5 E N/5.5 E MODEL: SERIAL NO. MODEL: SERIAL NO. 110 - 120... - Page 5 Hickory Industries, Inc. HICKORY INDUSTRIES, INC. HICKORY INDUSTRIES, INC. NORTH BERGEN, NJ 07047 NORTH BERGEN, NJ 07047 N/5.5 E N/5.5 E MODEL: SERIAL NO. MODEL: SERIAL NO. 208 - 220 110 - 120 MOTOR: VOLTS CYCLE AC CURRENT MOTOR: VOLTS...
-
Page 6: Machine Drawings And Dimensions
Machine Drawings and Dimensions The following drawing of the Front View, Side View, and Top View indicate where the dimensions are taken and should be used to plan the installation of the units. N/ 5.5 E Top View Front View Right Side View N/ 5.5 E... -
Page 7: Electrical Conversion And Adjustment Instructions
Hickory Industries, Inc. Electrical Conversion and Adjustment Instructions Before converting or adjusting the machine to another type of electricity, it is imperative that electrical power to the machines should also be turned off. When converting, make sure that the proper electrical diagram is followed and that the motor and timer match the connected single phase voltage! Cooking Cycle In order to start the cooking cycle, the elements must be powered. -
Page 8: Reasons For Problems And Solutions
Hickory Industries, Inc. 1.6.1 Reasons for Problems and Solutions Problem Cause Solution Unit does not heat. Rotisserie not "on". Make sure that the TEMPERATURE switch is on. Thermostat must be set (i.e. 550°F). The cooking timer must be operational (cook cycle). A red LED on the TEMPERATURE switch indicates that the contactor is supplying power to the heating... -
Page 9: Spit Drive Mechanism
Hickory Industries, Inc. Spit Drive Mechanism This unit is equipped with a planetary motion spit drive system. This means that each spit is turning upon its axis at the same time that they turn about the center shaft. When the motor switch is turned to on, the disks and the spits will begin to turn. -
Page 10: N/5.5E Parts List
Hickory Industries, Inc. N/5.5E Parts List Item Qty. Description Material Length Size Manufacturer Shaft 5/8 (Removable Drums - Center) 5/8" Hickory Shaft Locking Slide Hickory Drive Bearing Holder (Left - with brass bearing) Steel (Chromed) Hickory Drive Bearing Holder (Right - with teflon bearing) Steel (Chromed) Hickory Brass Shaft Bearing Brass... - Page 11 Hickory Industries, Inc. N/5.5E Parts List (Contd.) Item Qty. Description Material Length Size Manufacturer Electrical Grounding Cap Hickory Electrical Wire Janor Wire Buchanan Contact Section 824 Buchanan Buchanan Contact Section 830 Buchanan Relay (Contactor) 3 Pole 220V Capacitor Element Holder Hickory Element Porcelain Insulator Hickory...
-
Page 12: N/5.5E Exploded View
Hickory Industries, Inc. N/5.5E Exploded View 4900 Westside Avenue, North Bergen, New Jersey 07047 N/5.5E Installation 8/5/97 Tel: [201] 223-0050 Fax: [201] 223-0950 Page 12 of 15... - Page 13 Hickory Industries, Inc. Glass Replacement on the 5.5E & 10.10E Machines Make sure that the handle and all associated hardware Make sure that the handle and all associated hardware is available at the site or order the mounting hardware is available at the site or order the mounting kit from from Hickory.
- Page 14 Hickory Industries, Inc. Replacing the front glass DO NOT TIGHTEN. This will ensure that you have Insert the screw on to the glass (use hi heat Loc-tite). enough play to move the glass around without As a hint, start with the middle screw it will give you bumping the glass.
- Page 15 Hickory Industries, Inc. If the glass is not evenly spaced, adjust the glass until its evenly spaced. CAUTION: If the screws are not snug enough, when lowering the glass door, the glass my hit the screws and chip the glass. CAUTION: When tightening the screws, if the glass shifts down, the glass door will be too close to the roof of the machine when the glass door is shut.
