  • Page 1 RTK Sports Navigation User’s Manual  ...

  • Page 2: Table Of Contents

    Table of Contents Chapter 1 Features and Specifications .................. 4 RoyalTek BV-3200 PND features ................4 General Usage......................4 Specification......................4 Button / I/O/Slot ...................... 5 RF Function......................6 Power function ......................6 Chapter 2 Getting Started ..................... 7 Hardware overview....................7 2.1.1...
  • Page 3 6.1.8. Can’t I see my photos..................33 6.1.9. Takes longer than normal time to get a GPS fix......... 33 6.1.10. Factory reset does mean a GPS reset............33 6.2. Maintenance ......................34 6.2.1. Storage precautions..................34 6.2.2. Accessories and repair precautions ............. 34  ...

  • Page 4: Chapter 1 Features And Specifications

    Chapter 1 Features and Specifications 1.1 RoyalTek BV-3200 PND features The RoyalTek BV-3200 Portable Navigation Device is a powerful multifunction GPS/multimedia navigation and entertainment device. ‧ 3.5”with TSP (Touch Screen Panel) ‧ Sun light readable ‧ High sensitivity Broadcom GPS ‧...

  • Page 5: Button / I/O/Slot

    1.3.2 System overview and description Component BV-3100 hardware specification Samsung S3C2416@400MHz Operation System Windows CE 5.0 core version Broadcom BCH-4750 host based chipset + external patch antenna. ( Patch size : 20mm X 6mm ) TFT LCD LG TFT, 3.5”, 240x320 QVGA SDRAM Samsung 64/128 MB 1.8 V Mobile DDR NAND Flash memory...

  • Page 6: Rf Function

    1.5 RF Function 1.5.1 GPS Specification GPS receiver Module Broadcom Chipset BCM-4750 host based Firmware Broadcom supplied with library and virtual com port driver Channel Time to Fix First time Hot: 5 Sec Warm: 60 Sec Cold: 90 Sec (Open sky) Accuracy 10M @ 90% on open sky Protocol...

  • Page 7: Chapter 2 Getting Started

    Chapter 2 Getting Started This chapter describes the hardware interface of the RoyalTek BV-3200 and its peripherals. Instructions for setting up the device and some basic system operations are also discussed. 2.1 Hardware overview This section introduces the BV-3200 PND external features and hardware components.

  • Page 8: Basic Operation, Knowing Your Bv-3200

    2.2 Basic Operation, Knowing your BV-3200 Front View Rear View Table 1: Function controls Function Description Touch Screen Displays the applications, data, and map images. Mini-USB connector serves as the power connector for USB Port/Docking charging the device or as the dock for uploading files from connector computers.
  • Page 9 Rear View (without rear cover) Component Description Battery Slot Put the battery on the slot, before use the device. Accepts Micro SD storage cards, allowing you use audio and Micro SD slot image files stored in it for use with internal applications  ...
  • Page 10 Assembly your BV-3200: 1. Put the battery on your BV-3200 2. Insert the Battery in your BV-3200 (Photo 1-1) 3. Put on the rear cover on your BV-3200 (Photo 1-2) 4. Fix the lock button Photo 1-1 Photo 1-2  ...

  • Page 11: Starting Operation On Your Bicycle

    2.3 Starting Operation on your bicycle To Install the U-Bolt and Handlebar bas: 1. Place the U-Bolt around the handlebar, and thread the ends through the handlebar base. (Photo 2-1) 2. Tighten the nuts to secure the base. Do not over tighten. 3.

  • Page 12: Starting Operation On Your Motorcycle

    2.4 Starting Operation on your Motorcycle. Install the U-Bolt ,Holder and Handlebar base: 1. Place the U-Bolt and the holder around the handlebar, and thread the ends through the handlebar base. (Photo 3-1) 2. Tighten the nuts to secure the base. Do not over tighten. Photo 3-1 Fix the double–socket arm to knob: 1.
  • Page 13 Attach the Base Plate to the BV-3200 Mount 1. Thread the M4 X 40 mm flathead bolts and nuts to attach the base plate to the BV-3200 cradle. (Photo 3-4) Attach the Base Plate to the Handlebar Base 1. Align the Bass of the handlebar base and the ball of the base plate with the double-socket arm.

  • Page 14: Starting Operation On Your Automobile

    2.5 Starting Operation on your Automobile Install the car mount on the selected area. 1. Press the suction cup of the car mount firmly against to the windshield.(Photo 4-1) 2. Press down the lever to fix the suction cup in place. 3.

  • Page 15: Charging Your Bv-3200 Device

    2.6 Charging your BV-3200 device 1. Plug the car charger to the 12 V outlet of your car and then connect the charger cable to the Mini USB port of the BV-3200.(Photo 5-1) 2. You now can let your BV-3200 have the continuous power by the car charger. Photo 5-1 NOTE: Your car may be required to switch the vehicle ignition into the accessories position to power the cigarette lighter.

  • Page 16: Chapter 3 Using The Bv-3200

    Chapter 3 Using the BV-3200 3.1 BV-3200 Operating Basics After fully charging the BV-3200 it is ready to be used. Y ou can now turn it on and proceed to system settings configuration. After turn on the device, main page will display. This is also referred to the Favorite page. 3.2 To configure system settings: If you intend to start using your BV-3200 at once, we recommend that you configure the language and time zone settings first.
  • Page 17 Tap “Language” on the System page. It will display current language in central area. To drag wheel scroll language tags. To set the system time zone, tap “Time Zone” in System Menu. Tap the icon to set up the function of daylight saving s time. represent enable the function of daylight savings time.

  • Page 18: Additional System Settings

    3.3 Additional System settings Other system settings can be used to view and adjust your device current preferences. Navigate from the System Menu. 3.4 Reset GPS Reset:：When user wonder if GPS receiver perform properly or not .( ex : Change the region) Factory Reset：The factory reset function not only resets the operating system settings to default factory values, but also reset the GPS settings.
  • Page 19 Tap the “YES” to reset the GPS. Tap the “Factory Reset” icon in the Reset Menu. Tap the “YES” to do the Factory Reset. Tap the “Calibration” icon in the Reset Menu.  ...

  • Page 20: System Information

    Tap on the center of the target. Repeat as the target moves around the screen. 3.5 System Information 1. Tap the Sys Info. icon in the System Menu. 2. You can view the OS version, GPS firmware version and other system information.. 3.6 Volume Tap the V olume icon in the System Menu.

  • Page 21: Backlight

    3.7 Backlight 1. Tap the Backlight icon in the System Menu. 2. Adjust the Backlight brightness by drag triangle icon. 3. Drag to left will become dark, drag to right will become light.  ...

  • Page 22: To Set The Favorite Application Category

    3.8 To set the favorite application category: Otherwise, provide more organized and friendly application management interface for user organize their own favorite application category by drag-and-drop, the maximum number of favorite application shortcut is 6. Add icon to the favorite page Drag the icon to the category bar of favorite.

  • Page 23: Power Supply

    3.9 Power Supply BV-3200 has a completive power management system, and enhances its standby time. In addition, it can make end-users more convenient to carry it for entertainment purpose, not only using in cars but also at home, outdoor activities. 3.10 Charge While end-users use our standard car charger or AC adapter to charge BV-3200, the main screen would remind you.

  • Page 24: Chapter 4 Entertainment

    Chapter 4 Entertainment 4.1. BV-3200 Multimedia Player The BV-3200 is a fully capable multimedia player that can enhance your portable entertainment. In addition to its navigating function, the BV-3200 is also a mobile entertainment tool to let you enjoy digital music, view photos. These functions make the BV-3200 a true multimedia device.
  • Page 25 The MP3 player window below controls playback. ○ 1 ○ 2 ○ 3 ○ 4 ○ Table 4-2-1: MP3 player functions Function Return Return to list page Songs List all song by alphabet Album List all albums by alphabet. Artist List all Artists by alphabet Search Current play list...
  • Page 26 Tap the song on the music list. Tap bottom information bar will switch to song’s progress.  ...
  • Page 27 ○ ○ 8 ○ 1 ○ 2 ○ 3 ○ 4 ○ 5 ○ 6 ○ 7 Table 4-2-2: Play sound functions Function Play/Pause P/ay/Pause song Forward Forward to next song. Previous Reword to previous song Stop Stop music play. Repeat Repeat play songs.

  • Page 28: Photo Viewer

    4.3. Photo Viewer The BV-3200 has a great photo viewing option that makes it easy to share and view digital photos anywhere on the go. The program features: • Support for JPEG files (Support Max. 500 photos) • Auto-scanning of supported files in the device’s Micro SD card & Flash disk •...
  • Page 29 Tap specific thumbnail will enlarge thumbnail. Tap the screen will cause control bar display ○ 1 ○ 5 ○ 2 ○ 3 ○ 4 Table 4-3-1: Photo Album Viewer Function Return Return to thumbnail page Previous page Display previous photo. Auto Play mode Auto play all photos.

  • Page 30: Chapter 5 Communications

    Chapter 5 Communications 5.1. BV-3200 Bluetooth Once your Bluetooth-enabled Headset is paired with your BV-3200, you can enjoy listening to the music through the Bluetooth headset. NOTE：Make sure the Bluetooth settings of your Bluetooth headset. The Bluetooth switch is set to “ON” or “enable”. 5.2.
  • Page 31 1. Back to “Communication” screen, and tap “Connection” 2. Tap “Search” to look for Bluetooth on of mobile phones, and 3. Choose one which you want to connect to, and tap “Connection”  ...
  • Page 32 4. Choose “Stereo” or “ Mono” 5. When the connection completes, the name of the connected device is displayed on the title bar of the “communications” screen. NOTE：Bluetooth function has distance limitation. While the Bluetooth headset is away, and make Bluetooth function disconnect, BV-3200 would try to re-connect within 10 seconds.

  • Page 33: Chapter 6 Troubleshooting And Maintenance

    Chapter 6 Troubleshooting and Maintenance 6.1. General troubleshooting 6.1.1. If your device does not respond, do a “hard reset.” To do a “hard reset,” Disconnect all cables, including the AC adapter, from your device. By sliding the hard reset switch on the primary ON/OFF switch on the right side of the device form OFF to ON position then tap the power button.

  • Page 34: Maintenance

    6.2. Maintenance • Avoid exposing your device to direct sunlight or strong ultraviolet light for extended periods of time. • Do not drop your device or subject it to severe shock. • Do not subject your device to sudden and severe temperature changes. This could cause moisture condensation inside the unit, which could damage your device.
