GE JEM25DMBB Dimensions And Installation Information

JEM25DM
GE Spacemaker II
™
Dimensions and Installation Information (in inches)
Exterior Dimensions* (in inches)
W x H x D
23-25/32 x 11-3/16 x 12-9/32
*Height includes feet. Depth does not include handle.
Built-In trim kit for 1.0 cu. ft. microwave ovens
For a custom built-in appearance, this kit allows built-in
installation of the Spacemaker II microwave oven into a wall or
cabinet alone, and is U. L. approved for installation over a GE
single electric wall oven.
Trim kits for model JEM25
JX827DMWW - White
JX827DMBB - Black
Installation Information: This information is not intended to
be used for installing unit described. Before installing, consult
installation instructions packed with product for current
dimensional data.
Note: Undercabinet Installation
Install Spacemaker II microwave ovens in just a few easy steps
with the mounting template, which provides all the necessary
measurements. Installation may vary depending on cabinets.
These microwave ovens can be installed on practically any
wood or metal cabinets.
Note:
120V, 60-cycle, grounded power receptble location optional on
back within cabinet opening.
For answers to your Monogram, GE Profile
®
GE ® appliance questions, visit our website at
ge.com or call GE Answer Center
®
800.626.2000.
1.0 Cu. Ft. Countertop Microwave Oven
or
™
service,
16-1/4
Not to be used over a thermal oven.
Undercabinet mounting kit Pub. No. 4-A019 for Spacemaker II microwave oven models available
at additional cost.
16" for flush
24-15/16" MAX.
receptacle
24-13/16" MIN.
18" for
in-cabinet
receptacle
Side cover
Bottom duct
26-1/8
Specification Revised 7/07
15-1/16" MAX.
14-15/16" MIN.
Listed by
Underwriters
Laboratories
340289
