NAMES OF THE PARTS

$ ) 1
@! &
! FREEZER
@ DRAIN PAN (Use for Defrost Only)
# THERMOSTAT DIAL
$ PLASTIC COATED SHELF
% RACK
^ MAGNETIC DOOR SEAL
& ICE CUBE TRAY
* RACK
( BOTTLE RACK
) CRISPER
1 SLIDE OUT CRISPER COVER.
#
% * (
^
1

HOW TO OPERATE

Starting your new Refrigerator

1. Clean the refrigerator thoroughly. Wipe the outside with a soft dry cloth, the
interior with a clean moist cloth.
2. Insert the power supply cord into the socket.
3. Turn the thermostat dial to "7". Close the door and let the refrigerator
operate for 15-20 minutes.

Temperature control

To control the internal temperature, adjust
the thermostat dial. The dial is numbered
from 1-7.
Number 1 is the warmest setting, number 7
the coldest.
The dial may be set any place on the scale.
It does not have to be set exactly on a
number. To make ice cubes in the freezer
compartment, adjust the thermostat to the
coldest setting.
NOTE: Wait 3-5 minutes before restarting if you unplug the refrigerator.
The unit may fail to operate properly if restarted too quickly.

How to defrost

Defrost the refrigerator when the frost accumulated on the evaporator is
about 5mm (1/5inch) thick.
Set the thermostat dial to "OFF". Keep drip tray in place. Defrosting usually
takes a few hours. To defrost quickly remove all goods from the refrigerator
and leave the door open. Never use a knife or other metal instrument to
scrape ice/frost from the freezer. After defrosting, empty water from drip tray
and return the thermostat dial to the desired position.
6
2
TEMPERATURE
CONTROL
2
