Panasonic AJ-D215 Specification Sheet

Broadcast Digital Quality for Professional Use
Panasonic's compact, lightweight
DVCPRO digital VCRs offer
extremely high picture quality. In
addition to the broadcast series,
which continues to win high
acclaim from broadcasters
worldwide, the line-up has now
been expanded to include a low-
cost professional series.
Another reason why DVCPRO
is quickly becoming the
standard in image production.
OPTIONAL ACCESSORIES
AG-MH800 Microphone Holder for WM-L30
WCV-65
AJ-YAD210P DVCPRO Termianl IEEE1394 I/F
Board ACM-12B
AJ-DTC2P DVCPRO Terminal Cable (2 m)
AJ-DTC4P DVCPRO Terminal Cable (4.5 m)
Battery Holder
AG-YA800 5" EVF Adaptor for WV-VF65B
Anton/Bauer Gold
SHAN-TM700 Tripod Adaptor
Mount Plate
AJ-B75 AC Adaptor
(Supplied)
T18!6.7BRM4 1/3" Bayonet Type Lens — Fujinon
T14!5.5BRM4 1/3" Bayonet Type Lens — Fujinon AU-M402H
T12!3.8BRM4 1/3" Bayonet Type Lens — Fujinon
SHAN-B220
SPECIFICATIONS
GENERAL View Finder
Power Requirement: DC12V (10.5V to 17V) CRT:
Horizontal Resolution:
Battery: Anton/Bauer, NP-1, BP-90,
AU-BP402, AU-BP220 Control:
DC In: XLR 4-pin (Male)
Power Consumption: Less than 16W (including 1.5" viewfinder)
VCR SECTION
Operating Temperature: 0°C to 40°C (32°F to 104°F)
General
Storage Temperature: –20°C to 60°C (4°F to 140°F)
Format:
Operating Humidity: Less than 80%
Recording Track:
Weight: Approx. 5.9 kg (13.0 lbs.)
(including lens, V.F., tape, and battery pack)
Continuous Recording Time: Approx. 120 min. with ABT14,
Anton/Bauer Trimpac Battery
Tape Speed:
CAMERA SECTION Tape:
Cassette Size:
Camera
Pick-up Device: Interline Transfer 1/3" CCD Image Sensor Recording/Playback Time: 184 min. with AJ-5P92L cassette
with On-Chip Lens (!3) FF/REW Time:
Digital Quantization: 8 bits A/D Video*
Digital Signal Processing: 13.5 MHz/27 MHz Sampling Frequency:
Sensitivity: 2000 lux with F5.6 ±1/2, 3200K
Minimum Illumination: 5 lux (F1.4, +18dB gain) Quantization:
Shutter Speed: 1/100 to 1/8000-sec. Error Correction:
S/N Ratio: 60dB (typical) Bandwidth:
Horizontal Resolution: 500 TV lines (Center) S/N Ratio:
Y/C Delay:
Vertical Resolution: 400 TV lines
Registration Error: Less than 0.03% (all zones, without lens) Audio*
Gain: 0/+6/+12dB, 0/+9/+18dB Sampling Frequency:
Optical System: F1.4 prism system Quantization:
Frequency Response:
ND Filter: 1/16 Manual on/off by slide switch
Distortion:
Lens Mount: 1/3" bayonet mount (conversion lens)
PANASONIC BROADCAST & DIGITAL SYSTEMS COMPANY
DIVISION OF MATSUSHITA ELECTRIC CORPORATION OF AMERICA
Executive Office: 3330 Cahuenga Blvd W., Los Angeles, CA 90068
(323)436-3500
EASTERN ZONE: One Panasonic Way 4E-7, Secaucus, NJ 07094 (201)348-7621
Mid-Atlantic/New England: One Panasonic Way 4E-7, Secaucus, NJ 07094 (201)348-7621
Southeast Region: 1225 Northbrook Parkway, Ste 1-160 Suwanee, GA 30024
(770)338-6845
Central Region: 1707 N Randall Road E1-C-1, Elgin, IL 60123 (847)468-5200
WESTERN ZONE: 3330 Cahuenga Blvd W., Los Angeles, CA 90068 (323)436-3500
Dallas Region: 6226 Abington Way, Houston, TX 77008 (713)802-2726
No. CA/Northwest Region: 5870 Stoneridge, #3, Pleasanton, CA 94588 (925)416-5102
Government Marketing Department: 52 West GudeDrive, Rockville, MD 20850 (301)738-3840
SP-AJD215P1
DVCPRO Large Video Cassettes
Wide Converter for T14!5.5BRM4
Lens — Fujinon
Model No. Time
Lens Adaptor for 1/2" Lens
AJ-5P92L* 184 min.
— Fujinon
AJ-P126L 126 min.
Battery Pack Battery Charger AJ-P94L 94 min.
AJ-P66L 66 min.
Anton/Bauer ABDT14,
Anton/Bauer
AJ-P34L 34 min.
ABT14, ABDP14,
ABC800H
ABP14
AJ-CL12L
AU-BP402
* For AJ-5P92L cassette tapes,use a VCR supporting
AG-B425
DVCPRO (25Mbps) 184 minutes tapes.
AU-BP220
1.5" monochrome Crosstalk: Less than –65dB
600 TV lines (Center) (at 1kHz, between 2 channels)
VR: Bright, Contrast, Peaking Wow & Flutter: Below measurable limit
SW: Tally, Zebra, Character Headroom: 20dB
AGC Level: Standard, +8dB
Signal Inputs
Front Mic In: XLR 3-pin, balanced, –60dBu, 3k
DVCPRO 1/4" Digital compressed recording
–60/–50/–40dBu selectable
Digital Video
Audio In (CH1/CH2): MIC/LINE Switchable with internal DIP SW
Digital Audio: 2CH
MIC: –60/–50/–40dBu selectable, 10k
Sub-Code
LINE: –6/0/+4dBu selectable, 10k
CTL: 1 Track
Signal Outputs
33.820 mm/s
Video Out: BNC!1, 1.0Vp-p, 75
1/4-inch Metal Particle Tape
S-VIDEO Out: 4-pin!1
AJ-5P92L: 125!78!14.6 mm
Y: 1.0Vp-p, 75
C: 0.286Vp-p, 75
Approx. 8 min. using AJ-5P92L
Audio Out (CH1/CH2): RCA (CH1/CH2), –6dBu unbalanced,
low impedance
Y: 13.5 MHz
Headphones: Stereo mini jack
C (P /P ): 3.375 MHz
B R
Others
8 bits/sample
DVCPRO I/F (Option): IEEE1394 Standard (6-pin)
Reed-Solomon Code
Lens: 12-pin
Y: 0 to 5.75 MHz +1.0/–3.0dB
DC IN: XLR 4-pin (DC 12V)
55dB
20 ns or less
* The specifications given above were measured by playing back
48kHz tapes recorded by this unit on standard DVCPRO VCRs.
16 bits/sample
Weight and dimensions shown are approximate.
20Hz to 20kHz, +1.0dB/–1.5dB
Specifications subject to change without notice.
Less than 0.2% (at 1kHz, reference level)
These products may be subject to export regulations.
PANASONIC CANADA INC.
5770 Ambler Drive, Mississauga, Ontario L4W 2T3
(905)238-2115
PANASONIC SALES COMPANY
DIVISION OF MATSUSHITA ELECTRIC OF
PUERTO RICO, INC.
San Gabriel Industrial Park, 65th Infantry Ave., KM9.5
Carolina, Puerto Rico 00630 (809)750-4300
MATSUSHITA ELECTRIC INDUSTRIAL CO., LTD.
VIDEO SYSTEMS DIVISION
2-15 Matsuba-cho, Kadoma, Osaka 571-8503 Japan
Tel. 81-6-6901-1161 Fax. 81-6-6908-5969
VSD-6110 [12288.1] (30K)40K902FF-1
Length
377 m
259 m
194 m
137 m
72 m
Cleaning Tape
ISO9001 / BS5750 : PART 1
FM No. 28369
Printed in Japan
AJ-
1/3" IT-3CCD DVCPRO Camera/Recorder
(NTSC: 525)
