Summary of Contents for Microspace MSMVGA
- Page 1 TECHNICAL USER'S MANUAL FOR: PC/104 Peripheral boards MSMVGA 65545 based VGA/LCD controller #260399-1 Nordstrasse 11/F, CH-4542 Luterbach Tel.: ++41 (0)32 681 53 33 - Fax: ++41 (0)32 681 53 31...
-
Page 2: Revision History
DIGITAL-LOGIC AG MSMVGA Manual V1.0 COPYRIGHT 1998-1999 BY DIGITAL-LOGIC AG No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval system, in any form or by any means, electronic, mechanical, optical, manual, or otherwise, without the prior written permission of DIGITAL-LOGIC AG. -
Page 3: Table Of Contents
VGA-Connector Analog Interface for Monitors ............11 VGA Connector for Flatpanel Display..............12 ................13 UMPER OCATION ON THE OARD The Jumpers on this MICROSPACE product ............13 6.1.1 Flatpanel Interface ..................13 6.1.2 Standby the VGA Controller:................13 6.1.3 Selection of the BIOS Address................ 13 6.1.4... -
Page 4: Preface
MSMVGA Manual V1.0 REFACE This manual is for integrators and programmers of systems based on the MICROSPACE card family. It contains information on hardware requirements, interconnections, and details of how to program the system. The specifications given in this manual were correct at the time of printing; advances mean that some may have changed in the meantime. -
Page 5: Recycling Information
DIGITAL-LOGIC AG MSMVGA Manual V1.0 Recycling Information Hardware: - Print: epoxy with glass fiber wires are of tin-plated copper - Components: ceramics and alloys of gold, silver check your local electronic recycling Software: - no problems: re-use the diskette after formatting Technical Support 1. -
Page 6: Msmvga Specifications
DIGITAL-LOGIC AG MSMVGA Manual V1.0 MSMVGA S PECIFICATIONS 65545 from C&T Controller: VGA / LCD BIOS Enhanced BIOS: MultiBios Feature 1. CRT and MONO-LCD Type Sharp Mono LM64P8XX Default Panels: 2. CRT and TFT LCD Type Sharp TFT LQD011 and Toshiba TFT LTM9C015 3. -
Page 7: Vga, Lcd
DIGITAL-LOGIC AG MSMVGA Manual V1.0 VGA, LCD 3.1 VGA / LCD Controller 65540/45 The 65540 High Performance Flatpanel/CRT VGA controller High integrated design (flatpanel/CRT VGA controller, RAMDAC, clock synthesizer) Local Bus (32 Bit CPU) Flexible display memory configurations – Two... - Page 8 DIGITAL-LOGIC AG MSMVGA Manual V1.0 65545 Display Capabilities CRT Mode Mono LCD DD STN LCD 9-Bit TFT LCD Video Simultaneous 2, 3, 4 1, 2, 3, 4 Resolution Color Gray Scales Colors Colors Memory Display 320x200 256 /256K 61 / 61...
- Page 9 DIGITAL-LOGIC AG MSMVGA Manual V1.0 Supported VGA Modes Mode: Type: Colors: CRT: Text: Graphic: DRAM: Monitor: Refresh/HR: Text 40 x 25 320 x 200 256k 70 Hz Text 80 x 25 640 x 200 256k 70 Hz Graphic 40 x 25...
-
Page 10: Vga/Lcd Bios Support
1. Check the FP_LIST.PDF if the LCD BIOS is available. Get the latest VGA-BIOS at our webpage http://www.digitallogic.ch OFTWARE Available Drivers he MICROSPACE Application CD contains a lot of various drivers. CD:\drivers\display\vga45\ Drivers for Windows NT4.0 w95_vl Windows 95 VESA win311 Windows 3.11... -
Page 11: Description Of The Connectors
DIGITAL-LOGIC AG MSMVGA Manual V1.0 Description of the Connectors VGA-Connector Analog Interface for Monitors VGA-Connector MICROSPACE Product Signal Name Sub-D 15 pol MSMVGA/L Pin No. Header Pin No. VGA red VGA green VGA blue Horizontal Sync. Vertical Sync. Ground Bridge... -
Page 12: Vga Connector For Flatpanel Display
DIGITAL-LOGIC AG MSMVGA Manual V1.0 VGA Connector for Flatpanel Display LCD Connector VGA-LCD Interface (flatpanel signals): Signals P20-P23 are located on the J4M connector Signal Signal M-Signal (altern. DE) Line Pulse LP Switched VDD (5V/1A) Shift Clock Switched B’light (12V/1A) -
Page 13: Jumper Location On The Board
DIGITAL-LOGIC AG MSMVGA Manual V1.0 UMPER OCATION ON THE OARD The Jumpers on this MICROSPACE product 6.1.1 Flatpanel Interface Flatpanel Interface: 1 - 2 2 - 3 Flatpanel Interface: negative -35V positive +35V VEE-Polarity 6.1.2 Standby the VGA Controller: Standby the VGA Controller:... -
Page 14: Selection Of The Flash Sector
DIGITAL-LOGIC AG MSMVGA Manual V1.0 6.1.5 Selection of the Flash Sector (for using C800-CFFF, as alternate Flash-BIOS Memory, use the 64k-GAL. The standard implementation is 32k-GAL!) J18, J19 Selected Sector: Sector 1 (Default) open open Sector 2 closed open Sector 3... -
Page 15: Jumper Locations
DIGITAL-LOGIC AG MSMVGA Manual V1.0 Jumper Locations DIGITAL-LOGIC AG MSMVGA V1.0 JMP-LOCATION TOP-SIDE 0299 JM... -
Page 16: Special Peripherals , Configuration , Functions
DIGITAL-LOGIC AG MSMVGA Manual V1.0 PECIAL ERIPHERALS ONFIGURATION UNCTIONS Onboard BIAS Power generation (only on the MSMV104L) On the MSMV104L (low cost) board is no BIAS generator implemented. IMPORTANT: The onboard voltage generation must be adjusted and measured before the LCD panel is connected, otherwise the display may be destroyed. -
Page 17: Negative Voltage With 5V Input
DIGITAL-LOGIC AG MSMVGA Manual V1.0 7.1.3.2 Negative voltage with 5V input... -
Page 18: Possible Failures
DIGITAL-LOGIC AG MSMVGA Manual V1.0 OSSIBLE AILURES General LCD Failures Refer to the Flatpanel Manual by DIGITAL-LOGIC AG. 1. Check the LCD-BIOS. You have a special BIOS for every LCD. 2. Check the cable to the LCD. 3. Check the Jumper. -
Page 19: Index
DIGITAL-LOGIC AG MSMVGA Manual V1.0 NDEX 16-Bit CPU Interface:........... 14 Negative voltage with 5V input ......18 CRT Displays ............9 Positive voltage with 5V input ......17 Failures ..............19 Selection of the BIOS Address ......14 Flash-BIOS Memory, ........... 15 Selection of the Flash Sector.......
