Chapter 9. FRU lists

This chapter lists the information on the field replaceable units (FRUs).
Attention: Be sure to read and understand all the safety information before replacing any FRUs.
Notes: FRUs that have a 1 or 2 in the CRU column are Customer Replaceable Units (CRUs).
• 1– identifies parts that are fairly simple to replace, requiring few or no tools.
• 2– identifies parts that are slightly more difficult to replace.
• N-identifies parts that are not to be replaced by the customer.
Item# Description
1 Motherboard
MB FRU NOK
MB FRU W8S
MB FRU W8P
2
CPU
I I74770K 3.5/1600/8/1150 84 CPU
I I54670K 3.4/1600/6/1150 84 CPU
3 PSU
ACBEL PC7033-EL0G 450W NEW CABLE PSU
ACBEL FS8003-EL1G ES5.0 625W PSU
4 Memory
HMT451U6AFR8C-PB 4GB D3-1600 MEMORY
M378B5273DH0-CK0 4GB D3-1600MEMORY
Elp_R J4208EBBG-GN-F 4GB D3L-1600 MEMORY
Mic_S D9QVG 4GB D3-1600 MEMORY
MT8JTF51264AZ-1G6J1 4GB D3-1600 MEMORY
M378B1G73BH0-CK0 8GB D3-1600MEMORY
HMT41GU6AFR8C-PB 8GB D3-1600 MEMORY
MT16JTF1G64AZ-1G6E1 8GB D3-1600 MEMORY
Elp_R J4208EBBG-GN-F 8GB D3L-1600 MEMORY
5
Graphics
MSI@Geforce GTX 650@2G/B/2D/mHDMI VGA
MSI@Geforce GTX 660@1.5G/B1/2D/DP/H VGA
AMD@HD8950@3G/B/D/H/2miniDP VGA
Bitland@HD8670@2G/B/DB/H/D VGA
Bitland@Geforce GTX 760@2G/A/2D/DP/H VGA
6 HDD
© Copyright Lenovo 2013, 2013
Service Part CRU ID
Number
90002894 N
90002895 N
90002896 N
1100782 N
1100784 N
36200512 N
36200513 N
1100649 2
1100213 2
1100651 2
1100652 2
1100681 2
1100217 2
1100647 2
1100669 2
1100648 2
11201703 2
11201867 2
11201704 2
11201702 2
11202298 2
