Panasonic Lumix G6 Specifications

Specifications
Type Digital Single Lens Mirrorless camera
SD Memory Card
SDHC Memory Card*
Recording Media
TYPE SDXC Memory Card*
* Compatible with UHS-I standard SDHC / SDXC Memory Cards
Image Sensor Size 17.3 x 13.0 mm (in 4:3 aspect ratio)
Lens Mount Micro Four Thirds mount
Type Live MOS Sensor
Total Pixels 18.31 Megapixels
Camera Effective Pixels 16.05 Megapixels
SENSOR
Color Filter Primary color filter
Dust Reduction System Supersonic wave filter
JPEG (DCF, Exif 2.3), RAW
Still Image
Recording File
MPO (When attaching 3D lens in Micro Four Thirds System standard)
Format
Motion Image AVCHD (Audio format: Dolby Digital 2ch) / MP4 (Audio format AAC 2ch)
Aspect Ratio 4:3, 3:2, 16:9, 1:1
RAW, RAW+Fine, RAW+Standard, Fine, Standard
Image Quality
MPO+Fine, MPO+Standard (When attaching 3D lens in Micro Four Thirds System standard)
Color Space sRGB, Adobe RGB
[4:3] 4,608 x 3,456 (L), 3,264 x 2,448 (M), 2,336 x 1,752 (S), 1,824 x 1,368*
[3:2] 4,608 x 3,072 (L), 3,264 x 2,176 (M), 2,336 x 1,560 (S), 1,824 x 1,216*
Still Image [16:9] 4,608 x 2,592 (L), 3,264 x 1,840 (M), 1,920 x 1,080 (S), 1,824 x 1,024*
[1:1] 3,456 x 3,456 (L), 2,448 x 2,448 (M), 1,744 x 1,744 (S), 1,712 x 1,712*
* When attaching 3D lens in Micro Four Thirds System standard.
[Full HD] 1,920 x 1,080, 60fps (sensor output is 60p, 28Mbps)
NTSC [Full HD] 1,920 x 1,080, 30fps (sensor output is 30p, 20Mbps)
Area [HD] 1,280 x 720, 30fps (sensor output is 30p, 10Mbps)
[VGA] 640 x 480, 30fps (sensor output is 30p, 4Mbps)
MP4
[Full HD] 1,920 x 1,080, 50fps (sensor output is 50p, 28Mbps)
PAL [Full HD] 1,920 x 1,080, 25fps (sensor output is 25p, 20Mbps)
RECORDING
Area [HD] 1,280 x 720, 25fps (sensor output is 25p, 10Mbps)
SYSTEM File
[VGA] 640 x 480, 25fps (sensor output is 25p, 4Mbps)
Size
(Pixels) NTSC
[Full HD] 1,920 x 1,080, 60p (sensor output is 60p, 28 Mbps)
Area
Motion AVCHD
Image Progressive
PAL
[Full HD] 1,920 x 1,080, 50p (sensor output is 50p, 28 Mbps)
Area
[Full HD] 1,920 x 1,080, 60i (sensor output is 60p, 17Mbps)
NTSC [Full HD] 1,920 x 1,080, 60i (sensor output is 30p, 24Mbps)
Area [Full HD] 1,920 x 1,080, 24p (sensor output is 24p, 24Mbps)
[HD] 1,280 x 720, 60p (sensor output is 60p, 17Mbps)
AVCHD
[Full HD] 1,920 x 1,080, 50i (sensor output is 50p, 17Mbps)
PAL [Full HD] 1,920 x 1,080, 50i (sensor output is 25p, 24Mbps)
Area [Full HD] 1,920 x 1,080, 24p (sensor output is 24p, 24Mbps)
[HD] 1,280 x 720, 50p (sensor output is 50p, 17Mbps)
Continuous Recordable Time** 150 min with H-PS14042, H-FS1442A, H-FS14140, H-FS45150
(Motion Image, AVCHD, Approx.) 140 min with H-FS014042
Actual Recordable Time** 75 min with H-PS14042, H-FS1442A, H-FS14140, H-FS45150
(Motion Image, AVCHD, Approx.) 70 min with H-FS014042
Flicker Reduction [1/50] [1/60] [1/100] [1/120] / OFF
Wi-Fi IEEE 802.11b/g/n, 2412 MHz - 2462 MHz (11 ch), Wi-Fi / WPA / WPA2, Infrastructure mode
Wi-Fi
FUNCTION
NFC ISO/IEC 18092 (NFCIP-1) NFC-F
Type OLED Live View Finder (1,440,000 dots)
Field of View (Approx.) 100%
Magnification (Approx.) 1.4x / 0.7x (35 mm camera equivalent) with 50 mm lens at infinity; -1.0 m-1
VIEWFINDER Eye Point (Approx.) 17.5 mm from eyepiece lens
Diopter Adjustment -4.0 - +4.0 (dpt)
Eye Sensor Yes
Eye Sensor Adjustment High / Low
Type Contrast AF system
Focus Mode AFS (Single) / AFF (Flexible) / AFC (Continuous) / MF
AF Mode Face detection / AF Tracking / 23-area-focusing / 1-area-focusing / Pinpoint
AF Detective Range EV -3 - 18 (ISO100 equivalent)
FOCUS
AF Assist Lamp YES
AF Lock Set the Fn button in custom menu to AF lock
Quick AF, Continuous AF (during motion image recording), AF+MF, Eye Sensor AF,
Others
Touch AF/AE Function, Touch Pad AF, Touch shutter, Touch MF Assist
Light Metering System 1,728-zone multi-pattern sensing system
Light Metering Mode Intelligent Multiple / Center Weighted / Spot
Metering Range EV 0 - 18 (F2.0 lens, ISO100 equivalent)
Exposure Mode Program AE / Aperture Priority AE / Shutter Priority AE / Manual
EXPOSURE
ISO Sensitivity (Standard Output Auto / Intelligent ISO / 160 / 200 / 400 / 800 / 1600 / 3200 / 6400 / 12800 / 25600 (Extended)
CONTROL
Sensitivity) (Changeable to 1/3 EV step)
Exposure Compensation 1/3 EV Step, ±5 EV
AE Lock Set the Fn button in custom menu to AE lock
AE Bracket 3, 5, 7 frames, in 1/3, 2/3 or 1 EV Step, ±3 EV
Auto / Daylight / Cloudy / Shade / Incandescent / Flash / White Set 1, 2 /
White Balance
Color temperature setting
WHITE
White Balance Adjustment Blue/amber bias, Magenta/green bias
BALANCE
Color Temperature Setting 2,500 K - 10,000 K in 100 K
White Balance Bracket 3 exposures in blue/amber axis or in magenta/green axis
Type Focal-plane shutter
Still Image Bulb (Max. 120 seconds), 1/4,000 - 60
SHUTTER Shutter Speed
Motion Image 1/16,000 - 1/30 (NTSC area), 1/16,000 - 1/25 (PAL area)
Self Timer 10 sec, 3 images / 2 sec / 10 sec
Clear Portrait / Silky Skin / Backlit Softness / Clear in Backlight / Relaxing Tone / Sweet
Child's Face / Distinct Scenery / Bright Blue Sky / Romantic Sunset Glow / Vivid Sunset Glow
/ Glistening Water* / Clear Nightscape / Cool Night Sky / Warm Glowing Nightscape / Artistic
SCENE GUIDE
Nightscape / Glittering Illuminations* / Clear Night Portrait / Soft Image of a Flower* /
Appetizing Food / Cute Dessert / Freeze Animal Motion / Clear Sports Shot / Monochrome
* For photo only.
** These are standard times taken at a temperature of 23°C (73.4°F) and a humidity of 50%RH. The time available for recording varies depending on the environment, the interval between recordings, and the manner of use. Actual recordable time is the time available for
recording when repeating actions such as switching the power supply [ON]/[OFF], starting/stopping recording, zoom operation etc.
• Maximum time to record motion pictures continuously with [AVCHD] is 29 minutes 59 seconds in Europe and some Asian areas.
• Maximum time to record motion pictures continuously with [MP4] is 29 minutes 59 seconds or up to 4 GB.
• You can check the recordable time on the monitor. (For [FHD] in [MP4] format, the file size is large and so the recordable time will drop below 29 minutes 59 seconds.)
• Use a card with SD Speed Class with "Class 4" or higher when recording motion images. (SD speed class is the speed standard regarding continuous writing.)
• SDHC Memory Cards and SDXC Memory Cards can be used only in equipment that is compatible with their respective formats.
• If the computer being used does not support SDXC Memory Cards, a message prompting you to format may appear. (Doing so will cause recorded images to be erased so do not choose to format.) If the card is not recognized, please refer to the below support site.
http://panasonic.net/avc/sdcard/information/SDXC.html
*** Shooting conditions: 23°C with 50%RH humidity; Monitor on; using a Panasonic SDHC Memory Card; Using the supplied battery; Using the supplied lens; Starting recording 30 seconds after the camera is turned on (When the optical image stabilizer is set to [Normal])
; Recording once every 30 seconds with full flash every second recording; Turn the camera off every 10 recordings. The number of recordable pictures varies depending on the recording interval time. If the recording interval time becomes longer, the number of recordable
pictures decreases. CIPA is an abbreviation of "Camera & Imaging Products Association".
Partial restrictions on using Panasonic digital video cameras to play AVCHD motion images recorded with the DMC-G6.
• AVCHD videos recorded onto an SD Memory Card or a DVD disc cannot be played on a device that does not support the AVCHD standard.
• AVCHD motion images recorded with the image quality set to 1,280 × 720 cannot be played on AVCHD-compatible digital video cameras.
• AVCHD motion images recorded with AVCHD-compatible digital video cameras cannot be played on the DMC-G6.
• More detailed information is available on our support site: http://panasonic.jp/support/global/cs/dsc/
About the performance of Face Recognition function
Recognition performance varies greatly depending on shooting conditions, i.e., according to factors such as angles, facial expression and lighting, so operation under all conditions cannot be guaranteed. Because the camera searches for faces that are similar to registered faces,
there are cases where the faces are not correctly recognized when the registered image and the shooting image varies much. When facial characteristics are similar, particularly between parents and their children or brothers and sisters, the camera may not distinguish the faces.
• "AVCHD Progressive", "AVCHD", the "AVCHD Progressive" Logo and the "AVCHD" Logo are trademarks of Panasonic Corporation and Sony Corporation. The release date may differ depending on the country. Check the website of the Panasonic sales company in your country or
region for details on the optional accessories that are available in your market. • The DMW-BLC12 comes with a function to check whether the battery and unit can be safely used together. • Batteries made by other companies which have been certified by Panasonic may be used
with these units, but we offer no guarantee as to the quality, performance or safety of such batteries. • Exercise care when purchasing batteries. Many fake or imitation batteries have been found among those sold at unusually low prices and those which customers cannot check for
themselves before purchasing. • Please confirm the latest information about batteries on the following website. http://panasonic.jp/support/global/cs/info/battery.html (English) • When a lens that does not support the contrast AF function is mounted, operation will automatically
switch to manual focus. Confirm the operation information of compatible lenses at Customer support. http://panasonic.jp/support/global/cs/dsc (English) • Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.
• HDMI, the HDMI Logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC. • Microsoft® and Windows® are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
• Four Thirds™ and Micro Four Thirds™, and Four Thirds and Micro Four Thirds Logo marks are trademarks or registered trademarks of Olympus Imaging Corporation, in Japan, the United States, the European Union and other countries. • Other names of systems and products
mentioned in this brochure are generally the registered trademarks or trademarks of the manufacturers who developed the system or product concerned. • Some accessories are not available in some countries. • Weight and dimensions shown are approximate. • Overall length
of lens is from the tip of the lens to the base side of the lens mount. • Some functions may not work when lenses other than the included lens are used. Please refer to Panasonic's website, etc., for the latest information. • Available of OSD languages may vary depending on the
sales area. • Some sample images are simulated. • The use of recorded or printed materials that are protected by copyright for any purpose other than personal enjoyment is prohibited, as it would infringe upon the rights of the copyright holder. • The Wi-Fi CERTIFIED Logo is a
certification mark of the Wi-Fi Alliance.
SH: 40 frames/sec
H: 7.0 frames/sec (with AFS), 5.0 frames/sec (with AFC, In 1-area-focusing AF mode)
Burst Speed
M: 4.0 frames/sec (with Live View)
BURST
L: 2.0 frames/sec (with Live View)
SHOOTING
9 images (when there are RAW files with the particular speed)
Number of Recordable Images Unlimited consecutive shooting (when there are no RAW files)
(depending on memory card size, battery power, picture size, and compression)
TTL Built-in-Flash, GN10.5 equivalent (ISO160 · m), GN8.3 equivalent (ISO100 · m)
Type
Built-in Pop-up
Auto, Auto / Red-eye Reduction, Forced On, Forced On / Red-eye Reduction, Slow Sync.,
BUILT-IN-
Flash Mode
Slow Sync. / Red-eye Reduction, Forced Off
FLASH
Synchronization Speed Less than 1/160 second
Flash Synchronization 1st Curtain Sync., 2nd Curtain Sync.
Type TFT LCD with Touch monitor
Monitor Size Free-angle 3.0 inch (7.5 cm) / 3:2 Aspect / Wide-viewing angle
MONITOR Pixels 1,036K dots
Field of View Approx. 100%
Monitor Adjustment Brightness, Contrast and Saturation, Red tint, Blue tint
Digital Zoom 2x, 4x
Max. 2x (Aspect ratio sets at 4:3. Not effective with L size recording. Magnification ratio
Still Image
depends on the recording pixels and aspect ratio.)
Extra Tele
2.4x (FHD/60p, FHD/60i, FHD/30p, FHD/24p in NTSC area / FHD/50p, FHD/50i, FHD/25p,
LIVE VIEW Conversion
Motion Image FHD/24p in PAL area), 3.6x (HD/60p, HD/30p in NTSC area / HD/50p, HD/25p in PAL area),
4.8x (VGA/30p in NTSC area / VGA/25p in PAL area)
Guide Lines (3 patterns)
Other Functions
Real-time Histogram
LEVEL GAUGE Yes (Built-in 3 shaft accelerometer sensor)
DIRECTION DETECTION FUNCTION Yes
Wi-Fi / Q.MENU / AF/AE LOCK / LVF/Monitor Switch / One Push AE / Touch AE / Preview /
Level Gauge / Focus Area Set / Photo Style / Aspect Ratio / Picture Size / Quality / Metering
FUNCTION Mode / Focus Mode / i Dynamic / i Resolution / HDR / Electronic Shutter / Flash Mode / Flash
Fn1, Fn2, Fn3, Fn4, Fn5, Fn6, Fn7
BUTTON Adjust. / Ex. Tele Conv. / Digital Zoom / Stabilizer / Motion Pic. Set / Picture Mode / Peaking /
Histogram / Guide Line / Rec Area / Function Lever / Step Zoom / Zoom Speed / Sensitivity /
White Balance / AF Mode / Drive Mode / Restore to Default
FUNCTION LEVER Yes (Auto / Zoom / Exp.)
Expressive / Retro / Old Days / High Key / Low Key / Sepia / Dynamic Monochrome /
Impressive Art / High Dynamic / Cross Process / Toy Effect / Toy Pop / Bleach Bypass /
CREATIVE CONTROL
Miniature Effect / Soft Focus* / Fantasy / Star Filter* / One Point Color / Sunshine*
* For photo only.
CREATIVE
Exposure Mode Program AE / Aperture-Priority / Sutter-Priority / Manual Exposure
VIDEO MODE
PHOTO STYLE Still Image and Motion Image Standard / Vivid / Natural / Monochrome / Scenery / Portrait / Custom
Normal playback, 30-thumbnail display, 12-thumbnail display, Calendar display, Zoomed
playback (Max. 16x), Slideshow (duration & effect is selectable), Playback Mode (Normal /
PLAYBACK Playback Mode Picture / Video / 3D Play / Category / Favorite), Location Logging, Clear Retouch, Title Edit,
Text Stamp, Video Divide, Time Lapse Video, Stop Motion Video, Resize, Cropping, Rotate,
Favorite, Print Set, Protect, Face Recognition Edit
IMAGE Protection Single / Multi, Cancel
PROTECTION /
Erase Single / Multi / All / Except Favorite
ERASE
PRINT Direct Print PictBridge compatible (Print size, Layout and Date settings are selectable)
USB USB 2.0 High Speed Multi
mini HDMI TypeC
HDMI Video: Auto / 1080i / 720p / 480p (576p in PAL system)
Audio: Stereo
Monaural Type, NTSC / PAL, NTSC only for North America
Audio Video Output • Check the website of the Panasonic sales company in your country or region for details on
INTERFACE the products that are available in your market.
Remote Input ø 2.5mm for remote
External Microphone Input ø 3.5mm for external microphone
Stereo, Wind-cut: AUTO / HIGH / STANDARD / LOW / OFF
Microphone
Microphone level adjustable: 19 levels
Speaker Monaural
English, German, French, Italian, Spanish, Polish, Czech, Hungarian, Russian, Chinese
(Traditional), Chinese (Simplified), Dutch, Thai, Korean, Turkish, Portuguese, Arabic, Persian,
Japanese, Swedish, Danish, Finnish, Greek, Vietnamese
LANGUAGE OSD Language
• Check the website of Panasonic sales company in your country / region or ask customer
support for details of the OSD language available on the products sold in your country /
region.
Li-ion Battery Pack (7.2V, 1,200mAh) (Included)
Battery
Battery Charger
POWER
350 images with H-FS1442A, H-FS45150
Battery Life (Approx.)
340 images with H-PS14042, H-FS14140
• CIPA Standard***
330 images with H-FS014042
Dimensions (Approx.) W x H x D: 122.45 x 84.6 x 71.4 mm / 4.82 x 3.33 x 2.81 inch (excluding protrusions)
390 g / 0.86 lb (SD card, Battery, Body)
340 g / 0.75 lb (Body only)
485 g / 1.07 lb (SD card, Battery, H-PS14042 lens included)
DIMENSIONS /
500 g / 1.10 lb (SD card, Battery, H-FS1442A lens included)
WEIGHT
Weight (Approx.) 555 g / 1.22 lb (SD card, Battery, H-FS014042 lens included)
590 g / 1.30 lb (SD card, Battery, H-FS45150 lens included)
655 g / 1.44 lb (SD card, Battery, H-FS14140 lens included)
700 g / 1.54 lb (SD card, Battery, H-FS1442A + H-FS45150 lenses included)
755 g / 1.66 lb (SD card, Battery, H-FS014042 + H-FS45150 lenses included)
Operating Temperature 0 °C to 40 °C (32 °F to 104 °F)
OPERATING
ENVIRONMENT
Operating Humidity 10%RH to 80%RH
PHOTOfunSTUDIO 9.2 PE
SILKYPIX® Developer Studio 3.1 SE
Software
LoiLoScope (trial version)
USB Driver
STANDARD
ACCESSORIES
Battery pack, Battery Charger, Body Cap*, Lens Cap, Lens Hood*, Lens Rear Cap*,
USB Connection Cable, Shoulder Strap, CD-ROM
Standard Accessories
* Lens Hood and Lens Rear Cap of H-PS14042 lens and Body Cap are not included for
DMC-G6X kit.
ABSOLUTE RESPONSE
