Alcatel ONE TOUCH OT-E206C User Manual

Alcatel ONE TOUCH OT-E206C User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Contents
1.
Your mobile.................................................................................................................................. 1
2.
Getting started............................................................................................................................. 5
3.
Basic functions ............................................................................................................................ 6
4.
Display ........................................................................................................................................ 9
5.
Recent calls ................................................................................................................................. 9
6.
Entertainment .............................................................................................................................10
7.
Alarm..........................................................................................................................................10
8.
Contact .......................................................................................................................................11
9.
Messages ....................................................................................................................................12
10.
Settings .......................................................................................................................................15
11.
Profile.........................................................................................................................................16
12.
Tools ...........................................................................................................................................17
13.
FAQ.............................................................................................................................................17
14.
Safety and use.............................................................................................................................19
Friendly reminder:
This user manual applies to the OT-E206C mobile phone. If there are minor differences in the
description or illustrations between the manual and the actual product the actual product shall
take precedence. Customers will not be notified separately of any upgraded model of this
We reserve the right to revise anytime the contents of this manual without prior notice.

1. Your mobile

1.1 Basic specifications
Item
Screen resolution
Contacts
Call Memory
Message
Li-ion battery
Specifications
Size: 87.5mm[L]×45mm[W]×21.5mm[Thickness]
Weight: 80g approx.(Including lithium battery）
128×128
500 entries
30 entries
350 entries
Rated capacity: 820mAh
Standard voltage: 3.7V
Talk time: 120 to 240 minutes
Standby time: 80 - 150 hours (approx.)
Operating temperature: -10℃ to +55℃
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ONE TOUCH OT-E206C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alcatel ONE TOUCH OT-E206C

Summary of Contents for Alcatel ONE TOUCH OT-E206C

  • Page 1: Table Of Contents

    Contents Your mobile..........................1 Getting started..........................5 Basic functions ..........................6 Display ............................9 Recent calls ..........................9 Entertainment ..........................10 Alarm............................10 Contact ............................11 Messages ............................12 Settings ............................15 Profile............................16 Tools ............................17 FAQ.............................17 Safety and use..........................19 Friendly reminder: This user manual applies to the OT-E206C mobile phone. If there are minor differences in the description or illustrations between the manual and the actual product the actual product shall take precedence.
  • Page 2 Explanation: Standby time refers to the time when the phone although in operating mode is not used for making calls or remains idle. Standby time and call time are both related to the conditions of use, the network situation and the environment. The SAR standard is 2.0W/Kg.
  • Page 3 1.3 Main Menu From the main menu, use the navigation key to select the item you want. After selection, press the left soft key to confirm. Display: Access to display settings, customize wallpaper, style, set Backlight time And activate LED indicators to SMS, call and alarm Call Memory: Access the Call Memory Games:...
  • Page 4 Tools: Set or use the stop-watch, the calendar and the world clock 1.3 Screen Icons Battery charge level Silent mode Vibration mode Unread message Inbox full Voice mail Missed call Call forwarding activated: Your calls will be forwarded Alarm clock activated Roaming instructions Signal strength indicator...

  • Page 5: Getting Started

    2. Getting started 2.1 Removing the back cover 2.2Inserting the UIM card (Operator dependent) The mobile phone can only be used with the UIM card inserted. Press and hold the key. Insert the UIM card with the metallic contact downwards, sliding it into the slot as shown by the arrow, paying attention to the position of the slanted angle.

  • Page 6: Basic Functions

    2.3 Installing / Removing the battery Remove the back cover and remove the battery as shown (direction of the arrow). 2.3 Charging your phone Attention: the phone will emit a low warning tone 20 minutes before the power runs out completely.
  • Page 7 3.2.2 Dialling a number in the Call Memory In the standby mode, press the key to access the Call Memory, and press this key again to dial the selected number. 3.2.3 Speed dialling In the standby mode, make a long key press on keys 2 to 9 to speed-dial a number. If you have not set the number for speed dialling, the phone will display “Speed dial is empty”.
  • Page 8 3.4.4 Introduction to the input method Inserting punctuations and special symbols When you are editing a text using the Es and English input mode, press key “1” to select the punctuation mark or a special symbol or press and hold “*” to access the symbol table. In the number input mode, press “*”...

  • Page 9: Display

    p，q，r，s，P，Q，R，S，7 t，u，v，T，U，V，8 w，x，y，z，W，X，Y，Z，9 Number input method (123) Press the number key to enter the corresponding number, press “*” to enter “*”. 4. Display Wallpaper: Choose the wallpaper and set it as main screen. Style: Choose a scheme of display. There are 6 available styles for you to choose Backlight time: Set the backlight time - 10 sec.30 sec.50 sec.

  • Page 10: Entertainment

    Detail: Check the data on the selected number. Save: Save the selected number in Contacts. Call: Call the selected number. IP call: Call the selected number with IP prefix. Send message: Send a message to the selected number. Send contact: Send the selected number to another party. Delete: Delete the selected number.

  • Page 11: Contact

    8. Contact The phone can store up to 500 contacts. From the standby mode press the right soft key to display the list of contacts. The contact list can also be accessed through Menu/Contact. 8.1 Contact list Select Menu/Contact/Contact list to access the contact records. Select the left soft key for the following options: View, Edit, Call, IP Call, Send message, Send contact, Delete, and Search View: Check the contact’s personal information.

  • Page 12: Messages

    ring tone. 8.5 Speed dial Select Menu/Contact/Speed dial to set keys 2 to 9 for speed dialling. If the number key has not been set, press the left soft key and select a phone number from Contacts. If the number key has been set, press the left soft key and the following options will be available: Set number, clear.
  • Page 13 9.2 Inbox Select Menu/Messages/Inbox to access the list of messages in this box. Press the left soft key for the following options: View, Reply, Delete, Forward, Call, and IP Call. View: Review the contents of the current messages. From the contents, press the left soft key for the following options: Reply, Delete, Forward, Extract details, Call, IP call.
  • Page 14 Press the left soft key for the following options: View, Send, Edit and Add. It has 10 message templates in factory reset mode, and you may edit it optionally or add more templates accordingly. 9.6 Delete message Select Menu/SMS/Delete message to access delete function. You may delete the messages in Inbox, Outbox, and Draft box and also clear all the messages.

  • Page 15: Settings

    number, press the left soft key to choose the number that you want to send and then press ok key to send out. If the contact person has many numbers, you may switch between the numbers by pressing the left key or the right key, and then choose the numbers you want to send by pressing the left soft key and press OK key to send out.

  • Page 16: Profile

    You can activate or inactivate Auto power on function, and set the time when you want the phone power on automatically. 10.4 Auto power off he phone power off automatically. 10.5 Security Select menu/settings/security, then enter the security submenu by inputting the phone code (default code is 1234).

  • Page 17: Tools

    on/off, and the alert mode of incoming call, SMS, and the unanswered call. Load default: resumed the mode you choose to the factory settings. Tools 12.1 Stop watch Press the key to start counting and the key to stop it. While counting, press the key to record the previous count.
  • Page 18 Item to be checked The telephone does not Make sure that the charger is correctly connected to the charge properly phone and the power socket. Make sure you are using a charger specifically designed for this phone. The phone does not Check the battery charge level.

  • Page 19: Safety And Use

    Item to be checked When you cannot (1) The network provider does not provide this service or you connect to the network have not subscribed to this service. Please contact your normally provider for details on the subscription and use of these services.

  • Page 20: Mobile Phone

    car engines. Safety of use in a vehicle Please observe the relevant local or national regulations related to the use of mobile phones in a vehicle. Please refrain from using the phone while driving. If you are driving and need to use the phone in an emergency, use a hands-free device (optional purchase) to be safe.

  • Page 21: Mobile Phone

    Operating environment This phone is equipped with a built-in antenna. When the phone is on, unless necessary, do not touch the antenna area (top of the phone) for optimal communication quality. Do not use your phone while it is being charged during thunderstorms, or use it outdoors to avoid being struck by lightning or other injury.

  • Page 22: Mobile Phone

    Please take your used, unwanted lithium batteries to a designated place. Do not dispose of them in a rubbish bin. Emergency call In an emergency situation, if the phone is on and you are within the network range, it can be used to make an emergency call.

  • Page 23: Mobile Phone

    Warning: The manufacturer disclaims any liability for damage, which may result as a consequence of improper use of this mobile phone or use contrary to the instructions contained in this manual. Alcatel logo and Alcatel name are Trademark of Alcatel-Lucent used under license by TCT Mobile Limited All rights reserved ©...
