Introduction
The DP SATA 6Gb/s 2-Port PCIe adds 2 eSATA
6Gb/s to PCIe-equipped computers.
Features and Benefits
•
Adds 2 internal SATA 6Gb/s channels to
your PCIe system
•
Compliant with Serial ATA specification,
Revision 3.0
•
Supports ATA/ATAPI-7 specification
•
Installs in standard height or low profile
chassis with the included brackets

Package Contents

•
DP eSATA 6Gb/s 2-Port PCIe adapter
•
Spare low profile bracket
•
Driver CD and installation guide
04-0744B
DP eSATA 6Gb/s
2-Port PCIe

Installation Guide

1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DP eSATA 6Gb/s 2-Port PCIe and is the answer not in the manual?

Questions and answers

Summary of Contents for SIIG DP eSATA 6Gb/s 2-Port PCIe

  • Page 1: Installation Guide

    Revision 3.0 • Supports ATA/ATAPI-7 specification • Installs in standard height or low profile chassis with the included brackets Package Contents • DP eSATA 6Gb/s 2-Port PCIe adapter • Spare low profile bracket • Driver CD and installation guide 04-0744B...

  • Page 2: System Requirements

    Vista (32-/64-bit) / XP (32-/64-bit) / Server 2003 & 2008 (32/64-bit) / Server 2008 R2 / Server 2012 • Mac OS X v10.6.x to v10.8.x (Intel-based ® Apple computers only) Layout Hard Disk LED Pins (connect horizontally) eSATA connectors Figure 1: DP eSATA 6Gb/s 2-Port PCIe...

  • Page 3: Hardware Installation

    Hardware Installation For low profile systems, install the spare low profile bracket now. General instructions for installing the card are provided below. Since the design of computer cases and motherboards vary, refer to your computer’s reference manual for further information, if needed. Static Electricity Discharge may permanently damage your system.

  • Page 4: Windows Installation

    Install the board and follow Microsoft procedures to install Windows accordingly. Reboot Windows. The DP eSATA 6Gb/s 2- Port PCIe is ready for use. For Existing Installation Install the board and boot up Windows. The DP eSATA 6Gb/s 2-Port PCIe is ready for use.
  • Page 5 Windows 7 (32-/64-bit) / Server 2008 R2 For New Installation Install the board and follow Microsoft procedures to install Windows accordingly. After the installation completes, insert the driver CD, click Start button, in the Search programs and files box, type D:\setup.exe, press Enter.
  • Page 6 At the User Account Control window, click Yes. Skip this step if not prompted. Click Next. Select I accept the terms of the license agreement, then click Next. Click Finish. Click Yes to complete the installation. Windows Vista (32-/64-bit) / Server 2008 (32-/64-bit) For New Installation Install the board and follow Microsoft...
  • Page 7 For Existing Installation Install the board and boot up Windows. At the Found New Hardware window, click Cancel. Insert the driver CD, click the Start button, in the Start Search box, type D:\setup.exe, press Enter. (Change D: to match your CD-ROM drive letter) At the User Account Control window, click Allow.
  • Page 8 Install the board and follow Microsoft procedures to install Windows accordingly. At the Windows Setup screen, press F6 to install the RAID driver. When prompted, press S to specify the location of the driver. Insert the floppy disk, then press Enter. Select Asmedia 106x SATA Controller 64bit, then press Enter.
  • Page 9 Insert the driver CD, click Start, then Run. Type D:\setup.exe, click OK. (Change D: to match your CD-ROM drive letter) Click Next. Select I accept the terms of the license agreement, then click Next. Click Finish. Click Yes to complete the installation. To Verify Windows Installation Use Device Manager to verify installation.

  • Page 10: Mac Os Installation

    Mac OS Installation The driver is built-in to Mac OS. Simply install the board and boot up the system, the DP eSATA 6Gb/s 2-Port PCIe adapter is ready for use. To Verify Mac OS Installation Click About This Mac, click More Info, then click System Report.

  • Page 11: Technical Support And Warranty

    Go to www.siig.com, click Support, then REQUEST A PRODUCT REPLACEMENT to submit a request to SIIG RMA or fax a request to 510-657-5962. Your RMA request will be processed, if the product is determined to be defective, an RMA number will be issued.
  • Page 12 Fremont, CA 94538-3152, USA Phone: 510-657-8688 DP eSATA 6Gb/s 2-Port PCIe is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. All other names used in this publication are for identification only and may be trademarks of their respective owners.
