GE Spacemaker JVM141H Use And Care Manual

GE Spacemaker JVM141H Use And Care Manual

625 watts
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Contents
Adapter Plugs
Aluminum Foil
Appliance
Registration
Auto Roast
Auto Simmer
Care and Cleaning
Control Panel
Conversion Guide
Cooking
Complete
Reminder
Delayed Cooking
Exhaust Fan
Extension Cords
Features
Grease Filters
Grounding
Instructions
Light Bulb Replacement
Microwaving Tips
Model JVM141H
22
4
Model and Serial Numbers
Oven Shelf
2
Power Levels
Precautions
12, 13
13
Problem Solver
Repair Service
15-17
6,7
Safety Instructions
14
Temperature Cook
Temperature Probe
5
Time Cook
6
11
Time Defrost
6, 16
Warranty
22
5
16, 17
22
11
16
2
800.626.2000
Timer
2
18, 19
8-11
20, 2;
23
3,4
10
10, 12, 13
8
9
Back Cover

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Spacemaker JVM141H and is the answer not in the manual?

Questions and answers

Related Manuals for GE Spacemaker JVM141H

Summary of Contents for GE Spacemaker JVM141H

  • Page 1 Exhaust Fan 6, 16 Extension Cords Features Grease Filters 16, 17 Grounding Instructions Hold Time Light Bulb Replacement Microwaving Tips Model JVM141H GEAppiances MinutelSecond Timer Model and Serial Numbers 18, 19 Oven Shelf Power Levels 8-11 Precautions 20, 2; Problem Solver...

  • Page 2: Write Down The Model And Serial Numbers

    Serial Number Use these numbers in any correspondence or service calls concerning your microwave oven. Ml these things are nomd with your microwave oven: Steam or vapor escaping from around the door. o Light reflection around door or outer case.

  • Page 3: Optional Accessory

    This microwave oven is UL listed for instigation over electric and gas ranges. Optional Accessory available at extra cost from your GE supplier. Chamoal ~ter Kit for non-vented instigation. mic~wave oven specifically designed to heat or —...
  • Page 4 TV dinners maybe microwaved in foil trays less than 3/4” high; remove top foil cover and return tray to box. When using metal in microwave oven, keep rneti (other than metal shelfl at least l-inch away from sides of oven.

  • Page 5: Cooking Complete Reminder

    Features of Your Microwave Oven Cooking Complete Reminder (For TIME COOK and DEFROST cycles) To remind you that you have food in the oven, the oven will display “End” and beep once a minute until you either open the oven door or touch the CLEAR/OFF pad.

  • Page 6: Temperature Cook

    It’s designed to be easy to use and understand. With your microwave oven, you have the option of using your automatic cooking control pads for quick and easy convenience cooking. Or you may make your own programs to suit your individualized cooking style.

  • Page 8: Time Cook

    Step 2: Touch AUTO START pad (instead of START pad). Step 3: Enter the time you want the oven to start. (Be sure your microwave oven clock shows the correct time of day.) Step 4: Touch START pad. The oven will automatically start at the desired time.

  • Page 9: Time Defrost

    Defrosting by ~me Time Defrost is designed for speedy thawing of frozen food and is one of the great advantages of a microwave oven. Use Time Defrost to quickly thaw foods such as bread, rolls, vegetables, fruits and leftovers. Auto Defrost is preferred for meat...

  • Page 10: Cooking By Temperature

    Cooking by Temperature Internal temperature is the best test of doneness for many foods. Temp Cook/Hold takes the guesswork out of cooking because the oven automatically switches to Hold setting after reaching the preset food temperature and maintains that temperature for up to one hour or until you touch the CLEAR/OFF pad.

  • Page 11: Delayed Cooking

    How to Use the Minute/Second ~mer The MIN/SEC TIMER has three timing functions: . It operates as a minute timer. It can be set to delay cooking. It can be used as a hold setting after defrosting. The MIN/SEC TIMER operates without microwave energy.

  • Page 12: Automatic Roasting

    Automatic Roasting Auto Roast uses the temperature probe to cook to the desired serving temperature. Unlike Temp Cook/Hold, which uses a single power level, Auto Roast - up to 3 power settings which automatically switch during roasting, thus providing even, tender cooking resulh without overcooking.

  • Page 13: Auto Roast Guide

    Auto Roast Guide Use containers and coverings as directed at left. Place probe correctly in roast before cooking. . When oven beeps and flashes “TURN1’ turn meat over. Recommended codes are also shown inside oven on Auto Roast Guide. Food Beef Tender Roast Rare...

  • Page 14: Conversion Guide

    Automatic Defrosting With the Auto Defrost feature, the oven automatically sets the defrosting time and power levels for you. You choose the appropriate code number from 1 to 6 for the food you are defrosting, then enter the food weight in pounds and tenths of a pound (See Conversion Guide below) and touch START.

  • Page 15: Care And Cleaning

    Be sure bulbs to be replaced are cool before removing. Remove bulbs and replace with 40-watt incandescent bulbs (WB2X4253) available from your GE supplier. Raise lamp cover and replace screws that were removed. Connect electrical power to microwave oven.
  • Page 16 Remove bulb and replace with 30-watt incandescent bulb (WB2X4235) available from your GE supplier. Secure lamp housing with screw. Clean off the grease and dust on hood surfaces often. Use a warm detergent solution. About 1 tablespoon of ammonia maybe added to the water.
  • Page 17 To replace grease filter, slide the filter in the ~rame slot on the back of the opening. Pull filter upward and to the front to lock into place. To remove the charcoal filter, disconnect power at main fuse or circuit breaker or pull plug. Remove the top grill by taking off 3 screws which hold it in place.
  • Page 18 The two position wire shelf is specifically designed for added capacity heating and reheating in your Spacemaker” microwave oven. More than one food may be heated or reheated and ready to serve at the same time.
  • Page 19 How to Heat or Reheat Similar~pes of Food No plates of leftovers maybe reheated together. Arrange thick or dense foods to outside edges of plate and cover with plastic wrap. Microwave at High (10) for 2 to 3 minutes. Reverse position of plates (top to bottom) and rotate 1/2 turn.
  • Page 20 A fu5e in your home may be blown or the circuit breaker tripped, Replace fuse or WEN WILLN~ reset circuit breaker. CQMH ON * Unplug your microwave oven, then * Make sure 3-prong plug on oven is fully inserted into wall receptacle. * Door not securely closed. CONTROL PANEL LIGHTED, YET OVEN * STAW must be touched afier entering cooking selection.
  • Page 21 Light reflection around door or outer case. If you need more help.. call, toll free: The GE Answer Center” 800.626.2000 consumer information service been forgotten or not seated properly in oven wall when using things are normal with your microwave oven: Dull, thumping sound while oven is operating.

  • Page 22: Grounding Instructions

    GroundiW Imtructiom This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a power cord having a grounding wire with a grounding plug.

  • Page 23: If You Need Service

    NEXT, if you are still not pleased, write all the details-including your phone number—to: Manager, Consumer Relations GE Appliances Appliance Park Louisville, Kentucky 40225 FINALLY, if your problem is still not resolved, write: Major Appliance...
  • Page 24 To know what your legal rights are in your state, consult your local or state consumer affairs office or your state’s Attorney General. If fuflher help is needed concerning this warranty, write: Manager—Consumer Affairs, GE Appliances, Louisville, KY 40225 Part No. 164 D2092P11O 49-8082 Pub.
