Page 1: Illustrated Parts List
ILLUSTRATED PARTS LIST MODEL NO. 96012004401 CUSTOMER CATALOG NO. PB1638LT PRODUCT NO. 960 12 00-44 401536 Rev.1 10.12.06 TR/VB... -
Page 2: Repair Parts
REPAIR PARTS TRACTOR - - MODEL NUMBER PB1638LT (96012004401). PRODUCT NO. 960 12 00-44 DECALS PART PART DESCRIPTION DESCRIPTION 181251 Decal, Clutch Brake 194543 Decal, Hood RH 401492 Decal, Replacement 194544 Decal, Hood LH 189683 Decal, Engine HP 145005 Decal, Caution, Battery... - Page 3 TRACTOR - - MODEL NUMBER PB1638LT (96012004401). PRODUCT NO. 960 12 00-44 SCHEMATIC BATTERY STARTER FUSE AMMETER (OPTIONAL) WHITE CLUTCH / BRAKE ATTACHMENT CLUTCH (PEDAL UP) (CLUTCH OFF) BLACK BLACK SEAT SWITCH (NOT OCCUPIED) BLACK BLACK GRAY GRAY REVERSE SWITCH...
- Page 4 REPAIR PARTS TRACTOR - - MODEL NUMBER PB1638LT (96012004401). PRODUCT NO. 960 12 00-44 ELECTRICAL 197428...
- Page 5 REPAIR PARTS TRACTOR - - MODEL NUMBER PB1638LT (96012004401). PRODUCT NO. 960 12 00-44 ELECTRICAL PART DESCRIPTION 163465 Battery 74760412 Bolt Hex Hd 1/4-20 unc x 3/4 176689 Box Battery 176138 Switch Interlock 175688 Harness Asm Light W/4152j 4152J Bulb Light #1156 4799J Cable Battery 6 Ga.
- Page 6 REPAIR PARTS TRACTOR - - MODEL NUMBER PB1638LT (96012004401). PRODUCT NO. 960 12 00-44 CHASSIS Chassis-Alpha_Stlt_2...
- Page 7 REPAIR PARTS TRACTOR - - MODEL NUMBER PB1638LT (96012004401). PRODUCT NO. 960 12 00-44 CHASSIS PART DESCRIPTION 174619 Chassis 176554 Drawbar, Stretch 155272 Bumper, Hood/Dash 193510X010 Dash 72140608 Bolt, Carriage 3/8-16 x 1 174996 Panel Dash LH 172105X010 Panel Slkscr Dash RH...
- Page 8 REPAIR PARTS TRACTOR - - MODEL NUMBER PB1638LT (96012004401). PRODUCT NO. 960 12 00-44 DRIVE drive-fender.stlt_46...
- Page 9 REPAIR PARTS TRACTOR - - MODEL NUMBER PB1638LT (96012004401). PRODUCT NO. 960 12 00-44 DRIVE PART PART DESCRIPTION DESCRIPTION - - - - - - Transaxle Dana D4360-139 175410 Pulley, Engine (See Breakdown) 173937 Bolt Hex 7/16-20 x 4 Gr. 5-1.5...
- Page 10 REPAIR PARTS TRACTOR - - MODEL NUMBER PB1638LT (96012004401). PRODUCT NO. 960 12 00-44 STEERING steering_pl.lt_58...
- Page 11 REPAIR PARTS TRACTOR - - MODEL NUMBER PB1638LT (96012004401). PRODUCT NO. 960 12 00-44 STEERING PART DESCRIPTION 186780 Wheel Steering 175131 Axle Asm 169840 Spindle Asm LH 169839 Spindle Asm RH 6266H Bearing Race Thrust Harden 121748X Washer 25/32 x 1-5/8 x 16 Ga.
- Page 12 REPAIR PARTS TRACTOR - - MODEL NUMBER PB1638LT (96012004401). PRODUCT NO. 960 12 00-44 ENGINE OPTIONAL EQUIPMENT Spark Arrester engine-bs.1cyl_49 PART PART DESCRIPTION DESCRIPTION 170551 Control Th/ch Flag 17000612 Screw Hex Wsh Thdrol 3/8-16 17720408 Screw Hex Thd Cut 1/4-20 x 1/2 19091416 Washer 9/32 x 7/8 x 16 Ga.
- Page 13 REPAIR PARTS TRACTOR - - MODEL NUMBER PB1638LT (96012004401). PRODUCT NO. 960 12 00-44 SEAT seat_lt.bolt_9 PART PART DESCRIPTION DESCRIPTION 401042 Seat 72050412 Bolt Rdhd Sht Nk 1/4 - 20 x 1 -1/2 140551 Bracket Seat Pivot 134300 Spacer Split .28 x .96...
- Page 14 REPAIR PARTS TRACTOR - - MODEL NUMBER PB1638LT (96012004401). PRODUCT NO. 960 12 00-44 MOWER DECK 38_deck-manual_4...
- Page 15 REPAIR PARTS TRACTOR - - MODEL NUMBER PB1638LT (96012004401). PRODUCT NO. 960 12 00-44 MOWER DECK PART PART DESCRIPTION DESCRIPTION 192556 Mower Housing Assembly 193214 V-Belt 72140506 Bolt Carriage 5/16-18 x 3/4 193216 Spring Brake Return 138017 Bracket Asm Fr. Sway Bar 19131311 Washer 13/32 x 13/16 x 11 Ga.
- Page 16 REPAIR PARTS TRACTOR - - MODEL NUMBER PB1638LT (96012004401). PRODUCT NO. 960 12 00-44 MOWER LIFT 16 17 lift-rh.1piece_3 PART PART DESCRIPTION DESCRIPTION 159460 Wire Asm Inner/Sprg w/plunger 173288 Link Front 159471 Shaft Asm Lift RH 73350800 Nut Jam Hex 1/2-13 unc...
