Nexgrill 720-0076 User Manual

32 qt. all stainless steel turkey fryer
Hide thumbs
Table of Contents

Advertisement

Quick Links

32 QT. All Stainless Steel
WARNING:
1. READ ALL INSTRUCTIONS BEFORE USING THIS TURKEY FRYER. FAILURE TO FOLLOW
ALL MANUFACTURER'S INSTRUCTIONS COULD RESULT IN A FIRE OR EXPLOSION WHICH
COULD CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH.
2. USE ONLY THE ENCLOSED HOSE & REGULATOR.
3. DO NOT USE THE ENCLOSED HOSE & REGULATOR ON ANY OTHER GAS APPLIANCES!!
4. USE OUTDOORS ONLY!!
Turkey Fryer
USER MANUAL
Model Number: 720-0076
• Safety Precautions &
Warnings
• Parts List
• Assembly Instructions
• Leak Testing
• Lighting Instructions
• Troubleshooting
• General Cleaning and
Maintenance
• Preparation and Cooking
Instructions
• Limited Warranty
• Recipes

Advertisement

Table of Contents
loading

Related Manuals for Nexgrill 720-0076

Summary of Contents for Nexgrill 720-0076

  • Page 1 ALL MANUFACTURER’S INSTRUCTIONS COULD RESULT IN A FIRE OR EXPLOSION WHICH COULD CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH. 2. USE ONLY THE ENCLOSED HOSE & REGULATOR. 3. DO NOT USE THE ENCLOSED HOSE & REGULATOR ON ANY OTHER GAS APPLIANCES!! 4. USE OUTDOORS ONLY!! Model Number: 720-0076...

  • Page 2: Safety Precautions And Warnings

    SAFETY PRECAUTIONS & WARNINGS NEVER operate an outdoor cooker inside a building or confined area or within 10 feet of any combustible surface or material. Perform all testing outdoors in a well-ventilated area. OUTDOOR USE ONLY Use cooker on level, solid ground or on a concrete surface.
  • Page 3 1. stand 2. burner 3. regulator & hose 4. spring 5.shutter 6. safety ring 7. stockpot 8. pot lid 9. perforated boiler 10. poultry rack 11. fish fryer 12. dipping basket 13.basket handle 14. grab hook 15. 12” thermometer 16. 2 OZ injector 17.

  • Page 4: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Required Tools: adjustable wrench(not supplied); Philips or flat head screwdriver(not supplied) Estimated Time of Assembly: 10 minutes Assemble Regulator The hose and regulator is a pre-assembled unit. Do not take it apart. Simply connect the hose and regulator assembly to the LP gas cylinder and to the cooker.

  • Page 5: Leak Testing

    Assemble Safety Ring Put the safety ring on the stand.(Figure #f Secure the safety ring to the stand by using the 2 clamps fixed on the stand. (Figure #g) (Figure #f) ( Figure #g) Assemble Basket Handle To attach the handle to the dipping basket, align the 3 holes on handle to any 3 holes along the upper-outter rim of basket. With nuts and bolts provided, use a philips or flat head screwdriver, attach the nuts on the outside of the basket and bolts from the inside.

  • Page 6: Lighting Instructions

    4. Splash on a soapy liquid (ex. dishwashing liquid and water) on the connections around the regulator and Propane Tank connection.(Figure #i) (Figure If “growing” bubbles apprear, there is a leak. Close Propane Tank Valve immediately. Retighten connections and repeat the leak test procedures.

  • Page 7: Troubleshooting

    TROUBLESHOOTING 1. Most propane tanks are equipped with a safety device to shut off the flow of gas should the hose be cut or severed. Sometimes this safety device may be tripped when lighting the cooker. To prevent this, ALWAYS make sure the regulator valve is in the closed position ( turned fully “...
  • Page 8 Your deluxe outdoor cooker will fry, steam or boil meat, seafood and vegetables. Maximum capacity is 25 pounds. CAUTION: DO NOT use a kitchen stove for frying a turkey in this unit. This Nexgrill unit is designed for use as a outdoor cooker.

  • Page 9: Limited Warranty

    Therefore, this exclusion may not apply to you. Nexgrill does not assume, or authorize any other person to assume for this Nexgrill Turkey Fryer any liability from the sale of this product beyond that expressly set forth in this limited warranty. This warranty gives you specific rights. The law of your state may give you additioanl rights.
  • Page 10 RECIPES Buffalo Wings 24-30 Chicken Wings 1 Gallon Vegetable Oil 1 Small Bottle of Hot Sauce ½ Teaspoon of Salt ¼ Teaspoon of Pepper ¼ Cup of Butter or Margarine, melted 1 Teaspoon White Vinegar Pich of Garlic Salt Celery Sticks and Blue Cheese Dressing Thaw wings(if frozen) and place into basket.
