Master Chef MR-320 Instruction Manual

Mr-320 (3.2 cu.ft) mr-490 (4.9 cu.ft)
Hide thumbs
1
2
3
4
5

Advertisement

Available languages

Available languages

Table of Contents

NAMES OF THE PARTS

MR-320 (3.2 cu.ft)
1
7 2 4
3
6
9
8
5
1. EVAPORATOR
The heart of the refrigerator.
It evaporates the refrigerant fluid and thereby absorbs heat from the surrounding. Made of pure
aluminum.
2. DRAIN PAN (Use of Defrost Only)
Discards the water that drips of the evaporator when defrosting.
3. CONTROL BOX :
Regulates the operation of the motor and controls the inside temperature of the refrigerator.
4. SHELF
Has full width and can slide out.
5. RACK For butter, eggs, and small size goods.
6. MAGNETIC DOOR SEALS
Keeps the refrigerator virtually airtight all along the edge, but is nevertheless easy to open.
7. ICE CUBE TRAY Ice cubes are easy to remove from the tray.
8. USABLE RACK for cans or jars.
9. BOTTLE RACK for bottles, cans or jars.
10. CRISPER
for vegetables and fruits.
11. SLIDE OUT CRISPER COVER.
¡á MR-490 (4.9 cu.ft)
4 10
11 2 1
7
3
5
8
9
1

HOW TO OPERATE

Starting your new Refrigerator

1. Clean the refrigerator thoroughly. Wipe the outside with a soft dry cloth, the inside with a
damp cloth.
2. Keep the door open and insert the power supply cord into the socket.
3. Turn the thermostat dial to "7". Close the door and let the refrigerator operate for 15-20
minutes.
The freezer should then show some traces of frost.

Temperature control

You can control the inside temperature by turning
the thermostat dial. Higher numbers mean greater
6
cooling power, smaller numbers mean less cooling
power. To make ice cubes in the freezer
compartment, set the dial to "7". The dial does not
have to be set exactly on the numbers, but can be
any place in between.
NOTE : Wait 3 to 5 minutes before restarting if you unplug the machine. Unit may
fail to operate properly if restarted too quickly.
How to defrost
Defrost the refrigerator when the frost accumulated on the evaporator is about 5mm(1/5inch)
thick.
Set the thermostat dial to "OFF". Remove foods. Keep drip tray in place. Defrosting usually takes a
few hours. To defrost quickly remove all foods from the refrigerator and leave door open. Never
use a knife or other metal instrument to remove ice/frost from the evaporator. After defrosting
empty water from drip tray, return the thermostat dial to the desired position to start refrigerating
again.
6
2
TEMPERATURE
CONTROL
1
