Gasoline containing up to 10% ethanol (E10) is
acceptable for use in this machine. The use of any
gasoline exceeding 10% ethanol (E10) will void
the product warranty.
Operator Manual
RZ4222F BF / 967036501
Please read the operator's manual carefully and make sure you
understand the instructions before using the machine.

Advertisement

Table of Contents
loading

Related Manuals for Husqvarna RZ4222F

Summary of Contents for Husqvarna RZ4222F

  • Page 1 The use of any gasoline exceeding 10% ethanol (E10) will void the product warranty. RZ4222F BF / 967036501 Please read the operator’s manual carefully and make sure you understand the instructions before using the machine.
  • Page 2 When this product is worn out and no longer used, it should be returned to the reseller or other party for recycling. To implement improvements, specifications and designs can be altered without prior notification. Note that no legal demands can be placed based on the information contained in these instructions. Use only original parts for repairs.

  • Page 3: Table Of Contents

    CONTENTS INTRODUCTION ............... 5 Running ..............30 Driving and Transport on Public Roads ...... 5 Operating On Hills ............ 31 Towing ................. 5 Mowing Tips ............. 32 Operating ..............5 Stopping the Engine ..........33 Good Service .............. 6 Moving Machine By Hand ........34 SYMBOLS AND DECALS ..........
  • Page 4 WARNING! Failure to follow cautious operating practices can result in serious injury to the operator or other persons. The owner must understand these instructions, and must allow only trained persons who understand these instructions to operate the mower. Each person operating the mower must be of sound mind and body and must not be under the influence of any mind altering substance.

  • Page 5: Introduction

    INTRODUCTION Congratulations Towing Thank you for purchasing a Husqvarna ride-on If machine is equipped with a tow hitch, use extreme mower. This machine is built for superior efficiency caution when towing. Never allow children or others in to rapidly mow primarily large areas. A control panel or on the towed equipment.

  • Page 6: Good Service

    INTRODUCTION Good Service Husqvarna's products are sold only in specialized retail stores with complete service. This ensures that you as a customer receive only the best support and service. Before the product is delivered, the machine has, for example, been inspected and adjusted by your retailer.

  • Page 7: Symbols And Decals

    SYMBOLS AND DECALS These symbols are found on the machine and in the operator’s manual. Study them carefully so that you know what they mean. IMPORTANT INFORMATION WARNING! Xxxx xxxxxx xxxxx xxxx xxxxxxxxx xxxxxx Xxxx xxxxxx xxxxx xxxx xxxxxxxxx xxxxxxxxx. xx xxxxxxxx xxxx xxxxxx. xxxxxx xxxxxxxxx.
  • Page 8 SYMBOLS AND DECALS Shut off engine and remove key before performing any Keep a safe Read Operator’s maintenance or repair distance from the Use on slopes no Manual work machine greater than 10° No passengers Whole body Severing of fingers Do not open or Careful backing up, Careful going...

  • Page 9: Safety

    SAFETY Safety Instructions These instructions are for your safety. Read them carefully. WARNING! WARNING! THIS CUTTING MACHINE IS CAPABLE This symbol means that important OF AMPUTATING HANDS AND FEET safety instructions need to be AND THROWING OBJECTS. FAILURE emphasized. It concerns your safety. TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR...
  • Page 10 SAFETY • Disengage blades when not mowing. Shut off engine and wait for all parts to come to a complete stop before cleaning the machine, removing the grass catcher, or unclogging the discharge guard. • Operate machine only in daylight or good artificial light.

  • Page 11: Personal Safety Equipment

    SAFETY Personal Safety Equipment WARNING! When using the machine, approved personal protective equipment (shown in illustrations) shall be used. Personal protective equipment cannot eliminate the risk of injury but it will reduce the degree of injury if an accident does happen.
  • Page 12 SAFETY • Do not use on steep slopes. • Do not try to stabilize the machine by putting a foot on the ground. • Do not mow near drop-offs, ditches, or embankments. The machine could suddenly roll over if a wheel is over the edge or if the edge caves in.

  • Page 13: Safe Handling Of Gasoline

    SAFETY Safe Handling of Gasoline WARNING! The engine and the exhaust system become very hot during operation. There is risk for burns if touched. Allow engine and exhaust system to cool before refueling. To avoid personal injury or property damage, use extreme care in handling gasoline.

  • Page 14: General Maintenance

    SAFETY General Maintenance • Never operate machine in a closed area. • Keep all nuts and bolts tight to be sure the equipment is in safe working condition. • Never tamper with safety devices. Check their proper operation regularly. • Keep machine free of grass, leaves, or other debris buildup.
  • Page 15 SAFETY Sparking can occur when working with the battery and the heavy cables of the starter circuit. This can cause battery explosion, fire or eye injury. Sparking in this circuit can not occur after the chassis cable (normally negative, black) is removed from the battery. WARNING! Avoid electrical sparking and its consequences by the following...

  • Page 16: Towing

    Spark Arrestor WARNING! A spark arrestor for the muffler is available through any authorized Husqvarna dealer. This mower is equipped with an internal combustion engine and should not be used on or near any unimproved forested, bush covered...

  • Page 17: Controls

    CONTROLS This operator’s manual describes the Husqvarna driven hydraulic pumps. Using the left and right Zero Turn Rider. The rider is fitted with a four-stroke steering controls, the flow is regulated and thereby the overhead valve engine. direction and speed.

  • Page 18: Steering Control Levers

    CONTROLS Steering Control Levers The machine’s speed and direction are continuously variable using the two steering controls. The steering controls can be moved forward or backward about a neutral position. Furthermore, there is a neutral position, which is locked if the steering controls are moved outward.

  • Page 19: Parking Brake

    CONTROLS Parking Brake IMPORTANT INFORMATION The machine must be not be moving when engaging the parking brake. Always set the parking brake before dismounting. Release the parking brake before moving the mower. The parking brake is found on the left of the machine. Push the release button and pull the lever backward to activate the brake—push forward to release it.

  • Page 20: Ignition Switch

    CONTROLS Ignition Switch The ignition switch is placed on the control panel and is used to start and stop the engine. On models equipped with headlights, turn the key clockwise to ACCESSORY for headlight use. 8052-001 Ignition switch Choke Control The choke control is used for cold starts to provide the engine with a richer fuel mixture.

  • Page 21: Fuel Tank

    CONTROLS Fuel Tank Read the safety instructions before refueling. The machine has one fuel tank, just behind the console. The tank capacity is 3.5 gallons (13.25 liters). Regularly check the gas cap gasket for damage and keep the cap properly tightened. The engine will run on a minimum of 85-octane unleaded gasoline (no oil mix).

  • Page 22: Fuel Shut Off Valve

    CONTROLS Fuel Shut Off Valve The fuel shut off valve is located at the left rear of the seat. The valve is off when the handle tab is turned perpendicular to the fuel line. IMPORTANT INFORMATION Always raise the deck to the highest position for transport.

  • Page 23: Seat Adjustment Lever

    CONTROLS Seat Adjustment Lever The seat can be adjusted lengthways. When making adjustments, the lever under the right side of the seat is pulled up, after which the seat can be moved backward or forward. IMPORTANT INFORMATION Seat should not be adjusted while unit is in motion.

  • Page 24: Operation

    OPERATION Read the Safety section and following pages, if you To turn to the right are unfamiliar with the machine. While moving in a forward direction, pull the right lever back towards the neutral position while maintaining Training the position of the left lever, this will slow the rotation Due to unique steering capabilities, zero turn mowers of the right wheel and cause the machine to turn in are far more maneuverable than typical riding...

  • Page 25: Before Starting

    OPERATION Before Starting 1. Read the sections on Safety and Controls before starting the machine. 2. Perform the daily maintenance before starting (see Maintenance Schedule in the Maintenance section). 3. Check that there is sufficient fuel in the fuel tank. 4.

  • Page 26: Starting The Engine

    OPERATION Starting the Engine 1. Sit on the seat. 2. Raise the mower deck by pushing the release button on the top of the lifting lever. Pull the lifting lever backward to the locked (transport) position. 8058-019 Mower deck lifting lever 3.
  • Page 27 OPERATION 5. Move the steering controls outward to the locked (outer) neutral position. 8058-186 Place controls in neutral position 6. Move the throttle to the middle position. 8058-170 Set the throttle 7. If the engine is cold, the choke control should be pushed forward to the choke position.
  • Page 28 OPERATION 8. Press in and turn the ignition key to the start position. IMPORTANT INFORMATION Do not run the starter for more than 5 seconds each time. If the engine does not start, wait approximately 10 seconds before retrying. 8050-780 Turn to the start position 9.

  • Page 29: Jumper Cables Use

    OPERATION Weak Battery WARNING! Lead-acid batteries generate explosive gases. Keep sparks, flame and smoking materials away from batteries. Always wear eye protection when around batteries. IMPORTANT INFORMATION Your mower is equipped with a 12-volt negative grounded system. The other vehicle must also be a 12-volt negative grounded system.

  • Page 30: Running

    OPERATION Running 1. Release the parking brake by pushing the top release button in and moving the lever downward. NOTE: The mower is equipped with an operator presence system. When the engine is running, any attempt by the operator to leave the seat without first setting the parking brake will shut off the engine.

  • Page 31: Operating On Hills

    OPERATION Operating On Hills Read the Safety Instructions Driving on Slopes in the Safety section. WARNING! Do not drive up or down hills with slopes greater than 10 degrees. Do not drive across slopes. • The slowest speed possible should be used before starting up or down hills.

  • Page 32: Mowing Tips

    OPERATION Mowing Tips WARNING! • Observe and flag rocks and other fixed objects to avoid collisions. Clear the lawn of stones and other objects that can be thrown out by the • Begin with a high cutting height and reduce it blades.

  • Page 33: Stopping The Engine

    OPERATION Stopping the Engine 1. Move the throttle to the minimum position (tortoise symbol). 2. Move the steering controls outward. 3. Disengage the mower deck by pressing the blade switch down. 8058-173 Disengage the mower deck and move throttle to minimum 4.

  • Page 34: Moving Machine By Hand

    OPERATION Moving Machine By Hand When pushing or pulling the mower, engage the EZT bypass linkages. The EZT bypass linkages are located on the rear of the frame, below the rear engine guard. 1. Raise the deck into the highest cutting position.

  • Page 35: Maintenance

    MAINTENANCE Maintenance Schedule The following is a list of maintenance procedures that an authorized service workshop is recommended to must be performed on the machine. For those points maintain your machine in the best possible condition not described in this manual, visit an authorized and to ensure safe operation.
  • Page 36 MAINTENANCE Daily At least Maintenance once interval each in hours year MAINTENANCE Before After ■ Check/adjust throttle cable ● ● Check the condition of belts, belt pulleys ■ ■ Change the engine oil ■ ■ Replace the engine oil filter ■...

  • Page 37: Battery

    MAINTENANCE Battery STANDARD STATE APPROXIMATE BATTERY CHARGING TIME* TO FULL CHARGE AT 80 F / 27 Your mower is equipped with a maintenance free BATTERY Maximum Rate at: battery and does not need servicing. However, CHARGE 50 Amps 30 Amps 20 Amps 10 Amps periodic charging of the battery with an automotive...

  • Page 38: Safety System

    Visually check that no damage is found on the lever, links or switch belonging to the parking brake. Perform a standstill test and check that there is sufficient braking action. To adjust the parking brake, contact the Husqvarna service workshop. IMPORTANT INFORMATION The machine must be absolutely standing still when applying the parking brake.

  • Page 39: Tire Pressures

    MAINTENANCE Tire Pressures All tires should be at 15 psi / 103 kPa / 1 bar. 8011-564 Check tire pressures Caster Wheels Check every 200 hours. Check that wheels rotate freely. If wheels do not rotate freely take the unit to your dealer for service.

  • Page 40: V-Belts

    MAINTENANCE V-belts Check every 100 hours of operation. Check for severe cracking and large nicks. NOTE: The belt will show some small cracks in normal operation. The belts are not adjustable. Replace belts if they begin to slip from wear. Deck Belt 1.

  • Page 41: Cutting Blades

    4. Tighten blade bolt securely. 5. Torque blade bolt to 45-55 ft/lbs (60-75 Nm). IMPORTANT INFORMATION Special blade bolt is heat treated. Replace with a Husqvarna bolt if required. Do not use lower grade hardware than specified. 8050-844 Blade...

  • Page 42: Adjusting The Mower Deck

    MAINTENANCE Adjusting the Mower Deck Leveling deck Adjust the deck while the mower is on a level surface. Make sure the tires are inflated to the correct pressure. See Technical Data / Transmission. If tires are under or over inflated, the deck cannot be properly adjusted.

  • Page 43: Caster Wheels

    MAINTENANCE Cleaning IMPORTANT INFORMATION Regular cleaning, especially under the mower deck, will increase the machine’s life-span. Make it a habit to Use protective glasses when clean the machine directly after use (after it is cooled), cleaning and washing. before the debris sticks. Do not spray water on the top of the mower deck.

  • Page 44: Lubrication

    LUBRICATION Lubrication Schedule 8050-832 12/12 Every year Lubricate with grease gun Filter change 1/52 Every Week Oil change Level check 1/365 Every day General Remove the ignition key to prevent unintentional Wipe away excess grease after lubrication. movements during lubrication. It is important to avoid getting lubricant on the belts When lubricating with an oil can, it must be filled with or the drive surfaces on the belt pulleys.

  • Page 45: Wheel And Deck Zerks

    Lubricate with a grease gun, 2-3 strokes per spindle. 8058-136 Deck spindle Transmission The transmission is maintenance free with no need for level checks or oil changes. If a leak occurs, replace the unit or contact your Husqvarna dealer.

  • Page 46: Troubleshooting

    TROUBLESHOOTING Problem Cause Engine will not start • Blade switch is engaged. • Steering controls are not locked in the neutral position • Parking brake is not activated • Battery is dead • Contamination in the carburetor or fuel line. •...
  • Page 47 TROUBLESHOOTING Problem Cause Engine overheats • Clogged air intake or cooling fins • Engine overloaded • Poor ventilation around engine • Defective engine speed regulator • Too little or no oil in the engine • Contamination in the carburetor or fuel line. •...

  • Page 48: Storage

    Drain the fuel into an approved container outdoors and store Always use genuine Husqvarna spare parts. far away from open flame. Never use An annual check-up at an authorized service gasoline for cleaning. Use a degreaser workshop is a good way to ensure that your machine and warm water instead.

  • Page 49: Schematics

    SCHEMATICS...

  • Page 50: Technical Data

    TECHNICAL DATA Torque Specifications Engine crankshaft bolt 50 ft/lb (67 Nm) Standard ¼" fasteners 9 ft/lb (12 Nm) Deck pulley bolts 150 ft/lb (203 Nm) Standard " fasteners 18 ft/lb (25 Nm) Lug nuts 75 ft/lb (100 Nm) Standard " fasteners 33 ft/lb (44 Nm) Blade bolt 90 ft/lb (122 Nm)
  • Page 51 TECHNICAL DATA The power rating of the engines indi- RZ4222F BF / 967036501 cated is the average net power output Engine (at specified rpm) of a typical production engine for the engine model measured Manufacturer Briggs & Stratton to SAE standard J1349/ISO1585. Mass...

  • Page 52: Conformity Certificates

    CONFORMITY CERTIFICATES USA requirements Labels are placed on the engine and/or in the engine compartment stating that the machine will fulfill the requirements. This is also applicable to special requirements for any of the states, (California emission rules etc.). Do not remove any of these labels. Certificates can also be supplied with the machine at delivery or written in the Engine manual.

  • Page 53: Service Journal

    SERVICE JOURNAL Date, mtr reading, stamp, sign Action Delivery Service Charge the battery Adjust the tire pressure of all wheels to 15 PSI (1 bar) Mount the steering controls in the normal position Connect the contact box to the cable for the seat’s safety switch Check that the right amount of oil is in the engine Adjust the position of the steering controls Fill with fuel and open the fuel shut off valve...
  • Page 54 SERVICE JOURNAL SERVICE JOURNAL Date, mtr reading, stamp, sign Date, mtr reading, stamp, sign Action Action After the First 10 Hours Change engine oil Date, mtr reading, stamp, sign Action 25-Hour Service Check the fuel pump’s air filter Sharpen/Replace mower blades if required Check the tire pressures Check battery with cables Lubricate according to lubrication chart...
  • Page 55 SERVICE JOURNAL SERVICE JOURNAL Date, mtr reading, stamp, sign Date, mtr reading, stamp, sign Action Action 50-Hour Service Perform the 25-hour service Clean/replace the air cleaner’s filter cartridge (paper filter (shorter intervals for dusty operating conditions) Change engine oil Lubricate according to lubrication chart Check/adjust the parking brake Action Date, mtr reading, stamp, sign...
  • Page 56 SERVICE JOURNAL SERVICE JOURNAL Date, mtr reading, stamp, sign Date, mtr reading, stamp, sign Action Action 300-Hour Service Perform the 25-hour service Perform the 50-hour service Perform the 100-hour service Check/adjust the mower deck Clean the combustion chamber and grind the valve seats Check the engine valve clearance Replace the air cleaner’s pre-filter (foam) Date, mtr reading, stamp, sign...
  • Page 57 SERVICE JOURNAL Date, mtr reading, stamp, sign Action...
  • Page 58 SERVICE JOURNAL Date, mtr reading, stamp, sign Action...
