Tekvox TEK 1 User Manual

Ethernet-based mini control system
Hide thumbs Also See for TEK 1:
Table of Contents

Advertisement

Quick Links

Download this manual
TEK 1 User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TEK 1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tekvox TEK 1

Summary of Contents for Tekvox TEK 1

  • Page 1 TEK 1 User’s Manual...

  • Page 2: Table Of Contents

    Campus Network supports DHCP ......................19 Campus Network does not support DHCP ..................... 19 To set a static IP address on a TEK 1 using the serial port ..............19 Determining the Current IP Address ....................... 20 Wiring ................................. 21 Serial Port ...............................
  • Page 3 To Run a Macro ............................32 To Send an Email ........................... 32 Set Schedule On/Off: ..........................32 Device Commands ..........................33 TEK 1 Serial Port Commands ......................... 33 Specifications ............................34 Ethernet control interface ........................34 Serial control interface ..........................34 Logic Inputs .............................

  • Page 4: Copyright & Trademark

    V072412 Copyright & Trademark © Copyright 2006-2008 - TEKVOX, Inc. No part of the contents of this book may be transmitted or reproduced in any form or by any means without the written permission of TEKVOX, Inc. All rights reserved. This document was printed in the United States of America.

  • Page 5: Fcc Class B Notice

    TEK 1 User’s Manual V072412 FCC Class B Notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial or home environment.

  • Page 6: Warranty

    If it has been determined product is defective, please call TEKVOX and ask for an Applications Engineer at (210) 348-6565 (USA) to receive an RMA # (Return Material Authorization Number) to begin the repair process as quickly as possible.

  • Page 7: Introduction

    TEK 1 User’s Manual V072412 Introduction TekPatrol™ is a state-of-the-art asset management technology providing real-time supervision and control of any device with a serial connection and released protocol. Use TekPatrol to supervise devices and controlled areas for security and maintenance purposes. Our technology works in your classroom or office, providing control and security of your projector, plasma, other audio visual equipment, lights and computer equipment.

  • Page 8: Benefits

    TEK 1 User’s Manual V072412 Benefits • Improves equipment life by managing operational times • Reduces maintenance and energy costs • Adds reliable security to room devices • Improves equipment reliability • Increases administrator productivity • Easy to configure and install Features •...

  • Page 9: Description And Installation

    With a TEK 1 it is possible to monitor a device that only has IR control. For projectors that do report these timers, the TEK 1 reports both its own and the projector’s timers. The filter timer for the TEK 1 is called Maintenance timer.

  • Page 10: Rear Panel Features

    1. 24 volt connection: Use this power connection to power another device like an occupancy sensor or power the TEK 1 from another power source, like a power pack for an occupancy sensor. 2. Relay 1 and 2: 2 Amp Isolated contact closer. Use these relays for devices that require isolation, such as AC devices, or may draw larger currents.

  • Page 11: Applications

    TekWizard Template: TEKVOX – Standard In a standard configuration a TEK 1 is used to control and monitor a video projector or large screen display. The TEK 1 is installed in the ceiling and an RS-232 cable with a security wire is connected between the TEK 1 and projector.

  • Page 12: 12 Volt Security Alarm

    Other devices like the room’s PC and monitor can also be protected by TEK 1. This is accomplished by looping a security wire from one of the unused Logic Inputs on the TEK 1, through the PC and monitor, and then back to ground on the TEK 1. For someone to remove any of these monitored items they must first cut the security wire.

  • Page 13: Miniature 24 Volt Security Alarm

    When motion is detected, the occupancy detector triggers a high event on Input 2 of the TEK 1. Once motion is no longer detected, the occupancy detector triggers a low event on Input 2 of the TEK 1.
  • Page 14 TEK 1 the Digital Output is in an open state, causing the pull-up resistor to supply current to turn on the power pack. Once the TEK 1 is running, a command is issued to turn on this output causing the power pack to go off.

  • Page 15: Occupancy Detection, Lighting Control And Miniature Alarm

    Occupancy Detection, Lighting Control and Miniature Alarm TekWizard Template: TEKVOX – Occupancy2 As mentioned above the TEK 1 has the ability to operate with an occupancy detector. Since there is an extra logic output, a miniature alarm can be added to the TEK 1.

  • Page 16: Occupancy Detection, Lighting And Screen Control

    As mentioned above the TEK 1 has the ability to operate with an occupancy detector. Since there are two relays on the TEK 1, it is possible to control a projection screen or raise and lower a projector lift. Features •...

  • Page 17: Ir Control

    By adding a power current sensor at the display device the TEK 1 can determine if the device is powered on. Once the TEK 1 knows the device is on, the internal lamp and maintenance timers within the TEK 1 are operable.

  • Page 18: Installation

    The TEK 1 is designed with permanent side flanges and only requires #6 wood or metal screws. The TEK 1 should not be mounted on a monitored device and should not be easily visible. If the TEK 1 is stolen with the device, it cannot send an Email or set an alarm. Also the power supply should not be easily disconnected along with the projector.

  • Page 19: Configuring The Tek 1

    Configuring the TEK 1 For most installations all that is required is to connect a TEK 1 to the campus network is connect a live network cable and apply power. A DHCP server on the camps network automatically assign’s an IP address.

  • Page 20: Determining The Current Ip Address

    Settings in the Properties window. Another useful method is to use the PC serial connection as mentioned above. While pressing the lower case ‘x’ key apply power to the TEK 1. 2. Once a message is displayed, release the ‘x’ key and tap the Enter key.

  • Page 21: Wiring

    TEK 1, you should be able to register between 5 and 12 volts between Ground and the TX pin and Ground and RX pin on the TEK 1. Of course power must be on for both devices.
  • Page 22 TEK 1 User’s Manual V072412 Canon LV-7245 Mini Din-8P Direct TEK 1 Canon GND-----4 RX-------7 TX-------1 IN1------Shield TekSecurity Box TEK 1 TekSecurity TekSecurity Canon To TekMonitor To Device Mini Din-8P OUT1---WHT------1 GND-----BLK------2------------------------2------BLK-------4 TX-------RED------3------------------------3------RED-------1 RX------GRN------4------------------------4------GRN-------7 IN1 -----YEL-------5------------------------5------YEL-------Shield PU1-----BLU-------6 Canon SX-50 Mini Din-8P...
  • Page 23 TEK 1 User’s Manual V072412 Dell Mini Din-6P Direct TEK 1 Dell GND-----1 RX-------3 TX-------5 IN1------2 TekSecurity Box TEK 1 TekSecurity TekSecurity Dell To TekMonitor To Device Mini Din-6P OUT1---WHT------1 GND-----BLK------2------------------------2------BLK-------1 TX-------RED------3------------------------3------RED-------4 RX------GRN------4------------------------4------GRN-------3 IN1 -----YEL-------5------------------------5------YEL-------2 PU1-----BLU-------6 Epson DB-9 FM Direct...
  • Page 24 TEK 1 User’s Manual V072412 Hitachi DB-9 FM Direct TEK 1 Hitachi GND-----5 RX-------3 TX-------2 IN1------Shield TekSecurity Box TEK 1 TekSecurity TekSecurity Hitachi To TekMonitor To Device DB-9 FM OUT1---WHT------1 GND-----BLK------2------------------------2------BLK-------5 TX-------RED------3------------------------3------RED-------2 RX------GRN------4------------------------4------GRN-------3 IN1 -----YEL-------5------------------------5------YEL-------Shield PU1-----BLU-------6 Mitsubishi Mini Din-8P Direct...
  • Page 25 TEK 1 User’s Manual V072412 NEC DB-9 FM (LCD/Plasma) Direct TEK 1 NEC GND-----5 RX-------3 TX-------2 IN1------Shield TekSecurity Box TEK 1 TekSecurity TekSecurity To TekMonitor To Device DB-9 FM OUT1---WHT------1 GND-----BLK------2------------------------2------BLK-------5 TX-------RED------3------------------------3------RED-------2 RX------GRN------4------------------------4------GRN-------3 IN1 -----YEL-------5------------------------5------YEL-------Shield PU1-----BLU-------6 NEC Mini Din-8P (Projector)
  • Page 26 TEK 1 User’s Manual V072412 Sampo DB-9 FM Direct TEK 1 Sampo GND-----5 RX-------2 TX-------3 IN1------Shield TekSecurity Box TEK 1 TekSecurity TekSecurity Hitachi To TekMonitor To Device DB-9 FM OUT1---WHT------1 GND-----BLK------2------------------------2------BLK-------5 TX-------RED------3------------------------3------RED-------3 RX------GRN------4------------------------4------GRN-------2 IN1 -----YEL-------5------------------------5------YEL-------Shield PU1-----BLU-------6 Sanyo Mini Din-8P Direct...
  • Page 27 TEK 1 User’s Manual V072412 Sony DB-9 M Direct TEK 1 Sony GND-----5 RX-------3 TX-------2 IN1------Shield TekSecurity Box TEK 1 TekSecurity TekSecurity Sony To TekMonitor To Device DB-9 M OUT1---WHT------1 GND-----BLK------2------------------------2------BLK-------5 TX-------RED------3------------------------3------RED-------2 RX------GRN------4------------------------4------GRN-------3 IN1 -----YEL-------5------------------------5------YEL-------Shield PU1-----BLU-------6 Toshiba Mini Din-8P Direct...

  • Page 28: Lan Connection

    TEK 1 User’s Manual V072412 LAN Connection Straight-through cable Side 1 Side 2 Wire color Pin Wire color White-orange White-orange Orange Orange White-green White-green Blue Blue White-blue White-blue Green Green White-brown White-brown Brown Brown * These pins are not used www.tekvox.com...

  • Page 29: Diagnostics - Telnet

    TekManager. Since a control system cannot perform auto-discovery to locate a TEK 1, it is necessary to configure the TEK 1 using a static IP address or at least make certain that the IP address cannot change. There are several benefits to communicating with the TEK 1 instead of the display device.

  • Page 30: Protocol

    • If Device Control <= 255, Here Is Device Control End command plus data. If the TEK 1 detects a change in its’ Device Control data, it sends a Here Is All Device Control Group command plus new data. Commands: 0.
  • Page 31 TEK 1 User’s Manual V072412 Communications status codes (COMSTAT): 0. No error 1. Invalid data 2. Invalid command code 3. Device locked (Future) 4. Checksum error 5. Busy 6. Too Much Data 7. Data End 8. Not My Serial Number 9.

  • Page 32: Server Commands

    TEK 1 User’s Manual V072412 Server Commands Command Name Bytes Return Len / S00(17)1 Enable Security 1 byte Value (0/1 1=Enabled) S00(18)1 Enable Usage Report 1 byte Value (0/1 1=Enabled) S00(19)1 Enable Error Messages 1 byte Value (0/1 1=Enabled) S00(20)1...

  • Page 33: Device Commands

    Device Commands Port values Each device command must reference a port. The Port Port Name Port Name value refers to the system, input or output on the TEK 1. System Input 1 Input 2 Relay 1 Input 3 Relay 2...

  • Page 34: Specifications

    TEK 1 User’s Manual V072412 Specifications Ethernet control interface Connectors ............1 - RJ-45 male connector Data rate............... 10/100Base-T, half/full duplex with auto sensing Protocols .............. DHCP, ICMP (ping), TCP/IP, UDP, Telnet, SMTP Default settings ............ Link speed and duplex level are set to auto sensing.

  • Page 35: Architectural Specifications

    ICES-003. The device shall feature an external power supply capable of operating from 100 to 240 VAC, 47-63 Hz. The external power supply shall be UL/CUL certified. The unit shall be a TEKVOX TEK 1 TekMonitor. www.tekvox.com TEKVOX, Inc. – 210.348.6565 –...
