Summary of Contents for AITech HD.PC.Video to HDMI Converter
- Page 1 HD.PC.Video to HDMI Converter Operation Manual Operation Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Introduction ..................2. Features ....................3. Operation Controls and Functions ............ 4 3.1 Front Panel ..................3.2 Rear Panel ..................4. Remote Control ................... 5. RS-232 Remote Control Protocol ............5.1 RS-232 transmission format............6. Connection and Installation ............... 7. -
Page 3: Introduction
1. Introduction The HD.PC.Video to HDMI Converter is a high quality Video converter box to convert Analog and digital signals to HDMI v1.3 output. The product is compatible to HDMI v1.3 specifications, a cutting edge technology which defines to transfer Deep Color (10-bit and 12-bit) video. Simply select from the front panel or remote control to choose the input sources. -
Page 4: Operation Controls And Functions
3. Operation Controls and Functions 3.1 Front Panel: 480I 480P POWER HDMI 1 HDMI 2 HDMI 3 COMP 1 COMP 2 SVIDEO-1 SVIDEO-2 VIDEO-1 VIDEO- DELAY 576I 576P AUDIO CSC-5300 HDMI 1.3 VIDEO SWITCHER 3D Video Comb Filter/12bit Power switch and power LED indicator: Press the switch to power on the unit and the power LED will illuminate. -
Page 5: Remote Control
4. Remote Control 1. Audio Delay: Press to delay audio output for 150ms. Audio Delay 480I 480P POWER 576I 576P 2. Format selection: To switch between Interlace and Progressive format. COMP 3. Power: Press the button to turn on/off the unit. SVIDEO 4. -
Page 6: Rs-232 Transmission Format
5.1 RS-232 transmission format: Command Code Response Description S POWER 0 > POWER OFF POWER OFF S POWER 1 > POWER ON POWER ON S SOURCE 0 > SOURCE HDMI1 HDMI1 INPUT S SOURCE 1 > SOURCE HDMI2 HDMI2 INPUT S SOURCE 2 >... -
Page 7: Connection And Installation
6. Connection and Installation ↑ ↓ ↓ ↓ BLU-RAY BLU-RAY 7. Specifications LCD TV Frequency bandwidth 2.25Gbps (single link) Input ports 3 x HDMI female ports (Type A connector) 1 x PC with audio jack 2 x Y/Pb/Pr with R/L 2 x CV/SV with R/L 1 x RS-232 Output port... - Page 8 AITech International www.aitech.com HD.PC.Video to HDMI Converter AITech P/N: 07-033-003-12...
