"When You Need More Than Staples."
Toll Free: 800-658-8788
Fax: 801-927-3037
info@abcoffice.com
IDEAL CUTTERS
Model 1038 Model 1058
Model 1071 Model 1080
Model 1110
1.
Knife guard
2.
Manual clamp
3.
Knife carrier
4.
Front gauge with narrow-strip-cutting
device
5.
Paper supports
6.
Back gauge
7.
Side lay with cm / inch scale
8.
Rotary knob for adjustment of front
gauge
9.
Locking screw for front gauge
10. Collapsible extension table
11. Foot clamp
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1071 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ABC Office 1071

  • Page 1 “When You Need More Than Staples.” Toll Free: 800-658-8788 Fax: 801-927-3037 info@abcoffice.com IDEAL CUTTERS Model 1038 Model 1058 Model 1071 Model 1080 Model 1110 10. Collapsible extension table 11. Foot clamp Knife guard Manual clamp Knife carrier Front gauge with narrow-strip-cutting...
  • Page 2: Safety Regulations

    For the model 1038 loosen the set screw (I). Tighten the lock nut (II) and retighten the set screw (I). For modes l1058, 1071, 1081 and 1110, tighten the lock nut (III). While holding the lock nut (III) in place with a second crescent wrench, tighten the lock nut (IV).
  • Page 3 IDEAL 1071 Place clamp with knife guard (A) as illustrated on the machine. The knife guard must be caught behind the guiding screw (B). Turn allen screws into fixing points and tighten. Allen wrench and screws are packed with the machines.
