Summary of Contents for Thermal Fogger Pioneer
- Page 1 KNAPSACK CORDLESS BATTERY POWERED ULV COLD FOGGER Model : Pioneer Model: Pioneer User’s Manual USER’S MANUAL ...
-
Page 2: Table Of Contents
CONTENTS Contents ······························································································ 1 Illustration ···························································································· 2 Warning ······························································································· 2 Technical specification ········································································ 3 Work principle ····················································································· 3 Flow rate knob ····················································································· 3 Operation ···························································································· 4 Install, move out battery…………...……………………...……….……...5 Spare parts list····················································································· 6 Inform Due to further improvement, we are sorry if could not inform individually. - 1 - ... -
Page 3: Illustration
Illustration Pressure Chamber Chemicals Tank Main Power Switch Flexible Hose Flow Rate Knob Nozzle Cover Warning Before operation, check battery have enough power. For better maintain battery, please remember every 2 month, run out off battery then fully charge. Do not upside down if tank has liquid. -
Page 4: Technical Specification
Technical specification Voltage DC 24 V Power 450 W Dimension 33 x 24 x 49 CM Net Weight 9.70 KG Tank capacity 5 L / 1.3 GAL. Flow rate 0 - 0.325 L/min, 0 - 9.61 OZ/min Work principle ULV cold fogger produce high-speed airflow, press chemicals solution to nozzle breaks into small particle around 20 micron, float in air longer, eliminate pest, disinfect air continuously. -
Page 5: Operation
Operation Fill chemicals to tank, tighten cover. Turn on Main power switch, carry on shoulder. Turn on Handle switch (Ⅰ-slow speed, Ⅱ-fast speed, -stop). Trigger under handle 4.1 Pull trigger spray. 4.2 Hold on-pull trigger continuous spay. 4.3 Press lock up button inside continuous spray. 4.4 Release pull trigger stop spray. -
Page 6: Install, Move Out Battery
Discharge residual chemicals. Install, move out battery, Push down battery catch device, Move out battery along slide, Push in battery along slide, catch device will automatically rebound back lock appropriately. - 5 - ... -
Page 7: Spare Parts List
Spare parts list Item No. Spare parts name Quantity Remark Tank Gasket 50×42×3.5 Cover Connecting ring Pressing buckle Spring Φ6.5 PVC Pipe Φ4×Φ6×1900mm PVC Pipe Φ4×Φ6×1800mm Fixed sets Suction head accessory PVC Pipe Φ4×Φ6×250mm Suction head Filter Screw ST2.9×8.5 Cover Self-locking block Brand label... - Page 8 Screw ST3.5×13 Screw M3×10 Flat wash Rivet 3×5.5 Spring card Fixed plate PTFE pipe Φ6×Φ4×13 Rivet 3.5×50 Torsional spring Rolling bearing Hook Storage battery Connecting ring Water-proof joint Sleeve Connecting strip Pressure chamber Switch Seal Motor assembly Motor plate Screws ST2.9×16 Butt plate...
- Page 9 Bellows Handle, under part Screws ST2.9×25 Handle, top part Switch Button Slide block Compression spring Valve switch button Compression spring Adjustable block Pulley Rivet 2×13 Rivet 3×18 Rivet 3×13 Valve core O-ring Ф5.1×1.6 O-ring Ф3×1.25 Valve Extension spring Screw M3×12 Accelerator knob Adjustable lever...
- Page 10 PVC Pipe Φ4×Φ6×100mm Screw ST2.9×13 - 9 - ...
- Page 11 1 : 2 38 39 1 : 2...
