- Page 1 Manual and User Guide TV Talker Infrared System Model WIR 240 Model WIR 250 Transmitter Model WIR 240 Receiver Model WIR RX240 or Receiver Model WIR RX250 MAN 147E ©2011 Williams Sound...
-
Page 2: Table Of Contents
Contents System Overview .................. 3 System Components ................3 Safety Information ................. 4 Recycling Instructions ................5 Operating Instructions ................6 WIR TX240 ................. 6 WIR RX240 ................10 WIR RX250 ................12 In Case of Difficulty ................14 Warranty ..................... 15 System Specifications ................ -
Page 3: System Overview
System Overview Thank you for purchasing the TV Talker Infrared System from Williams Sound. Anyone needing auditory assistance to overcome background noise, reverberation, or distance from the sound source can benefit from the TV Talker Infrared System. You can use the TV Talker Infrared System for hearing assistance in conference rooms, listening to the TV, or with other audio equipment. -
Page 4: Safety Information
Safety Information HEARING SAFETY: CAUTION! This product is designed to amplify sounds to a high volume level which could potentially cause hearing damage if used improperly. To protect your hearing and the hearing of others: 1. Make sure the volume is turned down before putting on the earphone or headphone before adjusting the volume to a comfortable level. -
Page 5: Recycling Instructions
Recycling Instructions elp Williams Sound protect the environment! Please take the time to dispose of your equipment properly. Product Recycling for Customers in the European Union: Please do NOT dispose of your Williams Sound equipment in the household trash. - Page 6 Setting up the TX240 Transmitter NOTICE: THE RECHARGEABLE BATTERIES ARE SHIPPED IN A DIS- CHARGED STATE. THE BATTERIES MUST BE CHARGED OVERNIGHT BEFORE USING THE TV TALKER INFRARED SYSTEM. The WIR TX240 Transmitter may be placed on top of a TV or shelf. Place the TX240 Transmitter where it is clearly visible from your listening position.
- Page 7 TX240 Transmitter (Rear View) ❹ ❶ ❷ ❸ TV Microphone ❺ If an RCA connection is unavailable, use the provided TV microphone to pickup the sound source directly from the TV loud speaker as shown on left. Step 1: Connect the Transmitter Power Supply Plug the Power Supply cord into the “DC 12V”...
- Page 8 Step 2: (continued) NOTE: Some televisions have FIXED output and others have VARIABLE output. If available, FIXED output should be selected. Consult your television manual for more information. “Fixed” output means the volume on the television will not change when the volume is increased, decreased, or muted. “Variable” output means the volume on the television will change when it is increased, decreased, or muted.
- Page 9 Compatible with: 2.3 MHz (MONO) OPERATION: Connect the LEFT RCA plug from the TV or VCR audio output into the LEFT RCA jack on the TX240 Transmitter ❸ (the right jack should be left unplugged). Next, slide the stereo/ mono switch to the “O” mono position ➋ . The RX240 transmitter is now set for 2.3 MHz operation.
- Page 10 Setting up the RX240 Receiver Step 1: Install the Receiver Batteries Insert the rechargeable battery into the bottom of the RX240 Receiver (see page 11). Place the receiver into the charger cradle built into the top of the TX240 Transmitter and let charge overnight. The spare battery can be plugged into the charging port located on either side of the transmitter.
- Page 11 VOLUME CONTROL BATTERY (BAT AP07D) RX240 RECEIVER BALANCE CONTROL RX240 RECEIVER (BACK VIEW)
- Page 12 3. Turn the switch on your hearing aid to the “T” position and adjust the volume for comfortable listening when using induction loop feature. 4. If the sound is weak, increase the volume on the Williams Sound unit, then on your hearing aid.
- Page 13 NECKLOOP VOLUME CONTROL STEREO BATTERY HEADPHONE (BAT AP07D) JACK RX250 RECEIVER ON/OFF BALANCE SWITCH CONTROL RX250 RECEIVER (BACK VIEW)
- Page 14 9. If you are using the TV microphone and not getting a signal, try turning up the TV volume up slightly. Also, try positioning the TV mic directly over the TV speaker. 10. If the system still does not function, call Williams Sound at: 1-800-843-3544.
- Page 15 Williams Sound products are engineered, designed and manufactured under carefully controlled conditions to provide you with many years of reliable service. Williams Sound warrants the TV TALKER Infrared System against defects in materials and workmanship for TWO (2) years. During the first two years from the purchase date, we will promptly repair or replace the TV TALKER Infrared System.
- Page 16 If it is necessary to return the system for service, your Customer Service Representative will give you a Return Authorization Number (RA) and shipping instructions. Pack the system carefully and send it to: Williams Sound Attn: Repair Dept. 10300 Valley View Rd Eden Prairie, MN 55344...
-
Page 17: Wir Tx240
WIR 240, WIR 250 System Specifications: WIR TX240 Transmitter: Size, Weight, Color: 6.25"L x 4"W x 1.4"H (15.9cm x 10.2cm x 3.6cm), 170g, Gray Power Input: 12VDC (center is positive), 200 mA Class II wall transfomer TFP 042 Power Supply:... - Page 18 WIR RX240 Receiver: Weight: 55 g Material and Color: ABS plastic, Black Battery Type, Life: BAT AP07D NiMH Battery Pack, 7 hours Modulation Frequency: 2.3 and 2.8 MHz Frequency Response: 200 Hz to 8 kHz, ± 5dB Signal-to-Noise Ratio: 60 dB at 30ft (9m) Controls: Volume control thumbwheel;...
- Page 20 ©2011 Williams Sound MAN 147E...
