GE TBX16SIBAA Dimension Manual

GE Appliances
TBX16SIBWW—"S" Series Top-Mount No-Frost Refrigerator

Dimensions (in inches)

Front View
A B
Created 2/98
Top View
H
G
C
D
Height with hinge (in.) A
Height without hinge (in.) B
Depth without Doors (in.) C
Depth with Doors (in.) D
Depth plus Handle with Doors Closed (in.) E
Depth with Doors open 90° (in.) F
Width with Doors Closed (in.) G
E
Width with Doors open 90° (in.) H
Each side (in.)
F
Top (in.)
Back (in.)
For answers to your Monogram,
Performance Series,
GE appliance questions, call
GE Answer Center
Total volume and shelf
VOLUME and
area are calculated by the
SHELF AREA
Association of Home
Manufacturer Certified to
Appliance Manufacturers'
ASSOCIATION OF HOME
APPLIANCE MANUFACTURERS
ANSI/AHAN HRF-1-1979
standards.
® GE Profile
™ GE Profile, ™ and
® service, 800.626.2000.
Listed by
Underwriters
Laboratories
R
67-1/4
66-3/4
26-1/2
29-1/8
30-7/8
54-3/4
28
30-1/8
3/4
1
1
