Summary of Contents for CableTronix CT-CCT-BFR2
- Page 1 USER MANUAL CT-CCT-BFR2 Compression Tool...
-
Page 2: Package Contents
One User Manual PRODUCT DESCRIPTION The CT-CCT-BFR2 is a linear compliant compression tool for use with RCA, F, and BNC compression connectors from Cabletronix and other vendors. The tool comes with 3 adaptors for the appropriate RCA, F, and BNC connectors and supports RG59, RG6, and RG11 coaxial cables. - Page 3 3. PRODUCT DIAGRAMS Handle Adaptors for BNC, RCA, Back Plate and F connectors Sealing Sleeve Connector Adaptors 4. CABLE and CONNECTOR PREPARATION a. To get a solid and reliable fit it is important that the cable and connector be properly prepared before compressing the connector onto the cable.
- Page 4 5. USING THE COMPRESSION TOOL a. Select the appropriate adaptor for the connector to be compressed. b. Screw the adaptor to the tool’s plunger. c. Place the connector/cable assembly into the compression tool with the connector end flush with the adaptor and the compression end against the tool’s back plate. d.
