Banner American Finisher 4300 Operating Instructions Manual

Abc office laminator operating instructions
Hide thumbs Also See for Finisher 4300:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operating Manual
OPERATING
INSTRUCTIONS
FINISHER 4300
Model No. BA-FS43
Banner American Products, Inc.
abcoffice
800-658-8788
www.abcoffice.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Finisher 4300 and is the answer not in the manual?

Questions and answers

Related Manuals for Banner American Finisher 4300

Summary of Contents for Banner American Finisher 4300

  • Page 1 OPERATING INSTRUCTIONS FINISHER 4300 Model No. BA-FS43 Banner American Products, Inc. abcoffice 800-658-8788 www.abcoffice.com...

  • Page 2: Table Of Contents

    Table of Contents For Your Safety ... 2 Electrical Safeguards ... 2-3 III. Specifications ... 3 Set-up ... 3-5 Inspection ... 3 Appropriate Location ... 3 Loading Film onto Mandrels ... 3 Threading the Film ... 4 Mandrel Tension Adjustment ... 4 Roller Pressure Adjustment ...

  • Page 3: Control Panel

    Left Side Cover STANDARD STANDARD LAMINATING LAMINATING MOUNTING FORWARD SPEED MOTOR CONTROL REVERSE FANS Core Gripper abcoffice Finisher 4300 (BA-FS43) Upper Supply Mandrel Tie Bar Feed Table Right Side Cover MOUNTING Control Panel TEMPERATURE HEAT CONTROL SHOE Mandrel 800-658-8788 Mandrel...

  • Page 4: Ii. Electrical Safeguards

    I. For your safety... Do not connect the laminator to electrical power or attempt to operate it until you have read these instructions completely. Keep these instructions in a convenient location for future reference. Read all safety messages located in this instruction manual and on the laminator very care- fully.

  • Page 5: Iii. Specifications

    Appropriate Location: Your Finisher 4300 must be placed on a sturdy table or stand in a clean, well lit area with ample space on all four sides of the laminator. Contact your dealer for the optional stand designed especially for the Finisher 4300.

  • Page 6: Threading The Film

    Adjust the pressure only ¾ of a turn between tests. Adjust each pressure block as necessary. The pressure on your Finisher 4300 has been preset at the factory. However, shipping and handling may necessitate slight pressure adjustment. Once pressure is properly set you should only need to use the MOUNTING/LAMINATING knobs on the sides of your Finisher 4300.

  • Page 7: Slitters

    Slitters (Figure 4) To install the slitters, place the Main Body Clamps into the Top Roller Guard where they will slide into the slots in the in the top edge of the guard located at each end of the guard. Before setting the slitters in place, ensure the machine is loaded with the proper laminating film.

  • Page 8: Pressure Sensitive Laminating

    VII. Coating Mount Board... The Finisher 4300 is capable of applying an adhesive coating to mount board that has not previous been coated. 1. Load a roll of adhesive, with the liner wound to the outside, onto the top mandrel in the same manner as with laminating film.

  • Page 9: Viii. Mounting & Laminating

    VIII. Mounting & Laminating... 1. Be sure all laminator parts (i.e. safety shield, feed table, etc.) are in their proper positions and the laminat- ing film is loaded correctly (See page 3 for film loading instructions). 2. Open the ROLLER RELEASE handle and select the MOUNT position on both sides of your laminator. Close the rollers.

  • Page 10: Cleaning Rubber Rollers

    Cleaning Rubber Rollers: Excessive build-up of adhesive on the rollers may cause poor lamination quality and erratic film movement. Use the following procedure to remove any adhesive from the laminating rollers. 1. Turn the HEATED ROLLERS and TOP & BOTTOM SHOES OFF and allow the laminator to cool. 2.

  • Page 11: Trouble-Shooting

    X. Trouble-shooting... Symptom LCDs do not show display when heat switches are on. Film is not bonding to the print Laminated item curls Laminated item is wrinkled Laminated item is blistered Mandrel tension does not remain constant abcoffice Possible Cause No power to laminator Blown fuse Laminator not set to optimal...

  • Page 12: Laminating & Mounting Do's & Don'ts

    Warranty: Your Finisher 4300 is warranted to be free of defects in material and workmanship for a period of 1 year from the date of original purchase. In the event of a defect in materials or workmanship, Banner American Prod- ucts, Inc.
