4.0 Functions
Use (-) and (+) to set F1, F2, F3, A1, A2 and A3.
F1, F2 and F3 turn on Fan Speed 1, 2 and 3 respectively and give 'Fan only'
operation with no temperature control.
° °
A1, A2 and A3 turn on Fan Speed 1, 2 and 3 respectively, but only if the water
temperature is correct. (Please refer to your installation manual for full details).
Press (OK) to confirm the desired setting.
The iVECTOR will run indefinitely in Comfort Setting, providing automatic control
of the fan speed according to the difference between the set temperature and
the actual temperature.
° ° The room temperature and the time are displayed at all times. Press (OK) to view
the set temperature.
The comfort temperature can be adjusted for this zone by using the (+) and (-)
keys. (The default setting is 21°C).
The iVECTOR, when set in AUTO, will follow your chosen programme. Refer
to section 12 of your installation guide for programme options and set-up.
Auto
°
The room temperature and the time are displayed at all times.
Press (OK) to view the actual temperature in either the comfort or set-back modes.
The iVECTOR will run indefinitely in Set-back.
The room temperature and the time are displayed constantly. Press (OK) to view
°
set temperature and actual time. To reduce or increase the temperature in this
zone press the (+) and (-) keys. (The default setting is 19°C).
To access this setting set the control to the symbol
displayed. Adjust the period duration by pressing (+) and (-) keys. (In hours "H"
or, if greater than 24 hours then choose days "D").
The counter will decrease to "00". When the period is finished the thermostat
°
will return automatically to the AUTO setting.
To interrupt this period, adjust the duration to "no" with the minus (-) key.
The temperature applied during this time will be 7°C in winter and 30°C
in summer.
Turns iVECTOR on and off as required.
° °
Used to adjust the time and day.
Press (OK), then adjust the minute with (+) and (-) keys. Press (OK) to confirm,
° °
then adjust the hour with (+) and (-) keys. Press (OK) to confirm.
Adjust the day by pressing the (+) and (-) keys. Press (OK) to confirm.
Provides choice of 9 pre-programmed options and 4 user defined programmes.
P
°
Please refer to section 12 in your installation guide for more information.
