Dear Valued Customer,
Congratulations on your new Smart Sound Bar 2.1 purchase. Thank you for your
support. This sound bar is built-in Android™. To ensure safety and many years of
trouble free operation of your Sound Bar 2.1, please read the manual carefully before
making any adjustments, and keep them in a safe place for future references. The
Smart Sound Bar 2.1 is a versatile speaker unit with both digital and analog audio inputs
for audio visual sources. Connect the Smart Sound Bar to the audio output of your TV
and you can use the Smart Sound Bar 2.1 to enhance the sound from all sources
playing through your TV. We hope you enjoy your new Smart Sound Bar 2.1.
For technical assistance, please call 1800-788-2878 and select option 3 or email our
tech support group at
www.sceptre.com
.
For all other inquiries, please call 1800-788-2878 and select option 4 or email our
customer service group at
www.sceptre.com
.
We recommend you register your Smart Sound Bar 2.1 online at
http://www.sceptre.com
SceptreTS@sceptre.com
SceptreCS@sceptre.com
.
- 1 -
Smart Sound Bar 2.1 User Manual
or chat with us online at
or chat with us online at
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Sceptre SB301524W
-
Page 1: Dear Valued Customer
Smart Sound Bar 2.1 to enhance the sound from all sources playing through your TV. We hope you enjoy your new Smart Sound Bar 2.1. For technical assistance, please call 1800-788-2878 and select option 3 or email our SceptreTS@sceptre.com tech support group at or chat with us online at www.sceptre.com... -
Page 2: Table Of Contents
Table of Contents TABLE OF CONTENTS 2 SAFETY INFORMATION 3 SAFETY INSTRUCTIONS 4 PACKAGE CONTENTS 6 OVERVIEWS 6 & B RONT & E OUND EMOTE XTRAS OUNTING THE OUND NSTALLING ATTERIES TO THE EMOTE ONTROL CONNECTION SUGGESTIONS 15 TV 15 F YOU HAVE DIGITAL AUDIO WITH YOUR TV 16 F YOU HAVE ANALOG AUDIO WITH YOUR... -
Page 3: Safety Information
SAFETY INFORMATION Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if improperly handled. This product has been engineered and manufactured with the highest priority on safety. However, improper use can result in electric shock and / or fire. In order to prevent potential danger, please observe the following instructions when installing, operating and cleaning the product. -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS This product is designed and manufactured to operate within defined design limits, and misuse may result in electric shock or fire. To prevent the product from being damaged, the following rules should be observed for the installation, use and maintenance of the product. - Page 5 apparent, unplug the power cord Insert batteries in accordance and contact your dealer with instructions while using the immediately. Do not try to repair remote control. Incorrect the product yourself. polarities may cause damage and leakage of the batteries, Avoid using dropped or operator injury and damaged appliances.
-
Page 6: Package Contents
Package Contents Smart Sound Bar x 1 User Manual x 1 Warranty x 1 Drywall Anchor with Screw x 2 Sets 3 Head RCA Audio Cable x 1 3.5 mm Mini-jack Cable x 1 ... -
Page 7: Sound Bar Remote & Extras
Sound Bar and any Sceptre TV. The mute button of the Sound Bar only mutes the sound bar not the Sceptre TV, however if you use the Sceptre TV remote’s mute, it will mute the Sound Bar. - Page 8 Top of the Remote POWER – This button turns the sound bar on or off. (0-9), *, # – 0 functions as numerical key and space key. 1 functions as the numerical key and also the punctuation key. Press it repeatedly in order to cycle through all the punctuation marks.
- Page 9 Middle of the Remote HOME – This button brings you back to the home screen. ▲▼◄► – These buttons function as up, down, left, and right selection. When you press the KEYBOARD/MOUSE button it also functions as moving the mouse pointer. MENU –...
- Page 10 Bottom of the Remote ZOOM IN / ZOOM OUT – These buttons zooms in and out for pictures and web pages. VOL(+) / VOL(-) – These buttons increases or decreases the sound bar’s volume. PLAY/PAUSE, REWIND, FAST FORWARD, PREVIOUS CHAPTER, NEXT CHAPTER –...
- Page 11 Some Sceptre HDTV remotes might also have buttons used to control the sound bar. If you see Power, Source, Mode, Vol (+/-) buttons encircled with the SOUNDBAR word next to it, you can use them to control the Sound Bar.
-
Page 12: Sound Bar
Mounting the Sound Bar To mount the Sound Bar you need to have 520 mm of horizontal space on the wall. Measure the length of 520mm on the wall. With a pencil mark the two entry points where you are going to install the dry wall anchors and puncture the points with a nail so it is easier for the anchor to be screwed in. - Page 13 Align the mounting brackets on the back of the sound bar to the two screws protruding on the wall and fit into them, then finally slowly lower the sound bar so that it securely hangs onto the screws. - 13 - Smart Sound Bar 2.1 User Manual...
-
Page 14: Installing Batteries To The Remote Control
Installing Batteries to the Remote Control Please insert two AAA batteries into the remote control. Make sure that you match the (+) and (-) symbols on the batteries with the (+) and (-) symbols inside the battery compartment. Afterwards, re-attach the battery cover. Please note: ... -
Page 15: Connection Suggestions
Connection Suggestions If you have digital audio with your TV… Grab the included 3 head RCA audio cable and use the black colored RCA plug. Find the SPDIF digital audio coax connection on the back of the TV and connect one end of the cable to it. -
Page 16: If You Have Analog Audio With Your Tv
If you have analog audio with your TV… Grab the included 3 head RCA audio cable and use the red and white colored RCA plug. Find the analog audio out on the back of the TV and connect one end of the cable to it matching the colors red to red, and white to white. -
Page 17: If You Have An Audio Device With Your Tv
If you have an audio device with your TV… Grab the included 3.5mm mini-jack cable. Find the headphone jack connection on the audio device and connect one end of the cable to it. Connect the other end of the cable to the back of the Smart Sound Bar’s LINE IN connection. - Page 18 Using the features of Android on the Sound Bar with your TV… Obtain a HDMI cable (not included). Find a HDMI port on the sound bar and the TV. Connect one end of the cable to the back of the Smart Sound Bar’s HDMI connection and the other end to TV’s HDMI connection.
-
Page 19: Operation
Operation TO SWITCH ON / OFF THE UNIT Press the POWER icon on the front panel or the RED button on the remote control to turn on the unit. If the unit is ON you will see the display window show the source selected, volume level and sound mode. - Page 20 Setting up for Android Follow the instructions in page 18. Once the sound bar is displaying the initial setup screen for Android, you can begin setting it up. Use the directional buttons on page 9 to select through the options. Go through the selection, choosing your language, and setting up wireless network.
- Page 21 In the event you cannot enter letters via the number pad, press the EN/CH button on the remote control repeatedly until you see on the screen, then you can start entering alphabets via the number pad. Adjust the time, date, and finally adjust the screen size. The white border is supposed to be at the edge of your screen.
- Page 22 Apps, Media, & Settings Apps The APPS selection contains all the installed programs that allow the user to do a variety of things similar to a computer such as to go on the internet, or use email. You can also go on Google Play Store™ to install or remove additional applications. Use the remote’s directional buttons to select the app you want to launch.
- Page 23 Media The media selection allows the user to connect a USB flash drive or SD memory card and play music, picture, or video files from them. Use the remote’s directional buttons to select the media you want to launch. To exit the app press the HOME button or press the BACK button repeatedly.
- Page 24 Settings The settings selection allows the user to adjust the inner workings for Android. You can manage where to store your applications, change wall paper, setup WIFI manually, change the language and input language for Android. You can also perform factory reset (wiping clean everything and start from the beginning).
-
Page 25: How Do I Clean The Sound Bar
How do I clean the Sound Bar? IMPORTANT The power cable has to be removed from the socket before cleaning the Sound Bar. Do not use volatile solvent (alcohol, rosin, and toluene) to clean the Sound Bar. These types of chemicals might damage the housing. Cleaning the bezel and remote control Use a 100% cotton cloth or micro-fiber cloth for cleaning. -
Page 26: Troubleshooting
Troubleshooting The following table contains the common problems and the solutions to these problems. Please check this list before you contact the technicians. Problems Solutions Try increasing the volume of the speaker. NO SOUND Check that the Sound Bar is not turned off. Check the Sound Bar volume level. -
Page 27: Call Us If You Need Help
Operation Hours : Mon - Fri at 8:30 AM – 5:30 PM (PST) 16800 East Gale Ave. City of Industry, CA 91745 TEL : 626-369-3698 FAX : 626-855-5711 Website : www.SCEPTRE.com - 27 - Smart Sound Bar 2.1 User Manual... -
Page 28: Specification
Specification 2 × 2” Speaker(s) x Diameter (inch) Speaker type Active 8Ω Rated Impedance Full range Speaker 160 Hz – 20k Hz Frequency Response (Hz) Sound Pressure Level (dB) 80dB ± 3dB Output Power (Watt) 2 × 18W 1 × 3” Subwoofer x Diameter (inch) Additional 1 passive Bonus... - Page 29 Standard (AES), USB 2.0 × 2 (Support up Inputs (NTFS / FAT32 / FAT) to 2TB) SD Card × 1 (Support up Inputs (NTFS / FAT32 / FAT) to 32GB) I/O Ports Outputs HDMI × 1 Network Access media on DLNA Media Sharing app enabled network devices** Multimedia...
- Page 30 ***The product’s specifications may change without notice or obligation. ****This manual’s pictures and words are for references only and are subject to change without notice or obligation. Sceptre Inc is not liable for the misuse or misinterpretation of this manual.
-
Page 31: Limited Product Warranty
DO NOT RETURN YOUR UNIT TO SCEPTRE WITHOUT PRIOR AUTHORIZATION. Parts New or remanufactured parts will be used for repairs by SCEPTRE at its designated Service Center for one (1) year (or ninety (90) days for commercial use) from the effective warranty date. - Page 32 SCEPTRE, INC. or any dealer, distributor of authorized service provider/partner has been advised of the possibility of such damages, or any claim by any other warranty are not covered by this warranty or Sceptre Inc.
-
Page 33: Disclaimer, Trademarks, & Copyright Information
SCEPTRE is a trademark or registered trademark of Sceptre Group. Sceptre, Inc. shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product. -
Page 34: Fcc Compliance Statement
FCC Compliance Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following conditions: This device may not cause harmful interference This device must accept any interference received, including interference that my cause undesired operation. Please Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
