User Manual for the
HE693SNPMPX
SNP Multiplexer for
GE Fanuc Series 90
PLCs
Third Edition
29 November 2000
MAN0080-03

Advertisement

loading
Need help?

Need help?

Do you have a question about the HE693SNPMPX and is the answer not in the manual?

Questions and answers

Summary of Contents for HORNER HE693SNPMPX

  • Page 1 User Manual for the HE693SNPMPX SNP Multiplexer for GE Fanuc Series 90 PLCs Third Edition 29 November 2000 MAN0080-03...
  • Page 3 SERIAL NUMBER: WARRANTY REGISTRATION FORM Please fill out this form and return it to Horner APG. This information is vital to Horner APG, should warranty service be required. This document is also used to keep you informed of new product enhancements, software revisions and documentation updates.
  • Page 4 PAGE 4 29 NOV 2000 MAN0080-02 FOLD STAMP Horner APG, LLC. APG - Controls Division 640 North Sherman Drive Indianapolis, Indiana 46201 ATTN: Warranty Registration Department FOLD...
  • Page 5: Preface

    PAGE 5 PREFACE This manual explains how to use the Horner APG SNP Multiplexer for use with the GE Fanuc Series 90 family of Programmable Logic Controllers. Copyright (C) 2000 Horner APG, LLC., 640 North Sherman Drive Indianapolis, Indiana 46201. All rights reserved.
  • Page 6: About Programming Examples

    Due to the many variables and requirements associated with any particular installation, Horner APG cannot assume responsibility or liability for actual use based on the examples and diagrams. It is the sole responsibility of the system designer utilizing the SNP Multiplexer...
  • Page 7: Revisions To This Manual

    PAGE 7 Revisions to This Manual This version (MAN0080-02) of the SNP Multiplexer User Manual contains the following revisions, additions and deletions: 1. Converted manual into Word format. 2. Changed company name from Horner Electric, Inc. to Horner APG, LLC.
  • Page 8 PAGE 8 29 NOV 2000 MAN0080-02...
  • Page 9: Table Of Contents

    MAN0080-02 29 NOV 2000 PAGE 9 Table of Contents PREFACE..............................5 ABOUT PROGRAMMING EXAMPLES ....................6 Revisions to This Manual .........................7 CHAPTER 1: INTRODUCTION ......................11 CHAPTER 2: INSTALLATION.......................13 CHAPTER 3: POWER CONNECTIONS....................15 CHAPTER 4: OPERATION ........................17...
  • Page 10 PAGE 10 29 NOV 2000 MAN0080-02 NOTES...
  • Page 11: Chapter 1: Introduction

    CH. 1 CHAPTER 1: INTRODUCTION The Horner APG SNP Multiplexer (SNPM) is equipped with three (3) RS485 serial ports. Two of these ports have been designed for direct connection to SNP "Master" devices (i.e. Workmaster or an Operator Interface Unit), while the third port is designed for direct connection to a Series 90 CPU programming port.
  • Page 12 PAGE 12 29 NOV 2000 MAN0080-02 CH. 1 NOTES...
  • Page 13: Chapter 2: Installation

    MAN0080-02 29 NOV 2000 PAGE 13 CH. 2 CHAPTER 2: INSTALLATION The SNP Multiplexer can be panel mounted or used as a desktop accessory. An optional 15-pin cable is available for connection between the SNPM master port and the Series 90 programming port. The pin- out for the two slave ports is identical to that of a Series 90 programming port, therefore, any cables used for connection to the Series 90 can be connected to either SNPM slave port.
  • Page 14 PAGE 14 29 NOV 2000 MAN0080-02 CH. 2 NOTES...
  • Page 15: Chapter 3: Power Connections

    A device is to be connected to one (or both) of the slave ports that requires the +5VDC power on the slave port connector (i.e. the Horner APG Operator Interface Unit, or the Horner APG Thumbwheel Interface Unit).
  • Page 16 PAGE 16 29 NOV 2000 MAN0080-02 CH. 3 NOTES...
  • Page 17: Chapter 4: Operation

    MAN0080-02 29 NOV 2000 PAGE 17 CHAPTER 4: OPERATION With the SNPM installation and configuration complete, the SNPM can now be powered-up. The SNPM is equipped with two LED's, one near each slave port. At power-up, both LEDs will light during the SNPM internal initialization and diagnostics.
  • Page 18 PAGE 18 29 NOV 2000 MAN0080-02 Figure 4.1 – Cable Diagram...
