GE Profile PGB900DEMBB Dimensions And Installation Information

26-1/4"
PGB900DEM
46-3/8"
GE Profile 30" Free-Standing Gas Range
™
Dimensions and Installation Information (in inches)
*Note: Dimension from the wall to the front
of the closed door handle is 29". Depth to
front edge of cooktop 25-1/4".
Electrical Rating: 120V, 60Hz, 5A
Installation Information: Before installing,
consult installation instructions packed
with product for current dimensional data.
For answers to your Monogram, GE Profile
®
GE appliance questions, visit our website at
®
ge.com or call GE Answer Center
®
800.626.2000.
Installation Information (Dimensions in inches)
30"
47-3/16"
26-1/4"
46-3/8"
or
™
service,
30" FS Gas Ranges-CL
Recommended area for
120V outlet on rear wall
and area for thru the wall
connection of pipe stub
and shut-off valve
4
+ _
36-1/4" 1/4
9
Recommended common
area for gas outlet and
electrical outlet
30
2-1/2
8
24
2
C L
Recommended area for
thru the floor connection
of pipe stub and shut-off valve
Recommended area for
120V outlet on rear wall
and area for thru the wall
8
connection of pipe stub
All GE ranges are equipped with
an Anti-Tip device. The installation
and shut-off valve
of this device is an important,
required step in the installation
of the range.
4
Specification Created 5/07
230581
Re
ar
ele
30
2-1/2
24
2
