Virtual Reality VRCD300M Instruction & Owner's Manual

Am/fm stereo cd/cd-r/ cd-rw/mp3/wma player

Advertisement

VRCD300M
Instructions / Owner's Manual
AUX In
CD
CD/R
CD/RW
MP3
ID3
WMA
AM/FM Stereo
CD/CD-R/ CD-RW/MP3/WMA PLAYER
1 80
WATTS*


Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VRCD300M and is the answer not in the manual?

Questions and answers

Summary of Contents for Virtual Reality VRCD300M

  • Page 1 VRCD300M Instructions / Owner’s Manual AUX In CD/R CD/RW AM/FM Stereo CD/CD-R/ CD-RW/MP3/WMA PLAYER 1 80 WATTS*...
  • Page 3: Table Of Contents

    In the rare event that your VRCD300M is missing an item, contains a damaged part, does not perform as specified, requires warranty service, or you have an installation problem, DO NOT RETURN THIS PRODUCT TO THE STORE.
  • Page 4: Precautions

    PRECAUTIONS Please read these important precautions BEFORE attempting to install this unit. Driving a vehicle while operating this head unit may violate motor vehicle laws, and may result in serious injury, property damage, or death! • Disconnect the vehicle’s negative bat- •...
  • Page 5: Care Of Discs

    Care of Discs • Do not operate the player with scratched, bent or broken discs. discs. When a disc does not load properly, do not force it into the disc loader. • Never insert any foreign objects such as coins, pins, credit or ATM cards into the disc loader, this will damage the loading mechanism or cause it short circuit.
  • Page 6: Before You Install

    Contact the vehicle's manufacturer for vehicle specific instructions, or consider having the VRCD300M professionally installed. Tools Needed to Install Below are the basic tools needed for most installations. Depending on the vehicle you may need other tools to complete the installation.
  • Page 7: Marine Enclosure Installation

    Marine Enclosure Installation IMPORTANT! BEFORE THE FINAL INSTALLATION OF THE HEAD UNIT, CONNECT THE WIRING TEMPORARILY, MAKING SURE THE UNIT AND THE SYSTEM WORK PROPERLY. The Marine Enclosure can be mounted two ways. On top of or below the mounting surface. Top Mount Bottom Mount .
  • Page 8: Vehicle Installation

    Vehicle Installation Remove the Unit from the Marine Enclosure . Loosen the screws to remove the covers. . Remove the bolt. 3. Detach the main unit from the waterproof housing unit. Remove the Old Unit from the Dashboard A. Remove the outer trim frame(not shown). B.
  • Page 9 Vehicle Installation DIN FRONT-MOUNT (Method A) NOTE: Unit should be installed horizontally or less than a 30° angle. . Insert Half Sleeve into dashboard. . Bend mount tabs outwards to secure it. 3. Insert the unit into the Half Sleeve until you hear a click sound. If necessary, attach the mounting strap to the rear of the unit, then attach it with the sup- plied nut as in fig.
  • Page 10: Vehicle Installation

    Vehicle Installation DIN REAR-MOUNT (Method B) Installation using the screw holes on both sides of the unit. Note: The mounting sleeve, outer trim ring, and the mounting strap are not used for this method of installation. . Screw holes on the side of the unit. 2.
  • Page 11: Wiring Diagram

    Wiring Diagram • Before starting the installation, disconnect the negative battery cable from the battery’s negative terminal. • Before final installation of the unit, temporarily connect the wiring to ensure the unit operates correctly. NOTES...
  • Page 12: Position Of Controls

    Position of Controls . Power ON/OFF 5. #5 / -0 . Volume + 6. #4 / Random 3. AS/PS 7. #3 / Intro 4. Mono/Stereo 8. # / Repeat 5. Loud 9. # / Pause 6. Liquid Crystal Display 0. SEL 7.
  • Page 13: Remote Control

    Remote Control . Power . Mode/SW 9. Dis 3. Mute 0. Loud 4. Number Buttons/Presets . Loc (/Play/Pause, /Repeat, 3/In- tro, 4/ Random, 5/-0 Tracks . Stereo/Mono 6/+0 Tracks) 3. AS/PS 5. Previous/Fast Reverse 6. Band 4. Next/Fast Forward 7. Volume Down 5.
  • Page 14: Basic Operation

    Basic Operation Front Panel Setting other features Press OPEN button on the front panel to Press SEL button and hold for  seconds, flip down the front panel. short press and repeat them again to select these settings: DSP OFF>BEEP Reset the unit  ND> HOUR.
  • Page 15: Digital Tuner Operation

    Digital Tuner Operation Band selection stations until the memories are full. Press MODE button to select TUNER. Preset scan Press BAND to select: FM, FM, FM3, Select a band, press AS/PS button to MW (AM), and MW (AM). scan all preset stations in the memories of ST/MO the current band, each preset scan for 5 In FM mode, press ST/MO button on...
  • Page 16: File / Folder Search Function

    File & Folder Search Random Search for File by Name In disc mode press 4/RDM button to . Press AS/PS button until an asterisk activate random playing mode, press one blinks on left side of LCD. more time to return to normal playing. .
  • Page 17: Specifications

    Specifications ELECTRIC Power Supply ....................DC  ~ 6 Volt Current Consumption ..................< 0 Ampere Load Impedance ....................4 - 8 Ohm Dimensions ..............78mm W x 65mm D x 50mm H Maximum Power Output ................. 4 x 40 Watts RMS Output ......................4 x 9 Watts FM TUNER Frequency Range ..................87.5 ~ 07.9 MHZ Usable Sensitivity ....................
  • Page 18: Warranty

    Limited Warranty VIRTUAL REALITY VIDEO LABS products are designed and manufactured to provide a high level of ® trouble-free performance. VIRTUAL REALITY VIDEO LABS warrants, to the original purchaser, that its products are free from defects in material and workmanship for 30 days from the date of original purchase.
  • Page 20 ©009 Intellectual Solutions Inc., All Rights Reserved, All designs, logos and images are the exclusive property of Intellectual Solutions Inc. and/or its affiliates. U.S. and Foreign Patents Pending. 072009 Printed in China 06055...
