Wadia 7 Information & Operation Manual

Compact disc transport
Hide thumbs
Table of Contents

Advertisement

Quick Links

INFORMATION AND OPERATING MANUAL VWia 7 CD TRANSPORT
DIGITAL
CORPORATION

Advertisement

Table of Contents
loading

Related Manuals for Wadia 7

Summary of Contents for Wadia 7

  • Page 1 INFORMATION AND OPERATING MANUAL VWia 7 CD TRANSPORT DIGITAL CORPORATION...
  • Page 3 CAUTION TO REDUCE THE RISK OF FIRE OR ELECTRICAL SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. TO REDUCE THE RISK OF ELECTRICAL SHOCK, DO NOT REMOVE THE PRODUCT’S COVER. THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL.

  • Page 5: Table Of Contents

    REAR PANEL................I4 UNPACKING.................I6 SET-UP AND INSTALLATION ............ .I6 BASIC OPERATION ..............I 7 DISC PRECAUTIONS ..............7 AC POWER CONNECTION ............I7 CARE AND MAINTENANCE............7 SERVICE..................WARRANTY .................I8 SPECIFICATIONS ............... .I9...

  • Page 6: Important Safety Instructions

    35. IMPORTANT SAFETY INSTRUCTIONS To get the best performance from your Wadia 7 Compact Disc Transport, and for your own safety, please read and follow these important safety instructions. Before operating the Wadia 7 Compact Disc Transport please read all operating and safety instructions.
  • Page 7 12) The Wadia 7 Compact Disc Transport is meant to be turned on, and left on, at all times. However, if this product won’t be used for a long period of time, you should turn it off and disconnect the power cord.

  • Page 8: Front Panel

    Wadia 7 CD TRANSPORT FRONT PANEL The front panel of the Wadia 7 Compact Disc Transport is simple and elegant, with only two push buttons, two LED indicators, and a display window. All other functions are accessed through the remote control.
  • Page 9 CD TRANSPORT Wadia 7 OPEN / CLOSE: Pressing this button opens the disc drawer; pressing it again closes the drawer. Pressing this button while a compact disc is playing stops play, clears any previously programmed sequence of tracks, and opens the drawer.

  • Page 10: Remote Control

    R E M O T E C O N T R O L The Remote Control for the Wadia 7 CD Transport also includes the remote control commands for the Wadia 9 Decoding Computer, the Wadia 10 Glass Optical Interface, and the Wadia 5 PowerDAC.
  • Page 11 Wadia 7 CD TRANSPORT PROGRAM: Pressing this button enters all tracks subsequently chosen with the numeric keys (up to a total of 40 selections) as part of a programmed sequence, for playback in any desired order. Programming a sequence of tracks can be done either in the STOP mode or in the PLAY mode.
  • Page 12 (for example 0 followed by 4 will access Index Point 4; iO+ followed by 7 will access Index Point 17, etc.) CHECK: When a sequence of tracks has been programmed, the CHECK button can be used to review the contents of that program.
  • Page 13 WADIA 7 DISPLAY ON & OFF: These buttons allow you to extinguish and re-illuminate the display at your will. When the Wadia 7 Display is in the OFF position, any selection from the remote control that activates the display will illuminate the display window for approximately 5 seconds, after which it will once again extinguish itself.

  • Page 14: Rear Panel

    REAR PANELS POWER ON / OFF: On the rear of the Wadia 7 Power Supply is a switch that turns the Wadia 7 Compact Disc Transport on and off. The switch must be in the ON position for the product to function.
  • Page 15 The AES/EBU format is provided through an XLR type connector. When using this method of digital transmission, be sure that the pin configuration on the associated equipment matches that of the Wadia 7 Compact Disc Transport (Pin 1: Ground, Pin 2: Not Inverted Signal, Pin 3: Inverted Signal).

  • Page 16: Unpacking

    Wadia 7, be sure to reset the transport screw to the position in which you received it. 4) While the Wadia 7 Compact Disc Transport is still on its side, screw in the four pointed feet into the bottoms of the four corner posts. Similarly, screw in the four pointed feet into the bottoms of the four corner posts on the Wadia 7 Power Supply.

  • Page 17: Basic Operation

    Unplug the unit immediately if it becomes wet. CARE AND MAINTENANCE To clean the Wadia 7 Compact Disc Transport, use a soft cloth moistened with plain water. Don’t apply water, dusting sprays, solvents, abrasives, or cleaning fluids directly to the chassis.

  • Page 18: Warranty

    Wadia 7 Compact Disc Transport. Wadia Digital will not pay for loss of use or inconvenience caused by the failure of a Wadia 7 Compact Disc Transport. Wadia Digital will not pay for damage caused to other audio components caused by the failure of a Wadia 7 Compact Disc Transport within the limits allowed by State Law.

  • Page 19: Specifications

    CD TRANSPORT Wadia 7 SPECIFICATIONS CD Stability Vibration-Free Rigid Disc Clamping System (VRDS) CD Pickup Mechanical 3-beam, objective lens drive, 780 nm wavelength 2-dimensional parallel drive Machined Cast-alloy turntable Precision Servo-sled tracking mechanism Floating suspension system Pickup Drive Method Linear motor drive.
  • Page 22 624 TROY STREET, RIVER FALLS, WI 54022 (715) 426-5900 FAX (715) 426-5665...
