GE TBX18HACAA Dimension Manual

GE Appliances
TBX18HACWW—GE 17.6 Cu. Ft. Top-Freezer Refrigerator

Dimensions (in inches)

Front View
A B
Specification Created 2/00
Top View
H
G
C
D
VOLUME and
SHELF AREA
Manufacturer Certified to
ASSOCIATION OF HOME
APPLIANCE MANUFACTURERS
ANSI/AHAN HRF-1-1979
Height with hinge (in.) A
Height without hinge (in.) B
Depth without Doors (in.) C
Depth with Doors (in.) D
Depth plus Handle with Doors Closed (in.) E
Depth with Doors open 90° (in.) F
Width with Doors Closed (in.) G
E
Width with Doors open 90° (in.) H
Each side (in.)
F
Top (in.)
Back (in.)
Total volume and shelf
area are calculated by the Listed by
Association of Home
Underwriters
Appliance Manufacturers' Laboratories
R
standards.
For answers to your Monogram,
GE Profile Performance Series,
GE Profile ™ or GE appliance questions, call
GE Answer Center ® service, 800.626.2000.
®
C US
Today's GE refrigerators use about 50% as much
energy as refrigerator models made in 1980.
67-3/8
66-7/8
26-1/4
30
31-7/8
55-7/8
28
28-7/8
3/4
1
1
®
™
