Summary of Contents for AdvanceTec AdvanceMobile AT3550A
- Page 1 AdvanceMobile ™ Installation / User Manual Part No. AT3550A AdvanceTec Industries, Inc 1150 NW 163 Drive, Miami, FL 33169 T: 305-623-3939 F: 305-623-3996 Toll Free: 1-800-881-8211 Company web site: www.advancetec.com services: www.advancemobilegps.com...
- Page 2 Index Page Description Part numbers and installation guides 3 - 4 Installation Warnings 4 -5 Installation of Speaker 5 - 6 Installation of PTT Installation of Microphone 6 - 8 Installation of Power Cable 8 - 10 Installation of Vehicular and GPS Antenna Installation of Emergency PTT 10 - 11...
-
Page 3: Vehicles Equipped With Air Bags
The AdvanceTec AdvanceMobile™ is designed to provide secure and convenient vehicular communication with GPS tracking if needed. The AdvanceMobile™ consists of: 1. Part # AT8246A Junction Box 2. Part # AT8231A Speaker 3. Part # AT8230A Visor Microphone (Visor Mic.) 4. - Page 4 It is recommended that the installation of the vehicle communication equipment be performed by a professional installer/technician trained in the requirements for such installations. An air bag's size, shape and deployment area can vary by vehicle make, model, and front compartment configuration (for example, bench seat vs.
- Page 5 Mounting Bracket Thumb Screws Diagram 1 4. Position the Speaker on the mounting bracket and secure it by tightening the thumbscrews. The mounting bracket is used to permanently mount the Speaker in place while permitting it to be tilted to a desired angle. 5.
- Page 6 2. To attach the PTT to a flat surface, remove the 2 screws from the bottom of the PTT, which holds the Velcro strip in place. Remove the strips and replace the small plastic part that held the strips in place with the larger flat plastic part supplied with the PTT.
- Page 7 Caution: The AdvanceMobile™ should be used with a negative ground electrical system only. Reverse polarity (positive ground) will trigger protection circuits which cause the cable fuse to open. Check the ground polarity before you begin the installation to prevent wasted time and effort. 12V DC or 24V DC automotive systems are directly supported Determine the best cable route to the vehicle ignition for the Power Cable from the location where you intend to mount the Junction Box.
- Page 8 4. Cut the black lead to the desired length. 5. If the connection is being made under the dash or in the vehicle cabin, connect the black lead directly to the chassis of the vehicle. 6. If the connection is being made in the engine compartment, connect the in-line fuse holder between the black lead of the power cable and the desired chassis connection point.
- Page 9 GPS antenna connector on the junction box. The GPS antenna is an optional extra that is available to be purchased from AdvanceTec. 6. Feed the antenna cables out of sight to the location where you intend to...
- Page 10 F. Emergency PTT The RED Emergency PTT is available as an optional extra 1. To attach the Emergency PTT to the gear lever, strap the PTT around the gear lever using the Velcro strip attached, with the cord facing down. Velcro Strip Flat Plastic Diagram 8...
- Page 11 Diagram 10 3. Insert the SIM card under the metal cover and close the metal cover and slide to the right to lock. Diagram 11 4. Replace the plastic SIM cover and screw it closed. NOTE: The SIM card can not be inserted or removed while the Junction Box is powered.
- Page 12 2. DO NOT mount the junction box at this stage. Connect the PTT, Microphone, Speaker, Power cable and to their corresponding connections on the Junction Box as indicated in Diagram below. Mic. Speaker PTT Optional Optional Power Control Module Palm Mic/. Handset w/Cradle Diagram 8 3.
- Page 13 NOTE! Both the PTT and the Programming button must be kept depressed until the programming has been successfully completed and the 5 fast beeps are heard on the speaker. Diagram 12 3. Once the Private ID or Group ID has been successfully loaded, proceed to permanently mount the junction box with the screws provided ensuring that all extra cabling is secured out of harms way.
- Page 14 Incoming PTT 1. To respond to an incoming PTT call that is from the PTT Private ID or Group programmed into the AdvanceMobile ™, press and hold down the PTT button. 2. Speak towards the visor microphone 3. To respond to an incoming PTT call that is NOT from the Private ID or Group programmed into the AdvanceMobile ™, press and hold down the PTT button within 15 seconds of the receipt of the PTT call.
-
Page 15: Optional Extra Accessories
Optional Extra Accessories AdvanceMobile™ Control Module (Part # AT3510A) The AdvanceMobile™ control module (Control Module) is an optional extra which will enhance the features and functions of the AdvanceMobile™. With the addition of the Control Module, PTT calls from the AdvanceMobile™ can be increased from a single Private ID or Group ID to a Group ID and 9 different Private IDs. - Page 16 Diagram 15 NOTE! Both the PTT and the Programming button must be kept depressed until the programming has been successfully completed and the 5 fast beeps are heard on the speaker. 5. Once the new private ID is successfully programmed, the channel number in the screen will no longer flash.
- Page 17 6. Adjust the volume by pressing the Right Volume Buttons Up or Down. After a volume button is pressed a blinking dot will appear in the bottom right corner of the screen to indicate that it is in the volume mode. The Minimum volume is 0 and the Maximum is 5.
- Page 18 Privacy Handset ( Part # AT7107A) Diagram 16 1. PTT calls can be made and PTT and cellular calls can be received in the same way with the Privacy Handset as with the PTT described above. 2. Lift the privacy handset out of the cradle and using the PTT button on the back of the privacy handset follow the instructions for making and receiving calls as set out above.
- Page 19 Palm Mic (Part # AT8410A) Diagram 17 1. To use a Palm Mic. with the AdvanceMobile™, plug the connector on the end of the coil cord of the Palm Mic. into the corresponding RJ45 receptacle on Junction Box. 2. Once connected, the pressing of the switch on the Palm Mic. will deactivate the Visor Mic.
-
Page 20: Specifications
Specifications Input/Output • Input voltage 10.5Vdc to 32V dc Ignition detection: • Ignition “ON” 2.5Vdc to 32Vdc • Ignition “OFF” 0V to 2.5V or OPEN • Outputs Entertainment Mute • Open Drain • Continuous current capacity: 50Ma Audio Specifications • RJ45 Supports, Palm MIC # AT8410A and Privacy Handset Part # AT7107A •... - Page 21 • Conducted -57 dBm • Radiated 500 uV/m • Transient Response 0.01% BER during RX-TXRX • Frequency Acquisition 0.01% max ± 220 Hz RF input • Blocking Immunity 10% max Transmitter Specifications • Frequency Range min 806 max 825 MHz band •...
- Page 22 GPS Antenna Spec. Patch • Center Frequency 1575.42 ± 1.023 MHz (when covered with a radome and measured by LNA ground plane) • • Bandwidth (10dB return loss) 10 MHz min • Gain at Zenith 1dB type • Gain ay 10° elevation -5 dBic type •...
- Page 24 AdvanceMobile™ GPS services www.advancemobilegps.com AdvanceTec Industries, Inc 1150 NW 163 Drive, Miami, FL 33169 Tel: 305-623-3939 Toll Free: 1-800-881-8211 www.advancetec.com...
