PLUSTV 1680ex
USER'S MANUAL
Ver 1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PLUSTV 1680ex and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for KWorld PLUSTV 1680ex

Summary of Contents for KWorld PLUSTV 1680ex

  • Page 1 PLUSTV 1680ex USER’S MANUAL Ver 1.0...

  • Page 2: Table Of Contents

    4.3 Operations for PIP function at PC mode ..................14 5. Operations for game function....................... 14 6. Troubleshooting ........................... 15 Thank you for buying KWorld’s PLUSTV 1680EX . For better use of the product, please read this User’s Manual carefully before use.
  • Page 3 The right to interpret all contents of this User’s Guide belongs to the company The manual is subject to change without notice. This User’s Manual is not authorized to any party and no reproduction or copy, in part or whole, of the manual in any way is permitted. KWorld Website: www.kworld.com.tw...

  • Page 4: Instruction

    LCD monitor, you can easily get a fashionable and healthy LCD TV. The PLUSTV 1680EX has PIP (Picture In Picture) function at PC mode, which allows you to enjoy wonderful TV programs while operating PC, so neither work nor entertainment is held up.

  • Page 5: Packaged Contents

    Channel number ordering function allows you to arrange the order of programs as your favorites. PC/TV changeover switch. Composite video output TV program. (OSD can not support in this function ) 1.2 Packaged contents PLUSTV 1680EX 1 PC User’s Manual 1 PC Remote control...

  • Page 6: Technical Specifications

    1.3 Technical specifications Power input: DC 5V, 800mA TV System Input: 75Ω IEC or type-F TV System Support: NTSC, PAL, Secam (Depend on the model) Video Input: Composite video input (RCA) S Video input (4PIN) YPbPr input (RCA) VGA input Video Output: D-SUB output Composite video output (OSD is not support in this mode)

  • Page 7: Remote Control Instructions

    2. Remote control instructions 2.1 Diagram of remote control and buttons description 7. Video button 1. Power / Standby 12. NICAM button 5. Timing button 2. Mute 6. Display button 3. 0-9 Channel 4. Return button 18. Factory Default 16. Aspect Ratio button 19.
  • Page 8 set is over. 6. Display button: If this button is clicked, the number of the program you are watching will be displayed. 7. Video button: Clicking this button continuously, you can change over the mode among TV/ Video/ S video/ YPbPr circularly. 8.

  • Page 9: Hardware &Installation Instructions

    3 Hardware &installation instructions 3.1 Product picture and panel description : Power/Standby, OSD menu button, i.e. Press to open OSD menu. Press 3~5 seconds to switch the Power/Standby. : Program + and program - button. : Volume + and volume - button. LED indicator: Lighting up high for TV or PIP mode.

  • Page 10: Rear Panel Description

    3.2 Rear panel description VGA: The 15-pin connector end on attached cable connected to the output of video card in PC and the other end on the cable to the VGA port. Connected with MONITOR: monitor. AUDIO IN: Audio input port, which is connected with the output port of sound card of PC casing through the attached stereo audio cable.

  • Page 11: Connection Illustration

    3.3 Connection illustration...

  • Page 12: Installation And Channel Scan For The First Time

    3.4 Installation and Channel scan for the first time When you use the PLUSTV 1680EX for the first time, please refer to the hardware connection illustration in the user’s manual to complete the hardware installation. To ensure that you can watch and select active channels, please follow the next steps to setup your TV channels：...

  • Page 13: Menu Display And Description

    4. Menu display and description 4.1 Menu display and description Menu I: Picture Contrast, brightness, Chroma, hue can be adjusted from 0 to 100 respectively. (Note: Hue option can be displayed only if the video input is NTSC system signal.) There are two states, ON and OFF, for noise reduction.
  • Page 14 Menu III: Display setup Adjusting Output mode, you can change over the resolution and refresh rate of output picture. Aspect Ratio, used for the changeover of picture aspect ratio. Menu IV: Auxiliary Calendar, used to display year/month/day and week. You can use “P+”/“P-” and “VOL+”/”VOL-”...
  • Page 15 Menu V: TV Tuning Channel Number, used for the display of present channel number. Channel Skip, used to delete the channel with no signal or poor signal. Channel Swap, used to arrange the order of TV programs as per your liking. Region: Select your region (TV system) or common.

  • Page 16: Program Searching

    Menu VII: Timing Timer OFF: used to set the time for shutdown. It shall be changed to “on”. Timer ON: used to set the time for startup. It shall be changed to “on”. Valid time: used to set the valid time of your setting as once or every day. Startup Mode: used to set the mode for each startup, which can be set as video, S-video or TV.

  • Page 17: Operations For Pip Function At Pc Mode

    You can use CH. Swap option in TV Tuning menu to conduct ordering for TV programs. For example, CCTV-8 and CCTV-12 are now located in channel 8 and channel 12 respectively and you want to arrange them in channel 1 and channel 2 respectively, you can conduct the following operations: select CCTV-8, enter into TV Tuning menu, select CH swap option, change the channel number from 8 to 1, and then click Menu button.

  • Page 18: Troubleshooting

    6. Troubleshooting 6.1 TV part Failure Cause and action No power connection, or defective connection of No picture, no sound plug. Receiver is at standby mode. Speaker for multimedia is not connected Picture displayed without properly. sound Volume is not turned on. Click Volume + button. Chroma is not turned on.
