B410 PT Blade Chassis Installation Instruction
Rev
Date
1.0
09/21/2006
2.0
04/03/2007
3.0
4/18/2008
User Manual B410PT
Revision History
Modifications
First Draft
(1) Add Reset Switch on LED board 16-0123-01A, section 2.1
(2) Change top cover to allow easy HDD installation section 3.2
(3) Add air-recirculation block off form section 3.3
(4) Add additional 2.5" slim HDD section 3.4
(1) Change push button for fix the push button to hard to push issue
(2) Support Two 2.5" slim HDD
(3) Damper to reduce vibration to the HDD
(4) Plastic damper housing to reduce vibration to the Fan
(5) Support PCI-express MXM video
Update By
Sio Fu
Sio Fu
Sio Fu
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for TST B410PT
-
Page 1: Revision History
User Manual B410PT B410 PT Blade Chassis Installation Instruction Revision History Date Modifications Update By 09/21/2006 First Draft Sio Fu 04/03/2007 (1) Add Reset Switch on LED board 16-0123-01A, section 2.1 Sio Fu (2) Change top cover to allow easy HDD installation section 3.2 (3) Add air-recirculation block off form section 3.3... - Page 2 User Manual B410PT TST Corporation Blade Server Chassis www.tstcom.com User Guide Revision 2.0 US version April 2007...
- Page 3 Information in this document is provided in connection with TST products. No li- cense, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provide in TST‘s Terms and Conditions of Sale for such products, TST assumes no liability whatsoever, and TST disclaims...
- Page 4 (3) years from the date of invoice. These are the only war- ranties TST offers. TST makes no other warranties of any kind, express or implied, written, oral or statutory, and expressly disclaims any implied warranties, including...
- Page 5 User Manual B410PT Safety Instructions Use the following safety guidelines to ensure your own personal safety and to help protect your server, storage system, or appliance from potential damage. Throughout this guide, blocks of text may be accompanied by an icon and printed in bold type.
- Page 6 User Manual B410PT Safety Instructions If any of the following conditions occur, unplug the product from the electrical outlet and replace the part or contact your authorized service provider: The system cable, extension cable, or plug is damaged. An object has fallen into the product.
- Page 7 User Manual B410PT Safety Instructions There is a danger of a new battery exploding if it is incorrectly installed. Replace the battery only with the same or equivalent type recommended by the manufacturer. Do not dispose of the battery along with household waste.
-
Page 8: Table Of Contents
User Manual B410PT Index 1. Product Overview ...................1 Chassis Description ....................1 Chassis Front & Rear Views ................3 Chassis Front Panel Features ................4 Chassis Dimensions ....................5 Blade Components ....................5 2. System Board and Cable Features ............7 Front Panel Board ....................6 Serial ATA Backplane Board .................8 3. - Page 9 User Manual B410PT List Of Figure Figure 1 Front View of the Chassis ..................3 Figure 2 Rear View of the Chassis ..................3 Figure 3 Front Panel indicator ....................4 Figure 4 Chassis Dimension ....................5 Figure 5 Blade Dimension ....................5 Figure 6 Blade Opened view ....................6...
- Page 10 User Manual B410PT List Of Table Table 1 Front Panel Board ....................7 Table 2 22-pin Serial ATA pin assignment ................8 Table 3 7-pin Serial ATA data header pin assignment ............9 Table 4 4-pin Power header pin assignment ..............9 Table 5 CPU fan specification ..................24...
-
Page 11: Product Overview
Evidence of any damage to these chassis should be reported to the shipper immediately. If the wrong model has been received, please call your reseller or TST at 626-968-8851 to ar- range for a Return Material Authorization (RMA). TST cannot accept returns which do not display an RMA number on the outside of the package. - Page 12 User Manual B410PT The following compinents are included in the accessories box #6-32 RH screws 90 pcs (order #09-1003-01A) M5 x 3/4” Pan Head Screws, 24 pcs (order#09-1052-01A) AC Cord North America 10 pcs (order # 17-1012-01A) M5 Cage Nuts, 16 pcs...
-
Page 13: Figure 1 Front View Of The Chassis
User Manual B410PT 1.2 Chassis Front & Rear View Figure 1 Front View of the Chassis Blade modular Chassis Base Figure 2 Rear View of the Chassis Slide Rail Bracket Chassis Base Power AC Inlet... -
Page 14: Figure 3 Front Panel Indicator
User Manual B410PT 1.3 Chassis Front Panel Features Figure 3 Front Panel indicator Front Panel Button, connectors and LED functions Video Port To connect to display device Serial Port To connect to serial device Connect to network devices. NIC 1... -
Page 15: Figure 4 Chassis Dimension
User Manual B410PT 1.4 Chassis Dimensions 28.0” 6.95” 19.0” Figure 4 Chassis Dimension 1.5 Blade Dimensions 26.0” 1.8” 6.0” Figure 5 Blade Dimension... -
Page 16: Blade Components
User Manual B410PT 1.6 Blade components Figure 6 Chassis opened view motherboard Exhausted Fan 2.5” HDD... -
Page 17: System Board And Cable Features
User Manual B410PT Chapter 2. System Board and Cable Features 2.1 Front Panel Board (order #16-0123-01A) The Front Panel Board supports several push buttons and status LEDs to centralize system control, monitoring, and accessibility to within a common compact design. The following diagram overviews the board layout and pin assignments for connectivity. -
Page 18: Integration Steps
You have read the safety instructions of this user manual. Always follow the in- structions closely. While working on the system, do not attempt to service the system except as explained in this guide and elsewhere in TST documentation. You can install, replace or reinstall a part by performing the removal procedure in reverse order, unless additional information is provided. -
Page 19: Figure 15 Loosen The Thumbscrews
User Manual B410PT 3.1 Removing the server blade WARNING: DO NOT USE TOP THUMB SCREW TO LIFT CHASSIS! These thumb screws are used only to install and remove the blade only! 3.1.1 Removing the blade Ensure that the work surface is flat and clean to... -
Page 20: Removing The Top Cover
User Manual B410PT 3.2 Removing the top cover #6-32 FH screws (order #09-1002-01A) Ensure that the work surface is flat and clean to prevent scratching the computer cover Untigthen two flat head #6-32 6mm screws of the HDD cover as shown on the figure. -
Page 21: Figure 21 Secure The Board By Tighten Mounting Screws
User Manual B410PT 3.3 Installing the motherboard Board Before you perform this procedure, read the safety instructions of this manuel See safety instructions in Port Townsend Board Information document. Remove the blade from the chassis (see section 3.1) then, remove the front and rear top covers (see section 3.2) -
Page 22: Figure 23 Secure The Hdd On The Mounting Bracket
User Manual B410PT 3.4 Install and Remove a Hard Disk Drive NOTICE: Extra care must be taken when handling and storing the hard drives. The carriers provide some protection, but the hard drives can be damaged by rough handling. When removing the hard drives from the storage system, place them on a padded surface. -
Page 23: Figure 24 Remove The Fan From The Blade
User Manual B410PT 3.5 Changing fans Before you perform this procedure, read the safety instructions of this manuel Remove the blade from the chassis (see section 3.1) then, remove the front and rear top covers (see section 3.2) Unplug the 8pin power cable form the mother-... -
Page 24: Figure 27 Take Out The Psu Mounting Screws
User Manual B410PT 3.6 Replacing the Power Supply Module Before you perform this procedure, read the safety instructions of this manuel The only way to disconnect power completely is to unplug the power cord When connecting or disconnecting a cable, always hold the cable by its connector, the plug, not the cord Never open the power supply module for any reason. - Page 25 User Manual B410PT 3.7 Replacing the system battery Before you perform this procedure, read the safety instructions of this manuel The purpose of this section is for system integrator to submit for product safety conformity that may require paper trail instruction on replacing system battery.
-
Page 26: Convert The Rackmount Blade To Stand-Alone Blade
User Manual B410PT 3.8 Convert the rackmount blade to stand-alone blade The B410PT Port Townsend blade rackmount chassis can be easy to change to a stand-alone blade chassis . Install the Stand-alone top cover as shown by snap in the top cover into the rackmount chassis. -
Page 27: Install The System Into The Rack
When configured with a full set of drives, power supply and server board, the system weighs will be over 100 pounds. Take the following precautions to avoid problems or potential injury as you handle the B410PT blade chassis Do not unpack, lift or carry the system by yourself. Always have another person... -
Page 28: Install The Chassis In A Rack
User Manual B410PT This unit should be mounted at the bottom of the rack if it is the only unit in the rack. Use caution when pressing the component rail release latches and sliding a component into or out of a rack; the slide rails can pinch your fingers. -
Page 29: Figure 35 Rack's Mounting Hole Types
User Manual B410PT 4.2 Install the chassis in a Rack The blade chassis is specifically designed for rack mounting. You can install the system in a four-post cabinet or open rack that is 19 inches wide and between 28”, 30” and 36” deep. -
Page 30: Figure 36 Marking On The Rack
User Manual B410PT 4.2.1 Marking the rack You must allow 1U (44mm or 1.75 inches) of vertical space for each system you install in the rack. Rack cabients that meet EIA-310D standards have a pattern of three holes per rack unit with center-to-center holes spacing (beginning at the top holes of a 1U space) of 0.625”... -
Page 31: Figure 37 Removing The L-Shape Rack Mounting Bracket
User Manual B410PT 4.2.2 Install the chassis in a Rack From the rear of the blade chassis, untighten the #6-32 flat head screws as shown Slide out the L-shape rack mounting bracket #6-32 FH screws (09-1002-01A) Figure 37 Removing the L-shape rack mounting bracket... - Page 32 User Manual B410PT 5.1 Exhaust Fan Specification 40mm x 40mm x 28mm P-V curve Figure 41 System fan specification and P-V curve Specification ITEM DESCRIPTION Model Number Sunon PMD1204ppB1-A Rated Voltage 12V DC Input Voltage 7.0-13.2V DC Input Current 1.4A Speed 14500/9500 R.P.M.
-
Page 33: Figure 42 275W Power Supply Unit
User Manual B410PT 6. Power Supply Specification DC Output Characteristics Output Output Current Voltage MIN(A) MAX(A) -12V 3.3V +5VSB Table7 275W PSU DC Output Characteristics Figure 42 275W power supply Unit Specification ITEM DESCRIPTION Model Number ENO-3927B-G Input Voltage/Frequency 100-240 V AC/50~60Hz Input Current 6.0/3.0 A for 115/230 VAC... -
Page 34: Power Budget Calculation
User Manual B410PT 7. Power Budget Calculation Use these worksheet below to calculate the total power used by your configuration. List all current into the appropriate voltage level for each device and calculate the total current on each voltage level DO NOT OVERLOAD: Do not exceed power limit for any DC outputs 7.1 275W Power Supply... - Page 35 User Manual B410PT 8 BTU usage calculation Use this worksheet below to calculate the BTU (British Thermal Unit) usage of your ESR system configuration 50% loading, 75% loading and 100% loading. Loading Equation to calculate system power comsumption to BTU Result = Total Combine Wattage X 2.05...
