Hitachi CP-X3015WN Quick Manual

CP-X3015WN LCD Projector
Accessories and Lenses
Supplied Remote control, power cord, computer
Accessories cable, network and wireless software,
user's manuals, safety manual
Optional USBWL11N USB wireless adapter,
Accessories TB-1 wireless USB tablet,
LCDSC2000 soft sided case
Optional Lenses NA
Replacement Parts
Lamp CPX2015WNLAMP (DT01371) with filter
Remote Control HL02881
Filter MU06481
Projection Throw Chart
Screen Size 4:3
Diagonal Width
30 24
60 48
80 64
100 80
150 120
200 160
300 240
Throw Ratio: 1.5 - 1.8 : 1 (distance : width)
Screen size and throw distance are measured in inches.
HI0138-11/12 WEB
All specifications subject to change without notice.
3LCD and the 3LCD logo are registered trademarks of the Seiko Epson Corporation.
©2012 Hitachi America, Ltd. All Rights Reserved.
Hitachi America, Ltd.
900 Hitachi Way, Chula Vista, CA 91914
Toll Free: 1.800.HITACHI Email: dmd.info@hal.hitachi.com
•
Web: hitachi-america.us/projectors
Specifications
Throw Distance
Min Max
32 39
68 82
92 111
116 140
175 211
235 283
354 426
* Actual lamp life will vary by individual lamp and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
lamp life specified are not guaranteed and do not constitute part of the product or lamp warranty. Lamp brightness decreases over time.
** Actual filter life will vary by individual filter and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
filter life specified are not guaranteed and do not constitute part of the product warranty.
Projection Technology 3LCD, 3 chip technology
Resolution
XGA - 1024 x 768
White Light Output 3,200 ANSI lumens
Color Light Output 3,200 ANSI lumens
Colors 16.7 million colors
Aspect Ratio Native 4:3 and 16:9 / 16:10 compatible
Contrast Ratio 3000 : 1 (using active IRIS)
Throw Ratio 1.5 - 1.8 : 1
(distance : width)
Lens
F = 1.9 – 2.3 mm, x 1.2 manual zoom
Lamp Wattage 215W
Expected Lamp Life* Approximately 5,000 hours (standard mode)
6,000 hours (Eco mode)
Expected Filter Life** Approximately 5,000 hours
Speaker Output
16W (8W x 2)
Acoustic Noise Level 36 dB (29 dB in Eco mode)
Keystone +/- 30º vertical only
Computer
VGA, XGA, WXGA, WXGA+, SVGA, SXGA+,
UXGA (compressed), MAC 16"
H-Sync 31.5 kHz - 106 kHz
V-Sync 56 Hz - 120 Hz
Composite Video NTSC, NTSC4.43, PAL, PAL-M, -N, SECAM
Component Video
480i, 480p, 576i, 720p, 1080i, 1080p
HDMI 480i, 480p, 576i, 720p, 1080i, 1080p,
Computer signal TMDS Clock 27 MHz - 150 MHz
Digital Input HDMI x 1 (HDCP compliant)
Computer Input 1 15-pin mini D-sub x 1
Computer Input 2 15-pin mini D-sub x 1
Computer Monitor Output 15-pin mini D-sub x 1
Video Input
S-Video Mini DIN 4-pin x 1
Composite Video RCA jack x 1
Component Video 15-pin mini D-sub x 2 (shared with computer in 1/2)
Audio Input
3.5 mm stereo mini jack x 2, RCA jack (L/R) x 1,
MIC-in 3.5 mm mini jack x 1
Audio Output
RCA jack (L/R) x 1
Network LAN Wired RJ-45 port (10 base-T / 100 base-TX)
Network LAN Wireless USB-A, IEEE802.11 b/g/n - optional wireless adapter required
USB
Type A x 2 (PC-less presentation, wireless adapter, TB-1)
Type B x 1 (USB display or mouse control)
Control Terminals 9-pin D-sub x 1 (RS-232 control)
Power Supply AC100-120V / AC220-240V, 50/60Hz
Power Consumption 310W
Operating Temperature 40ºF - 95ºF (5ºC - 35ºC)
Dimensions (W x D x H) 12.5" x 11.3" x 3.9" (excl. protruding parts)
Weight approx. 7.9 lbs.
Approvals
UL 60950-1 / cUL FCC Part 15 subpart B class B
Warranty 3 year limited parts and labor
Extended Service Contract available (additional cost)
CP-X3015WN
Classroom and
Conference Room
Series
