NetAtlas PON, EPON
Manager
for OLT-1308S-22
Quick Start Guide
Version 1.10
6/2009
Edition 1
Copyright © 2009. All rights reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the NetAtlas and is the answer not in the manual?

Questions and answers

Related Manuals for ZyXEL Communications NetAtlas

Summary of Contents for ZyXEL Communications NetAtlas

  • Page 1 NetAtlas PON, EPON Manager for OLT-1308S-22 Quick Start Guide Version 1.10 6/2009 Edition 1 Copyright © 2009. All rights reserved.
  • Page 2 NetAtlas EPON Manager Quick Start Guide Overview NetAtlas EPON Manager is a Unix-based Element Management System (EMS) that allows you to configure and monitor EPON devices from a centralized location. The following figure displays an EMS application: • A - The EMS is the computer with the management software installed.
  • Page 3 NetAtlas EPON Manager Quick Start Guide This Quick Start Guide includes: EMS Server System Requirements Part I Installation Procedure - Follow these steps to install the EMS Server for the first time. Install HP OpenView Network Node Manager (NNM) Install MySQL Server...
  • Page 4 NetAtlas EPON Manager Quick Start Guide Software Solaris 2.9 X11R6/Motif 2.2 Database: MySQL 4.1.8 HP OpenView Network Node Manager 7.5 Web Server: Apache 2.2.4 (for OSS Interface) (optional) Devices Supported OLT-1308S-22 3.80(BHJ.0)C0 Part I Installation Procedure 1 Install HP OpenView Network Node Manager (NNM) See the documentation that comes with the HP OpenView NNM distribution for detailed information.
  • Page 5 NetAtlas EPON Manager Quick Start Guide 6 After the installation is complete, the following message displays and the system starts the HP OpenView NNM daemons. ******************************************************************* Congratulations! Your installation was successful. ******************************************************************* Starting Network Node Manager daemons: Name State Last Message(s)
  • Page 6 NetAtlas EPON Manager Quick Start Guide 4 Copy the MySQL installation file (for example, mysql-standard-4.1.8-sun- solaris2.9-sparc.tar.gz ) to the /usr/local directory. 5 Enter the command to uncompress the MySQL installation file. $ gunzip mysql-standard-4.1.8-sun-solaris2.9-sparc.tar.gz $ tar xvf mysql-standard-4.1.8-sun-solaris2.9-sparc.tar mysql 6 Create a symbolic link to the installation directory (in this example, the mysql-standard-4.1.8-sun-solaris2.9-sparc...
  • Page 7 NetAtlas EPON Manager Quick Start Guide 9 Enter bin/safe_mysqld --user=mysql & to run the MySQL server as a background process. $ ./bin/safe_mysqld --user=mysql & Starting mysqld daemon with databases from /usr/local/mysql-4.1.8- sun-solaris2.9-sparc/data 10Set the password for the root user. Specify the password in single quotes. In this...
  • Page 8 NetAtlas EPON Manager Quick Start Guide 5 The EMS begins the installation. Follow the on-screen instructions. Installing NetAtlas EPON Manager... OVW and EMS windows/daemons will be stopped before installation. Continue it? [yes] >> Where is the OpenView directory in FULL path? [default: /opt/OV] >>...
  • Page 9 NetAtlas EPON Manager Quick Start Guide After EMS installation is complete please re-login to your workstation so the NetAtlas EPON menu can be added to the front panel on the desktop. NetAtlas EPON Desktop Menu You can use this menu to do the following actions: NetAtlas EPON Manager Click this to start the NetAtlas EPON Manager.
  • Page 10 NetAtlas EPON Manager Quick Start Guide If you added nodes manually in HP OpenView NNM, this information is lost when you run this procedure. You have to add the nodes manually again. 1 Stop the EMS from running. $ /opt/GEPONEMS/bin/emsstop...
  • Page 11 5 Start the EMS There are three ways to start the EMS. The easiest way is to re-login into your workstation after installation and use the NetAtlas EPON Menu on the desktop. You can also launch the EMS via the following command:...
  • Page 12 NetAtlas EPON Manager Quick Start Guide 2 A map of your network displays. Double-click a network icon to display the network segment map. 3 The network segment map displays. Double-click the icon for your EPON device.
  • Page 13 NetAtlas EPON Manager Quick Start Guide 4 Double-click the IP interface icon in the device map to display the EMS login screen. Go to Log in to the EMS section on page 13. 6 Log in to the EMS When the EMS login screen displays, enter the username (the default is “admin”) and password (“1234”...
  • Page 14 Otherwise, click Evaluate to use a trial service. See Register the EMS for details. The main screen then displays as shown next. Double-click on the NetAtlas EPON Manager icon (A) to display the main device manager screen (B).
  • Page 15 NetAtlas EPON Manager Quick Start Guide Part II Additional Procedures Manually Add Network Nodes Use this section, if you did not choose to run auto discovery during HP OpenView NNM installation or if you want to add additional EPON devices to be managed by the EMS.
  • Page 16 NetAtlas EPON Manager Quick Start Guide 2 In the Add Object Palette screen that displays, click the Network icon (A) and the IP Network icon (B). Click the middle button on the mouse to drag the selected icon to the Internet screen.
  • Page 17 NetAtlas EPON Manager Quick Start Guide A) Specify the Network Name and Network Address fields (HP OpenView automatically calculates the subnet mask). B) Click OK. 5 A new network icon displays in the Internet screen. Double-click on the network icon...
  • Page 18 NetAtlas EPON Manager Quick Start Guide 6 To add a device object icon, click Edit, Add Object…. Select the ZyXEL Device (A) and the zyxel icon (B) you want to add. Click the middle button on the mouse to drag the selected icon to the network segment screen.
  • Page 19 NetAtlas EPON Manager Quick Start Guide A) Enter the IP address of your EPON device in the Preferred SNMP Address field. B) Click OK. 9 In the Add Objects screen (see step 7), select IP Map in the Object Attributes field and click Set Object Attributes….
  • Page 20 NetAtlas EPON Manager Quick Start Guide 11A new icon displays in the network segment map. Double-click on the device icon (A) to display the screen which shows all of the device’s network interfaces. Double-click on the IP interface icon (B) to display the EMS login screen (C).
  • Page 21 Click Register... to open the Registration screen to enter the license key. If you click Evaluate or Cancel, open the Registration screen by clicking Help > Register... in the NetAtlas EPON Manager main screen (see the User’s Guide). Before you activate the standard service, make sure the computer with the...
  • Page 22 4 Enter your e-mail address. 5 Select your country from the drop-down list box. 6 Click Submit to register your NetAtlas EPON EMS to activate the standard service. If you lost your license key or the EMS registration failed, contact your local agent or ZyXEL customer support.
  • Page 23 NetAtlas EPON Manager Quick Start Guide Software Solaris 2.9 X11R6/Motif 2.2 HP OpenView Network Node Manager 7.5 Web Server: Apache 2.2.4 (for OSS Interface) (optional) Follow these steps to install the EMS Remote Client on other computers. You need the IP address of the MySQL database/EMS server.
  • Page 24 NetAtlas EPON Manager Quick Start Guide Set up the Management Server Follow these steps on the management server, the computer where you installed HP OpenView NNM. 1 Run this command: ps -ef|grep nfsd If the nfsd process is not running, run /etc/init.d/nfs.server start.
  • Page 25 NetAtlas EPON Manager Quick Start Guide 4 Run these commands to mount the new directories. $ /etc/mount server_name:/etc/opt/OV/share $ /etc/mount server_name:/var/opt/OV/share 5 Set up the client by running the following script: $OV_BIN/ovwsetupclient /opt/OV/nfs/server_name 6 To verify that the configuration is correct, run the following command. It should display your fully qualified domain name of the server.
  • Page 26 Please input the home directory of MySQL database system [default: / usr/local/mysql ] >> Please input the user name who can access the MySQL database system [default: root ] >> Please input the user password [default: mysql ] >> NetAtlas PON, EPON Manager is installed successfully!
  • Page 27 The EMS prompts you to confirm that you want to uninstall the EMS. Enter y to proceed. Remove NetAtlas EPON Manager... Warning: You are going to uninstall NetAtlas EPON Manager, are you sure? [no] >> y Start uninstallation... Stop the EMS Window...
