- Page 1 PCCextend 145 HP Logic Analyzer Adapter User’s Manual Preliminary M200014-00 July 1996 Sycard Technology 1180-F Miraloma Way Sunnyvale, CA 94086 (408) 749-0130 (408) 749-1323 FAX...
- Page 3 2.0 Using the PCCextend 145 The PCCextend 145 is installed onto the two 34 pin headers located on the PCCextend 140 CardBus extender. The adapter should be mounted in the orientation shown in figure 2.0-1. Once installed, the HP termination adapters (on pods 1-4) can be installed on connectors JP1 through JP4.
- Page 4 Page 2 PCCextend 145 User’s Manual The following tables list the mapping of signals to the HP Logic analyzer adapter: Analyzer Analyzer CardBus CardBus CardBus CardBus Note Note Input Input Signal Signal Signal Signal Pod 1-0 CCBE0# Pod 1-1 CCBE1#...
- Page 5 Table 2.1-1B Signal Connection Table - Part A Table 2.1-1B Signal Connection Table - Part A The PCCextend 145 was designed to be used as state or timing analyzer. Jumpers JP3 through JP4 route selected signals to either regular input channels or CLK inputs.
- Page 6 Page 4 PCCextend 145 User’s Manual CTRDY# Jumper CTRDY# Jumper 1 - 2 CTRDY# is CLK1 on POD 4 2 - 3 CTRDY# in D9 input on POD 1 CCLK Jumper CCLK Jumper 1 - 2 CCLK is CLK1 on POD 1...
- Page 7 PCCextend 145 User’s Manual Page 5 Appendix Appendix A. PCCextend 145 Schematic A. PCCextend 145 Schematic M200014-00 1994-96 Sycard Technology...
