Ultra chef DOM-B51 Instruction Manual

Cfc-free
Hide thumbs
1
2
3
4
5
6

Advertisement

Table of Contents

F E ATURE CHART
FREEZER DOOR GASKET
FREEZER POCKET
FREEZER REMOVABLE SHELF
FREEZER TEMPERATURE
CONTROL KNOB
ICE TRAY
ICE BOX
REFRIGING-ROOM DOOR GASKET
EGG POCKET
REFRIGING-ROOM POCKET ( SMALL )
REFRIGING-ROOM POCKET ( LARGE )
LAMP COVER
REFRIGERATOR TEMPERATURE
CONTROL KNOB
REMOVABLE SHELF (LARGE)
GLASS SHELF
VEGETABLE BOX
CHILLED TRAY
1
Here are the features of your new refrigerator.
Take a moment to know all the features and convenience it was designed to provide.
Numbers match those in the illustration on page 1.
Ice tray
Fill tray 3/4 full to allow expansion of water during freezing. Place tray in freezer
chest. To release cubes, twist lid slightly.
Removable shelf
Shelves can be removed by pulling forward. The shelf can be placed at your
desirable position.
Freezer Shelf
To remove the freezer shelf!
1. Remove the screw on the left of inside freezer shelf with screw driver.
2. Push the shelf hooks to the back slightly and remove it by lifting off the slots of
bottom side.
3. Reverse procedure to install.
Defrost Drain Ve s s e l
To remove defrost drain vessel.
1. Lift the defrost drain vessel slightly, then rotate bottom out and pull it down.
2. Reverse procedure to install.
2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DOM-B51 and is the answer not in the manual?

Questions and answers

Summary of Contents for Ultra chef DOM-B51

  • Page 1 F E ATURE CHART Here are the features of your new refrigerator. Take a moment to know all the features and convenience it was designed to provide. Numbers match those in the illustration on page 1. Ice tray Fill tray 3/4 full to allow expansion of water during freezing. Place tray in freezer chest.

  • Page 2: M Ethods Of Safe Insta L Lat I O N

    M ETHODS OF SAFE INSTA L LAT I O N Lamp Cover 1. SAFE INSTALLATION PLACE FOR YOUR REFRIGERATOR To remove lamp cover 1. Push up the bottom ends of lamp cover gently, then pull out. • • • Place the refrigerator Place your refrigerator Place the refrigerator 2.

  • Page 3: Installation Steps

    2. INSTALLATION STEPS 3. THINGS TO KNOW BEFORE MOVING OR RELOCATING THE REFRIGERATOR! • • • • • • Select a safe place to Level the refrigerator Install the parts to their Unplug the power Take food out of the Fasten the interior install your refrigerator.

  • Page 4: How To Install

    HOW TO INSTA L L Location 4. CLEANING YOUR REFRIGERATOR Install refrigerator in a convenient location away from extreme heat and cold. Allow sufficient clearance about 6 cm between the refrigerator and • • • When cleaning your The refrigerator can Use a soft cloth for rear wall so it is easy for refrigerator to radiate heat.

  • Page 5: How To Operate

    HOW TO OPERAT E TEMPERATURE CONTROL Turn TEMPERATURE CONTROL toward MAX for colder temperature in refrigerator and freezer sections, and toward MIN for warmer temperature in Temperature is controlled automatically. The TEMPERATURE CONTROL at the inside refrigerator and freezer sections of the refrigerator and freezer section control the degree of cooling of each compartment.
  • Page 6 W H AT TO DO . . . Ultra Chef When out of operating for a long time. D O M - B 5 1 Remove the power supply cord. Model No.: Dry your refrigerator, opening the door for 2-3 days.
