RGBHV Video with Stereo Audio
Receiver Card for Pioneer PDPs
(with optical loop-through)
Receiver Model 7235
USER'S MANUAL
WORLD HEADQUARTERS
55 Cabot Court
Hauppauge, N.Y. 11788 USA
Tel: (631) 273-0404
Fax: (631) 273-1638
www.commspecial.com
Email:
info@commspecial.com
Communications Specialties Pte Ltd
100 Beach Road
#22-09 Shaw Tower
Singapore 189702
Tel: +65 6391 8790
Fax: +65 6396 0138
Email:
csiasia@commspecial.com
P/N: 123412 Rev. B
Advertisement
Table of Contents
Summary of Contents for Pure Digital Fiberlink 7235
- Page 1 RGBHV Video with Stereo Audio Receiver Card for Pioneer PDPs (with optical loop-through) Receiver Model 7235 USER’S MANUAL WORLD HEADQUARTERS 55 Cabot Court Hauppauge, N.Y. 11788 USA Tel: (631) 273-0404 Fax: (631) 273-1638 www.commspecial.com Email: info@commspecial.com Communications Specialties Pte Ltd 100 Beach Road #22-09 Shaw Tower Singapore 189702...
-
Page 2: Table Of Contents
CONTENTS General Information ........... 3 Introduction ............3 Technical Specifications ......... 3 Installation Instructions ..........5 Installation Procedure ..........5 System Connections ..........8 Indicator LEDs ............9 Operating Pointers and Troubleshooting ....10 Maintenance and Repairs ......... 11 Limited Warranty ............. 12... -
Page 3: General Information
Pioneer Display Panels* (PDPs), allowing the PDP to directly receive signals over one fiber from any Pure Digital Fiberlink 7220 Series transmitter, repeater or 8000/8100 Series O.D.A. It operates at 1310 nm wavelength and works with either single mode or multimode fiber. - Page 4 Number of Baseband RGBHV Video Outputs ... 1 internal PDP, 1 external RGB Format Supported .... RGB with separate H and V External Signal Connectors ..HD-15F RGB Processing ....... 24 bits, no compression or scaling Audio: Number of Audio Channels Supported ....
-
Page 5: Installation Procedure
Operating loss budget must not be exceeded. DANGER! The transmitting element in the Pure Digital Fiberlink 7235 receiver card contains a solid state Laser Diode located within the optical loop-through output connector. The laser emits invisible infrared electromagnetic radiation which can be harmful to human eyes. -
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS The following instructions explain how to: ® 1. Install the Pure Digital Fiberlink 7235 plug-in card into the expansion slot within a Pioneer PDP 2. Make fiber connections between the 7235 card and a 7220 Series transmitter 3. Operate the system. - Page 7 6. This product is not manufactured for repeated insertion and extrac- tion. Please be especially careful when inserting or extracting the product from the PDP. Inserting the Card: 1. Remove and save the screws at both ends of the slot cover, located on the bottom of the Pioneer PDP.
-
Page 8: System Connections
The system is operational if you see the video and hear the audio from the 7235 receiver card. System Connections: ® The external output connections for the Pure Digital Fiberlink 7235 model are as follows: Audio Connector OUTPUT: 2 position RCA jack... -
Page 9: Indicator Leds
Indicator LEDs: ® The Pure Digital Fiberlink 7235 receiver has four integral indicator LEDs that are used to monitor the state of the unit. The status of the LEDs are as follows: Power: ON: (GREEN) Indicates that correct power has been applied. -
Page 10: Operating Pointers And Troubleshooting
OPERATING POINTERS AND TROUBLESHOOTING Optical Fiber: The 7235 receiver card operates with most multimode (MM) and single mode (SM) optical fibers. All models within the 7220 Series use the same 1310 nm wavelength and optics for transmitting over multi- mode or single mode fiber, but be aware that the type of fiber you use will affect the system’s loss budget and the maximum transmission dis- tance that it can support. -
Page 11: Maintenance And Repairs
MAINTENANCE AND REPAIRS ® The Pure Digital Fiberlink 7235 receiver card has been manufac- tured using the latest semiconductor devices and techniques that elec- tronic technology has to offer. It has been designed for long, reliable and trouble-free service and are not normally field repairable. Should... -
Page 12: Limited Warranty
Communications Specialties, Inc. (CSI) warrants that for a period of ® three years after purchase by the Buyer, the Pure Digital Fiberlink 7235 receiver will be free from defects in material and workmanship under normal use and service. A Return Material Authorization (RMA) number must be obtained from CSI before any equipment is returned by the Buyer.
