GPX R633B User Manual

R633B Shortwave Radio
FCC Warnings
Warning: Changes or modifications to this unit not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment
Introduction and Setup
Power
Plug the AC power cord into an AC power
outlet to power the dock.
Tuning
SW2
SW1
AM
FM
DC IN 5V
VOL
Adjust to tune the radio.
Adjust to power the unit on
and select a desired volume.
Power Indicator
Time Set/Light
In Off mode, press
and hold to begin

setting the time.

Press to light up the
display.
Alarm Set/Light
In Off mode, press
and hold to begin
setting the alarm.
Press to light up the
display.
For Warranty Information and the most up-to-date version of this User's Guide, go to www.gpx.com
Email Support: prodinfo@dpiinc.com, Email Parts: partsinfo@dpiinc.com
Copyright © 2012 Digital Products International (DPI, Inc.) All other trademarks appearing herein are the property of their respective owners.
Specifications are subject to change without notice.
Battery Backup
Requires 3, D-size, batteries (not included)
Tuning
Tuning
SW2
SW1
AM
FM
Volume
DC IN 5V
VOL
Alarm On/Off
Press to turn the
Press to adjust the
alarm on or off.
hour when setting
the clock or alarm.
does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Source
Press to adjust the source
between SW1, SW2, AM
and FM radio modes.
Headphone Jack
DC Power Input
Power
TIME SET ALARM SET ALARM HOUR MIN
ON/OFF
LIGHT LIGHT
Volume Indicator
Hour
USER'S GUIDE
V: 846-01
Min
Press to adjust
the minute
when setting
the clock or
alarm.
Customer Service: 1-888-999-4215
