Tronios DVR User Manual

Hide thumbs Also See for DVR:

Advertisement

Quick Links

User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DVR and is the answer not in the manual?

Questions and answers

Summary of Contents for Tronios DVR

  • Page 1 User Manual...
  • Page 2: Table Of Contents

    ............................... 4  Chapter 1 Features ................................1  Chapter 2: Overview ............................... 2  2.1 Front Panel ................................2  2.1.1 4CH DVR Front Panel ........................... 2  2.2 Rear Panel ................................2  2.2.1 4CH DVR Back Panel..........................2  2.2.2 8CH DVR Back Panel..........................3 ...
  • Page 3 User Manual 6.3.2 Playback ..............................43  6.3.3 Configuration ............................46  6.3.4 Local setting............................55  6.3.5 Logout ..............................55  Chapter 7: Appendix ..............................56  7.1 Operation Function Table........................... 56  7.2 Record Alarm setting ............................57  7.3 Mail box server List ............................57  7.4 Troubleshooting ..............................
  • Page 4 User Manual 1. Read Instruction All the safety and operating instruction should be read before the equipment is operated. 2. Power sources This equipment should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power, please consult your equipment dealer.
  • Page 5: Chapter 1 Features

    Support SATA large capacity HDD and save real-time record image to HDD. storage Support DVR single CH and multiple CH Search/Playback of recorded Playback files. Support DVR backup via USB flash drive, removable drive, Recorder and Backup network. Supports HDD & video input alarm management and external alarm Alarm Setting signal inputs.
  • Page 6: Chapter 2: Overview

    User Manual Chapter 2: Overview 2.1 Front Panel Reminder: DVR is the abbreviation of Digital Video Recorder Equipment. 2.1.1 DVR Front Panel Key title Item Remark Function & Description or Indicator USB Port Connect to USB2.0 port List 2-1 2.2 Rear Panel 2.2.1...
  • Page 7: 8Ch Dvr Back Panel

    User Manual 2.2.2 8CH DVR Back Panel Item Physical port Connection method Video input Connect CH1-4 (Virtual) video input device BNC interface Video output Connect monitor output(BNC interface) Audio Input 4CH audio input (BNC interface Audio Output 2CH output; RCA(interface...
  • Page 8: 4/8-Ch Remote Controller

    User Manual 4/8-CH Remote Controller Item Key title Key function Channel select 1-8; Numeric key Numeric key; Clicking numeric “0” allow you switch to GUI (Graphical user Interface) 9、0 function Multiple display mode Menu Enter into Main menu/Exit Up arrow key, Volume adjust ▲...
  • Page 9 User Manual Mouse Operation Except using buttons of front panel or remote controller, you also can use mouse to perform system operation. TYPE Function In menu lock mode, Enter into pop-up menu and clicking any sub menu to pop up Log-in window; on menu unlock mode, enter into pop-up menu, and then clicking left key to enter into any sub menu directly.
  • Page 10: Chapter 3 Dvr Installation

    Camera and Monitor Connection Connect camera cable to video input of DVR, and from video output of DVR to Monitor via BNC connector (Refer to section2.2-Rear Panel); or If the camera is a PTZ speed dome, you could connect RS485 A & B to the according port of DVR respectively (refer to system figuration on Chapter 8).
  • Page 11: Chapter 4: Dvr Boot Up

    User Manual Chapter 4: DVR Boot up 4.1 System Initialization After connecting the Power cable of DVR to wall outlet and pressing the Power button on the front panel, you will enter into the system initializing screen shown as Picture 4-1...
  • Page 12: Main Menu Guide

    User Manual 5.2 Main Menu Guide Live set  Display Output Set  Privacy Zone  Record Parameters  Record Schedule  Main Stream  Record Search  Event Search Search Backup Log search Network Set  Sub stream  Main Menu  Email Set  Network Mobile Set  DDNS Set  Motion  Alarm Alarm set  HDD  PTZ set  Device Serial Set  General  System Users  System Information  Maintain  Advanced Event ...
  • Page 13: Main Menu

    User Manual 5.3 Main Menu On <Live> mode, click [Menu] button on the front panel or Remote controller to enter into Main menu interface shown as Picture 5-2. And also you can click [ ] icon to enter the main menu screen.
  • Page 14: Output Mode

    Spot output: display window will include Single, Quad and 9-split mode. Transparency: allow you adjust menu’s transparency, and its range is 1~128. Margin: allow you adjust the whole screen’s margin. Details operations please refer to the Picture 5-10. Volume: allow you adjust the DVR volume shown as Picture 5-11.
  • Page 15: Record Set

    User Manual Picture 5-10 Picture 5-11 5.3.1.3 Privacy Zone The function Allow you setup privacy zone parameters according to Picture 5-12. Each channel could set up to four privacy zones, and please follow below steps to set: 1. Select the area no (Area 1 ~ Area 4); 2.
  • Page 16: Main Stream

    User Manual Channel: allow you setup the channel you desired. Record: allows you set up record status (Enable/Disable) of each channel Pack Duration: indicates maximum continuous record time (15, 30, 45 and 60 min). Pre-record: Motion detection and I/O triggered record support Pre-record function.
  • Page 17: Search

    Playback Mode: You can use the Playback Control bar to operate the Fast Forward (X2, X4 and X8), Slow play (1/2, 1/4 and 1/8 speed), Play, Pause/Frame, Rewind(X2, X4 and X8). When ending playback, DVR will return back to previous menu shown as Picture 5-20.
  • Page 18: Event Search

    User Manual 5.3.3.3 Event Search Click [Main Menu Search Event Search] to enter into the interface shown as Picture 5-20. You could highlight and double-click the desired record for playback. And you also can filter the records you want to view based on date, time, and channel and record mode search. (First Page): go to the first page on the list.
  • Page 19: Media Player Backup

    After backup finished, please click [OK] button shown as Picture 5-24. Note: File will be saved as *.264 format. You could playback the record files via Dvr Client player. When installing Dvrclient, system will auto install the player. Please make sure the back-up device connect well before backup.
  • Page 20: Log Search

    User Manual Slow button: click the icon to play the backup record at 1/2, 1/4, 1/8 and 1/16 speed. FF button: click the icon to fast forward the backup record at x2, x4, x8 and/or x16 speed. Open: click the icon to open one record file. click the icon to enter into full screen mode.
  • Page 21: Network

    2. Exit and restart DVR; 3. Input media port and web port Picture 5-31 Set IP address captured by DVR and web port to a router Visit a remote DVR http: // public net IP: web port (such as: 8080)
  • Page 22: Sub Stream

    Friendly Reminder: The router’s port forwarding interface may be different, however, when entering into virtual server, user will always need forward port (range: 1025~65535) of router to IP address of DVR allocated or automatically captured, and select [All] or [Both] in corresponding protocol column and save the above setting.
  • Page 23: Email Set

    Picture 5-37 Receiver address: indicates receiver’s email address. The email address is used to receive image transmitted from DVR alarm. Please clear the images you have received as soon as possible to avoid overloading your email account. 5.3.4.5 Mobile Set The DVR is currently compatible with mobile phones running Andriod, Windows Mobile, Symbian operating systems, Iphone and Black berry on 3G networks.
  • Page 24 User Manual Click [Main menu Network Mobile] to enter into the [Mobile] interface shown as Picture 5-41. User Name: indicate user name of DVR, and support numbers and characters and 1~15 bits length User password: indicate user password of DVR, and...
  • Page 25: Mobile Viewer's Access Instruction

    User Manual Mobile Viewer’s Access Instruction The DVR is currently compatible with mobile phones running Windows Mobile, Symbian, Iphone, Blackberry and Androids operating systems. Below are these Mobile Viewer’s installation procedures. 1) First you need to copy a program named as “Aseesetup.CAB” that is included on the CD provided by the DVR to the mobile phone.
  • Page 26 User Manual Note: Please firstly make sure you have right PTZ parameter setting (details please refer to User Manual-Section 5.2.6.3) on DVR, then you could control PTZ camera through your mobile phone. The captured images will be saved to the defaulted path (Explorer Program Files Moveeye Photo file).
  • Page 27 Address: herein indicate public IP address connected to DVR or dynamic domain name used by DVR. Port: indicate the server port which has been set to your DVR. User’s Name herein input the user name which has been set on DVR-[Mobile Set] menu.
  • Page 28 The setting method for Iphone is same as the Sybian and Windows system. Please refer to the previous section. Enter device title Enter IP address of the DVR Enter DVR web port Enter user name of DVR Enter password of DVR...
  • Page 29 User Manual 4) Choose [Application Loader ] from the Main Menu shown as Picture 18 5) Click [Start] Button on the Add/Remove application menu shown as Picture 19 6) Click [browser] button and tick-select [ASee.alx] file shown as Picture 20 7)...
  • Page 30 4.3 Click the [History] button to enter into the History List shown as Picture 28. 4.4 Highlight one record and click [Enter] button to enter into pop up menu. When selecting [Open] option, system will directly be connected to the DVR and defaulted to display the CH1.
  • Page 31 User Manual 4.5 When selecting [Edit] option, system will allow you edit the history record. Picture 29 4.6 When selecting [Delete] option, the history record will be deleted. Picture 30 Picture 31 5) Click [Next Page] icon to search [Channel] option shown as Picture 32 and Picture 33, and then choose the channel you want to display.
  • Page 32 User Manual 9) Click [Close] button to exit the program shown as Picture 35. Androids Mobile Please make sure the software environment support on your Android Mobile, such as Apkinstaller. 1. Make sure your mobile have been connected to network and could download the software. Picture 36 Picture 37 Picture 38...
  • Page 33 Next CHs Group and help. 11. Setting Menu Address: Enter the IP address of the DVR Port: Enter the Mobile Port No. Of the DVR Device Name: Enter DVR name (User defined) User ID: Enter the User’s Name Password: Enter the User’s Password...
  • Page 34: Alarm

    IP address is changed in a dynamic IP system. User can visit a remote DVR by using DDNS on above three types (Static, DHCP and PPPoE) You can apply for a DDNS account for free at the www.3322.org...
  • Page 35: Alarm Set

    User Manual Show Message: You can set show message on the screen when motion alarm is detected. Buzzer time: you can set how long the buzzer will sound when motion is detected (10s, 20, 40s, 60s); Send Email Allows you set the alarm images is issued to a specified email. Full screen Alarm: The function is defaulted to “On".
  • Page 36: Device

    This figure is only for D9016 / CIF model reference Picture 5-43 When DVR is connected to a HDD, the system will automatically detect if HDD is normal or not; If the cable connected to HDD is loosen or HDD is abnormal, HDD status will be shown as “No Disk”, or, If HDD need to be formatted, status will be shown as “no format”,...
  • Page 37: Ptz Set

    HDD before they’re overwritten; and if overwrite is set to DISABLE the DVR will stop record once the DVR is full. Whilst you won’t lose old footage, you run the risk of missing new events as they happen. Be sure you want to do this before selecting it.
  • Page 38: System

    User Manual When operate DVR via keyboard, it is required to set communication protocol. baud rate serial Baud rate: communication. Data bit: set data bit of serial communication. Stop bit: set stop bit. Parity Check: set parity check to <None> or other.
  • Page 39 Maintain: allow you update version, recover ex-factory value, device reboot and shut down. Disk Manage: allow you manage and control the HDDs. Remote Login: allow you remote login DVR. Rotate Control: allow you sequence live screens for all the channels. Picture 5-53...
  • Page 40: Advanced

    Load Default: If [Load Default] is selected, you can initialize the system to the ex-factory default. Reboot: Click [Reboot] button to manually restart DVR system. Picture 5-55 Shutdown: Click the [Shutdown] button to shutdown the device. System Upgrade: You can insert a USB memory into USB port for updating;...
  • Page 41: Menu Lock

    Considering a system safety feature you can click [ ] icon to lock system interface when leaving the DVR. If you want to login to the DVR again, you would input device code and password to unlock the interface shown as Picture 5-58...
  • Page 42: Pip Mode

    User Manual Picture 5-59 We introduced setting PTZ parameters previously in section 5.3.6.2 – PTZ Set. Here we will discuss how to operate PTZ controls. Click the [ ] icon to enter into [PTZ control] menu shown as Picture5-60. Now user can control the camera with Pan, Tilt and Zoom capabilities.
  • Page 43: Mute

    5.9 Mute Click the [ ] icon, or press <Mute> button on the front panel and Remote controller to control the mute of DVR. 5.10 Manual Record You can start manual record function, or you also can click [ ] button on the Front panel or Remote controller to activate manual record.
  • Page 44: Chapter 6: Web Application Manager

    Chapter Web Application Manager 6.1 Plug-in download and installation Open your web browser and input the IP address and web port of DVR, such as http://172.18.6.202:8080/ . If your computer is connected to internet, it will download and install “ActiveX” Plug-in automatically. If your computer system is Vista, you may need to setup the user authority.
  • Page 45: Web Application Manager Log-In

    <Main stream> or <sub stream>, and then allow you tick-select <Open All Channels Preview>; Now you click [Log-in] button, and then you are allowed to access a remote DVR and monitor live video images using Web browser anytime from virtually anywhere.
  • Page 46 User Manual Volume switch Record icon: record will be saved to a specified position after starting record. Snapshot function: allow you capture the live images and save it to a specified position. The image should be saved as *.bmp format. : clicking the icon will close/open the current channel’s live mode Or click the right key of mouse on each <Live>...
  • Page 47: Playback

    User Manual Video control Adjust video Hue; Adjust video brightness; Adjust video Contrast; Adjust video saturation; Recover ex-factory default value. Picture 6-6 6.3.2 Playback Click [ ] icon to enter into <playback> interface shown Picture 6-7. Picture 6-7 The Web Application Manager supports up to 4 channels playback simultaneously. Record search Firstly, select one day you want to check and tick-select <synchronous Playback>...
  • Page 48: Playback Control

    User Manual Picture 6-8 Secondly, select record type (Normal record, Alarm record and All) and then click < > button shown as Picture 6-9. On the time axis, red part stand for alarm record, yellow stand for normal record and original part stand for no record during this period. Picture 6-9 If you tick-select <...
  • Page 49 User Manual Detail brief description is shown as below list Description Description Play Open/close audio Pause Volume adjust Stop Playback control bar (x1/2,1/4,1/8, normal, x2, x4, x8) By frame Stop all the play Clip Single channel mode Capture Quad mode Download Full screen Open all the channels...
  • Page 50: Configuration

    User Manual Picture 6-12 Tick-select the record file you want to download and click [Start download] System will download the record file in turn and save to local PC. 6.3.3 Configuration Click [Configuration] option to enter into the [Config] interface shown as Picture 6-13 and allow you set Display configuration, Record, Network, Alarm, Device, System parameters and Advance according to your actual request.
  • Page 51 Green stand for Normal record; Yellow stands for Motion detection; Red stands for I/O triggered record. Picture 6-16 Main Stream: detailed settings please refer to DVR local setting. Herein allow user modifies the resolution, frame rate, Bit rate and audio of the record channel.
  • Page 52: Network Parameters

    Static: System default <Static> as its network type. User could allocate IP and perform Port forwarding for DVR according to different router. When set <UPNP> to “On”, user no needs to perform port forwarding. Once you modify its network parameters successfully, DVR will automatically restart.
  • Page 53 Set network type to “PPPoE” shown as Picture 6-20. Its user name and password should be consistent with DVR local setting. Picture 6-20 Sub stream (shown as Picture 6-21): Relative parameters should be consistent with DVR local setting. Picture 6-21 Email setting: Click [Email setting] option to allow you set alarm email configuration parameters shown as Picture 6-22.
  • Page 54 User Manual Mobile: Its user name, password and port No should be consistent with DVR local setting shown as Picture 5-23. Picture 6-23 DDNS Setting: After user applies for DDNS service shown as Picture 6-24, you could enable <DDNS> function under any one network type mode (Static, DHCP and PPPoE). Now you remotely visit the DVR through domain name (http://domain name: port No).
  • Page 55 User Manual Picture 6-25 Motion Detection: allow you configure its <Sensitivity>, <Alarm out>, <Alarm record> and <Alarm Capture> etc. Details setting should be consistent with DVR local setting (Shown as Picture 6-26). Picture 6-26 I/O Alarm: allow you configure <I/O Status>, <Alarm output>, <I/O Alarm record> and <Alarm email>...
  • Page 56 Click <System> option to unfold its sub-options: General, Users and information. General: User could check DVR’s language and video system, and also set system time, date format, DST and NTP shown as Picture 6-30. Details setting should be consistent with DVR local setting.
  • Page 57 IE version and hardware version shown as Picture 6-32. Picture 6-32 6.3.3. 7 Advanced Click <Advance> to unfold its sub-options: System update, Load default, Events and system maintain etc. System update: allow you upgrade DVR system remotely shown as Picture 6-33. Picture 6-33...
  • Page 58 Click <Start update>, now processing bar will display current upgrade status shown as Picture 6-35. Picture 6-35 Load Default: allow you recover defaulted parameters of DVR remotely shown as Picture 6-36. Details setting should be consistent with DVR local setting. Picture 6-36...
  • Page 59: Local Setting

    User Manual Events: allow you configure abnormal type, buzzer output time, and alarm email and show message shown as Picture 6-37. Details setting should be consistent with DVR local setting. Picture 6-37 Maintain: allow you set auto system maintain for DVR remotely shown as Picture 6-38.
  • Page 60: Chapter 7: Appendix

    Live display Rea-time video surveillance remotely Remote record Set record mode and status of DVR remotely Remote playback Check local record history via network Network PTZ control Remotely control PTZ camera, position, focus, zoom and iris etc.
  • Page 61: Record Alarm Setting

    Format HDD Set network type and web port (except of Net setting PPPoE, other type need forward web port Basic option will to router of DVR. application effective after restart. System Info Modify MAC address Guide Set relative parameter ○, 5...
  • Page 62: Troubleshooting

    Q: Can the DVR have problems if it gets too hot, how can I prevent this? A: The DVR has a fan to help it dissipate heat while it is running. Please place the DVR in a place where there is good air circulation and away from heat sources to increase stability and life of the DVR.
  • Page 63: Usage Maintenance

    1. Please make sure DVR keep away from heating source. 2. Clean the internal dust regularly, keep DVR aeration well and be easy to heat dissipate. 3. Please not plug in RS-232 and RS-485 when power is on to avoid any damage to the port.
  • Page 64: Accessories

    User Manual 8-CH 7.7 Accessories Power cord Power Adaptor User Manual Guarantee Card USB Mouse Remote Controller Software CD...
  • Page 65 User Manual The material in this document is the intellectual property of our department . No part of this manual be reproduced, copied, translated, transmitted, or published in any form or by any means without our department prior written permission. Our products are under continual improvement and we reserve the right to make changes without noti ce.
